Toshiba 1600 Series Instructions d'installation

Toshiba International Corporation

Uninterruptible Power Systems

UE3G2L036C61T

Product Specifications

INPUT Voltage 208/240Vac

Voltage Range 168V~264V (+10% to -30%)

Frequency 50/60 Hz Auto Sensing

Synchronization window ± 3Hz

Power Factor Greater than 0.95

THD Current Less than 5% at Full Load

Topology True On-Line, Double Conversion, Input PF Correction

OUTPUT Voltage 208/240/120Vac

Capacity (VA) 3600

Capacity (W) 3100

Voltage Regulation ± 3%

Voltage Distortion Less than 6% THD at Full Non-Linear Load. Less than 3% THD at full Linear Load.

Step Load ± 8 % max from 100% to 0 % or from 0% to 100 % linear load

Rated Current 15A

1600 Series 3.6kVA 208/240V In - 208/240/120V Out Tower

Hardwire Solution - UE3G2L036C61T

Toshiba's 1600EP Series is an on-line Uninterruptible Power Supply (UPS) systems

provide continuous computer-grade ac power in a compact, high performance, and

energy efficient unit. The UPS unit assures safe and reliable operation of critical

office equipment. This can range from word processors and personal computers to

mini-computers and local area networks. All units feature an audible alarm that

sounds if the battery voltage drops below standard during use. This is an additional

aid to help in retaining the valuable office data banks. All units allow for computer

interfacing. This model is a hardwire solution. Customers have the option to

choose from a range of different receptacles panels’ offers by Toshiba. Please refer

to the specification for different line cord and receptacles panels options.

Toshiba International Corporation

Uninterruptible Power Systems

UE3G2L036C61T

Max Peak Current 45A

Overload Capacity 125% for 30 secs, 150% for 10 secs

Crest Factor 3.0 at full load

Frequency 50/60 Hz Auto Sensing

Frequency Regulation ± 0.5Hz/± 1.0Hz/± 1.5Hz (authorized service center selectable only)

Wave Form Sine wave, Zero Transfer Time

Load Power Factor 0.85

Efficiency AC to AC Greater than 83%

Common Mode Noise Less than 0.5 Vrms

BATTERY DC Voltage 216V

Backup Time 10 min (full load) 30 min (half load)

Battery type Enersys NPX-35 Flame Retardant Lead Acid 9Ah/12V Part #: 51896

Number of batteries Pack 3 (Six batteries in each pack)

Recharge time <12 hours to 90%

Interface RS-232, Dry Contact Connectivity, External Battery Connectivity

Input Hardwire Input

Output Hardwire Output

Dimensions WxDxH (mm) 838x254x711

BATTERY Ship Dimensions WxDxH (mm) 965x432x940

Dimensions W x D x H (inch) 33x10x28

Ship Dimensions WxDxH (inch) 38x17x37

Weight kg (lb) 120.2 (265)

Ship Weight kg (lb) 127 (280)

External Matching Battery Cabinet Single - 70 Mins, Double - 140 Mins. Max Two Cabinets. Part #: UE3-BC-0650

Line Cord Options 3.6kVA L6-30 Plug with 8" Line Cord (3 wire) Part #: UE31-6LC-30A

Receptacles Options Four L6-30R, Two 5-15R (Duplex) Part #: UE3-RP-B3

Five 5-20R (Duplex) Part #: UE3-RP-B5

Two L6-30R, Four 5-15R (Duplex) Part #: UE3-RP-B7

Network Interface Card RemotEye II - Part #: RMTI-INT-R25

Environmental Monitoring Device Part #: RMTI-EMD-HT

ENVIRONMENT Operating Ambient Temperature 0 ~ 40oC (32 ~ 104oF)

Recommended Temperature +15oC ~ 25oC

Storage Temperature -20oC ~ 40oC

Humidity 30-90%, Non-Condensing

Audible Noise 50dB (A) maximum @ 1 meter from Front Panel

Toshiba International Corporation

Uninterruptible Power Systems

UE3G2L036C61T

Altitude 3300 ft (1,000 m) above sea level

CONFORMANCE Regulatory Approvals UL, CUL, ISO 9001, NEMA/PEI-1993

WARRANTY Three years on electronics

Two years full replacement on battery (See Toshiba warranty policy for full details)
