Toyota COROLLA MATRIX 2009 Manuel utilisateur

2009 Navigation System

Quick Reference Guide

Customer Experience Center 1-800-331-4331

MN 00505-NAV09-MAT

Printed in USA 12/07

412031M1_R2.indd 1 1/2/08 6:38:41 PM

TABLE OF CONTENTS

114

LIMITATIONS OF THIS QUICK REFERENCE GUIDE 1

BASIC OPERATION 2

DESTINATION INPUT 3

By Address 3

DESTINATION INPUT - POINTS OF INTEREST (POI) 5

Points of Interest by Name 5

Points of Interest by Category 6

DESTINATION INPUT - TELEPHONE NUMBER 7

Business or Registered Memory Points 7

ADDITIONAL NAVIGATION FEATURES 10

Search Area 10

Route Preferences 10

3 Routes 10

Screen Preferences 10

Beep Setting 11

Volume Setting 11

Keyboard Setting 11

Screen Transition 11

Freeway Exit Info Mode 11

Estimated Distance and Time 12

Operation of Your Vehicle Emergency Screen 12

XM NAVTRAFFIC®13

This Quick Reference Guide is designed to provide information

on the basic operation and key features of the navigation system.

The Quick Reference Guide is not intended as a substitute for

the Navigation Owner’s Manual. We strongly encourage you to

review the Navigation Owner’s Manual so you will have a better

understanding of the navigation system capabilities and limitations.

LIMITATIONS OF THIS QUICK REFERENCE GUIDE

Press the

panel button,

and then touch .

step1Select preferences.

step2

XM NAVTRAFFIC®PREFERENCES

Show XM

NavTrafoc

Information:

Auto Avoid Trafoc:

Traf oc Voice

Guidance:

Show Free

Flowing Trafoc:

Touch to display trafoc information on the map.

Tr a f oc pow is displayed by color lines right along the side of the

freeways:

Free pow trafoc

Light trafoc jam

Heavy trafoc jam

Touch to make selecting another route offered by the system

when heavy or moderate trafoc is detected on the guidance route.

Touch to have trafoc information provided using voice

guidance.

Touch to show free powing trafoc illustrated by green arrows

on the map.

412031M1.indd 2 12/20/07 4:59:06 PM

BASIC OPERATION

NORTH UP OR COMPASS MODE Icon

Touch to change the map display between

North-up or Head-up perspectives.

ZOOM IN/ZOOM OUT Icons

Touch to magnify or reduce the

map scale.

INFO Button

Access Maintenance, Telephone,

Calendar, Language, and Screen Settings.

DISPLAY/TILT Button

Adjust the contrast, brightness or

turn off the screen. Change the angle

of the screen for best viewing.

AUDIO Button

Set the radio station presets, adjust the

balance and tone controls.

MENU Button

Access Voice Guidance Volume, Select

User, My Places, Setup and Suspend

Guidance.

DESTINATION Button

Input the destination by one of several

methods and initiate route guidance.

MAP/VOICE Button

Repeat the last voice guidance prompt

or cancel one touch scroll.

CURRENT VEHICLE POSITION Mark

Indicates the current position of the

vehicle and its directional heading.

{



AM•SAT

DISC•AUX

INFO

AUDIO

DEST

TUNE SEEK

TRACK

PWR•VOL

VOICE NAVIGATION

WMA

TOYOTA

SAT

M•

•S

•

TOY

PWR

•

VOL

E NAVI

ATI

MAP

VOICE

DIO

DISP

TILT

412031M1.indd 3 12/20/07 4:59:06 PM

DESTINATION INPUT

BY ADDRESS

Press the

DEST

panel button

followed by and move to

step 3. To change Search Area,

touch and move to step 2.

Input the house number using the

number keys.

Touch and input the

street name using the letter keys.

Touch to see all of the

available options.

Use or to scroll up or down

one page if necessary. Touch the

desired street.

Touch to type in the city

name or select from a previously

registered city. If the city is not

available try the next largest city in

the vicinity.

Select the appropriate Search

Area, then touch OK to conﬁrm the

selection.

step 1step 2

step 3step 4

step 5step 6

412031M1.indd 4 12/20/07 4:59:25 PM

DESTINATION INPUT

BY ADDRESS

Quick Tip - Enter the street name without

preﬁxes such as North or the letter N. The

system will display all of the options available.

If necessary, use the arrow

keys to adjust the position on

the map to put you closer to

your destination. Touch

to conﬁrm the position.

Select the desired Route Preference

by touching the Route Preference icon.

Select the desired Route

Preference(s) for the trip. When

the yellow bar appears, the route

has been selected. Touch to

conﬁrm your selection.

Use or to scroll up or down

one page if necessary. Touch the

desired city.

Touch .

step 7step 8

step 9step 10

step 11

412031M1.indd 5 12/20/07 4:59:26 PM

DESTINATION INPUT - POINTS OF INTEREST (POI)

POINTS OF INTEREST BY NAME

Quick Tip - If the POI isn’t listed in the database verify the

spelling and Search Area for accuracy.

Quick Tip - Touching the button next to the POI name will

display the address and telephone number.

Press the

DEST

panel button

followed by icon to access

points of interest by name.

Touch .

Input the POI name using the letter

keys and then touch .

Use or to scroll up or down

one page if necessary. Touch the

desired selection.

Select the desired Route Preference

and then touch .

step1step 2

step 3step 4

step 5Touch .

step 6

412031M1.indd 6 12/20/07 4:59:27 PM

DESTINATION INPUT - POINTS OF INTEREST (POI)

POINTS OF INTEREST BY CATEGORY

Press the

DEST

panel button

followed by the icon to access

the points of interest by category.

Touch .

Touch the icon to search

for points of interest in the vicinity.

Touch the icon.

Touch the icon

followed by OK and then touch

to see the points of

interest in the vicinity.

step 1step 2

step 3step 4

step 5Use or to scroll up or down

one page if necessary. Touch the

point of interest followed by

and then .

step 6

412031M1.indd 7 12/20/07 4:59:29 PM

DESTINATION INPUT - TELEPHONE NUMBER

BUSINESS OR REGISTERED MEMORY POINTS

Press the

DEST

panel button

followed by the icon.

Input the area code and telephone

number using the number keys

followed by the icon. It is not

necessary to dial “1.”

Select the business or assigned

memory point from the screen.

Select the desired Route Preference

and then touch .

Touch .

step 1step 2

step 3step 4

step 5

412031M1.indd 8 12/20/07 4:59:30 PM

Press the

panel button

followed by the icon to

Touch to input your home

address.

Make sure that you are in the

desired Search Area. Touch the

icon to begin address input.

Input the house number using the

number keys.

Touch and input the street

name using the letter keys. Touch

to see all of the available

options.

Touch or select

from a previously registered city.

step 1step 2

step 3step 4

step 5step 6

Tip - For security reasons, use a point close to

your home instead of your actual home address.

412031M1.indd 8 12/20/07 4:59:30 PM

If necessary use the arrow keys

to adjust the position on the

map. Touch to conﬁrm the

position.

Touch at the top left of the

screen to change the home icon.

Touch the desired icon for

your home.

Touch at the bottom of

the screen. Press the

MAP

VOICE

panel button to complete the

registration of your home.

step 8

step 9step 10

step 11

Touch the desired city.

step 7

412031M1.indd 7 12/20/07 4:59:29 PM
