TP-Link M5250 Manuel utilisateur

7106504705 REV 1.0.0

Specifications are subject to change without notice. TP-LINK is a registered

trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product

names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any

means or used to make any derivative such as translation, transformation, or

adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

www.tp-link.com

TP-LINK TECHNOLOGIES CO., LTD.

3G Mobile Wi-Fi

български

English

Češna

Ees

Hrvatski

Latviešu

Magyar

Lietuvių

Polski

Română

Slovenčina

Srpski jezik/Српски језик

Slovenski

CONTENTS

English......................................................1

български ................................................6

Čeština ...................................................11

Eesti........................................................16

Hrvatski...................................................21

Latviešu ..................................................26

Lietuvių ...................................................31

Magyar....................................................36

Polski......................................................41

Română..................................................46

Slovenčina..............................................51

Slovenski ................................................56

Srpski jezik/Српски језик .......................61

English

Quick Installation Guide

The product model shown in this QIG is "M5250",as an example.1.

Information for technical support can be found in the last page.2.

Connecting to the Internet

1Hardware Installation

Open the cover upwards, then install the SIM card, battery as shown.

Step 1: Step 3:

Step 2:

*The SIM card is not provided by TP-LINK.

*Micro or Nano SIM cards should be converted using provided SIM card trays.

*Recommend using the provided battery.

*Make sure to

have the triangle

notch outwards.

Note:

English

Turn on the M5250

Hold the power button until the LED screen is as shown below. (You

can also hold the power button to turn off the M5250.)

Connecting to the Internet

When power on, the M5250 will boot in 1 minute. Please follow the

corresponding instructions according to the status of Internet LED.

Refer to1. Establish a Wireless

Connection.

Finish:2. Now you can enjoy the

Internet.

Refer to1. Establish a Wireless

Connection.

Refer to2. FAQ2.

Finish:3. Now you can enjoy the

Internet.

Establish a Wireless Connection

Search for the Wireless Network name (SSID) and type in the Wireless

Password found on the M5250 rear cover label.

*Advanced conguration

For advanced conguration, please enter the web-management page:

Type http://192.168.0.1 in a web browser and press Enter, then enter the

default username and login password: admin, and press Log in.

*We suggest changing the wireless name and password on the Web-

Management page for your own security.

English

FAQ(Frequently Asked Questions)

FAQ1.What should I do if I cannot log into the web-management

page?

Verify that your device is connecting to the M5250.1.

Verify that you entered the correct IP address http://192.168.0.1.2.

Verify that your device is obtaining an IP address automatically.3.

FAQ2.What should I do if I cannot access the Internet?

Tip1. Check the LAN connection

Type1. http://192.168.0.1 in a web browser and press Enter, then

enter the default username and login password: admin, and press

Check if you can log into the web-management page successfully.If2. not, please refer to FAQ1 and retry.

Tip2. Check the PIN code

Type1. http://192.168.0.1 in a web browser and press Enter, then

enter the default username and login password: admin, and press

Check the "2. Connection Status->SIM Card Status" on the Status

page.

If the current status is PIN required , please choose "3. Advanced

->SIM Lock->PIN Management", then enter the correct PIN code

according to your ISP and click Unlock for the settings to take effect.

Tip3. Check your ISP parameters

Type1. http://192.168.0.1 in a web browser and press Enter, then

enter the default username and login password: admin, and press

Choose "2. Advanced->Dial-up->Prole Management" to verify the

parameters are correct with your ISP. These parameters include

APN, User name and Password.

If these settings are not correct, please click3. Create to create a

new prole with the correct parameters, and then select Dial-up to

choose the new prole from the Prole List.

Tip4. Check the current network connection mode

Type1. http://192.168.0.1 in a web browser and press Enter, then

enter the default username and login password: admin, and press

Choose "2. Advanced->Dial-up" to check the Dial-up Type, if the

current type is manual, and the Network status is Disconnected,

then click Connect button to reconnect it.

English

Note:In the manual connection mode, the M5250 will lose 3G

connection automatically if internet activity idles for 5 minutes, in

that case, you can repeat Tip4 to recover.

Tip5. Check the SIM card status

Verify that your SIM card has sufcient credit.1.

Verify that your SIM is in your ISP’s service area.2.

Verify that your SIM card is a WCDMA or GSM SIM card.3.

Verify that you install the SIM card correctly.4.

FAQ3. How do I restore factory default settings?

Tip1. Hold the RESET button for about 5 seconds until all of the LED

light on.

Tip2. Log into the web-management page, and go to "Advanced

->System Tools->Restore Factory".

Note:once the M5250 is restored, all the current congurations will be lost

and you may need to recongure it.

If your questions are not included here, please refer to our offical

website www.tp-link.com for technical support.

Charging Your M5250

Method 1:

Via the Power Adapter

Method 2:

Via Computer USB

*If the battery icon on the M5250’s LED screen light on and doesn’t ash any

more, it means your M5250 is fully recharged.

English

Important Safety Information

Keep the device away from water, re, humidity or hot environments.

•

Do not attempt to disassemble or modify the device.

•

Do not use damaged power adapter or USB cables to charge the device.

•

Do not use any chargers other than those recommended.

•

Do not use the device where wireless devices are not allowed.

•

*Please follow the above instructions when operating the device. We cannot

guarantee that no accidents or damage will take place due to improper use

of the device. Please use with care and operate at your own risk.

Screen Display

Power Saving Mode

For power saving, you may encounter the three situations below:

The LED icon and will turn off and the will ash automatically 1. after 60 seconds.

The WiFi connection will turn off automatically if no WiFi devices connect2. to the M5250 for 15 minutes.

When the M5250 is in manual connection mode, the 3G connection will3. disconnect automatically if internet activity idles for 5 minutes.

How do I recover from power saving mode?

In 1 and 2, you can simply tap the power button to recover.

•

In 3, you can log into the web-management page, and go to "

•Advanced

->Dial-up",then click the Connect button to reconnect.

*Please refer to the User Guide to modify the 3G and Wi-Fi Power Saving

default settings.

Battery Status

Internet Connected

WiFi Status

български

Ръководство за бърза инсталация

Моделът на продукта, показан като пример в това бързо 1. ръководство за инсталация, е „М5250”.

Информация за техническа поддръжка може да бъде 2. намерена на последната страница.

Свързване към интернет

1 Хардуерна инсталация

Отворете капака нагоре, след което инсталирайте SIM картата,

батерията, както е показано.

Стъпка 1: Стъпка 2:

Стъпка 3:

*SIM картата не се предоставя от TP-LINK.

*SIM карти от тип Micro или Nano трябва да се преобразуват с помощта

на предоставените конзоли за SIM карти.

*Препоръчително е да се използва предоставената батерия.

*Уверете се,

че триъгълният

прорез е отвън.

Забележка:

български

Включете продукта М5250

Задръжте бутона за захранването , докато LED екранът е такъв,

както е показан по-долу. (Можете също да задържите бутона за

захранването, за да изключите М5250.)

Свързване към интернет

След включване М5250 ще зарежда за 1 минута. Моля, следвайте

съответните инструкции според състоянието на светодиодния

индикатор за интернет.

Направете справка с 1. Установяване на безжична

връзка.

Край: 2. Сега можете да се

наслаждавате на интернет.

Направете справка с 1. Установяване на безжична

връзка.

Направете справка с 2. ЧЗВ2.

Край: 3. Сега можете да се

наслаждавате на интернет.

Установяване на безжична връзка

Потърсете името на безжична мрежа (SSID) и напишете паролата

за нея, която се намира на етикета на задния капак на M5250.

*Разширена конфигурация

За разширена конфигурация влезте в страницата за управление

на уеб:

Напишете http://192.168.0.1 в уеб браузър и натиснете Enter, след

което въведете потребителското име по подразбиране и паролата

за влизане: admin и натиснете Log in (Влизане).

*Ние предлагаме да промените името на безжичната мрежа и

паролата за нея на страницата за управлен ие на уеб за вашата

собствена сигурност.
