Toshiba 1000 Series Manuel utilisateur

True On-Line Double Conversion UPS

Auto-Restart and Cold Start Features

Programmable Load Shed Receptacles

Intelligent Charger with Rapid Charge in Only 4 Hours to 90%

Wide Input Voltage Window

Wide Input Frequency Window for Complete Generator Compatibility

Input Power Factor Greater than 0.97

Output Power Factor 0.70

Digital LCD in Multiple Languages

Optional Network Interface Card - RemotEye II®

Optional Environmental Monitoring Device

1000 VA to 3000 VA UPS

1000 Series

UNINTERRUPTIBLE POWER SYSTEMS

%XTENDED

7ARRANTY

!VAILABLE

Extended

Warranty

Available

&YUFOEFE

Extended

"WBJMBCMF

New Look,

New Panel,

New Color!

1000 Series UPS

UPS ADJUSTABLE SPEED DRIVES MOTORS CONTROLS INSTRUMENTATION PLC

INDUSTRIAL DIVISION

13131 West Little York Road, Houston, Texas 77041

Tel 713/466-0277 Fax 713/466-8773

US 800/231-1412 Canada 800/872-2192 Mexico 01/800/527-1204

www.toshiba.com/ind

Available Through:

*UPS1000Series071110*

Tower US 120 V Model UT1A1A010C6 UT1A1A015C6 UT1A1A020C6 UT1A1A030C6

International 230V Model UT1E1E010C6 UT1E1E015C6 UT1E1E020C6 UT1E1E030C6

Rackmount (2U) US 120 V Model UT1A1A010C6RKB2 UT1A1A015C6RKB2 UT1A1A020C6RKB2 UT1A1A030C6RKB2

International 230 V Model UT1E1E010C6RKB2 UT1E1E015C6RKB2 UT1E1E020C6RKB2 UT1E1E030C6RKB2

Input Voltage 120 VAC (80 to 144 V, +20% to -33%)

Voltage (International) 230 VAC (161 to 276 V, +20% to -30%)

Capacity (VA) 1000 VA 1500 VA 2000 VA 3000 VA

Capacity (W) 700 W 1050 W 1400 W 2100 W

Frequency 50/60 Hz Auto-Sensing

Power Factor Greater than 0.97

Topology True On-Line, Double Conversion, Input PF Correction

Output Voltage 100/110/115/120/127 VAC

Voltage (International) 208/220/230/240 VAC

Frequency 50/60 Hz Auto-Sensing

Wave Form Sine Wave, Zero Transfer Time

Load Power Factor 0.70

Efficiency AC/DC/AC Greater than 86%

Rated Current 8.3 A 12.5 A 16.6 A 25 A

Rated Current (International) 4.3 A 6.5 A 8.7 A 13 A

Overload Capacity 125% for 1 Minute, >130% for 10 Seconds

Crest Factor 3.0 at Full Load

Battery DC Link (Tower & 2U) 36 V / 12 V 9 AH x 3 72 V / 12 V 7.2 AH x 6 72 V / 12 V 9 AH x 6

Backup Time (Tower & 2U) 7 Minutes (Full Load) 6 Minutes (Full Load) 6 Minutes (Full Load) 5 Minutes (Full Load)

Interface RS-232 and USB Standard, Remote Contact, RemotEye II®and EMD Option

Physical Dimensions of Tower (L x W x H) 16.5” x 6.0” x 9.4” 16.7” x 8.9” x 14.2”

Dimensions 2U (L x W x H) 16.7” x 16.9” x 3.5” 25.0” x 16.9” x 3.5”

Weight (Tower/2U) 35.6 lbs/37.6 lbs 37.4 lbs/37.6 lbs 68.4 lbs/69.5 lbs 72.6 lbs/71.5 lbs

Line Cord 5-15P 5-20P L5-30P

Line Cord (International) IEC 320

Receptacles (Tower/2U) NEMA 5-15R (6/6) NEMA 5-15R (12/4)

Receptacles (Tower/2U)

International IEC 320 (4/4) IEC 320 (8/8)

Environment Operating Temperature 0 to 40oC (32 to 104oF)

Altitude 11500 ft (3500 m) Above Sea Level

Warranty Three Years on Electronics

Two Years Full Replacement on Battery (See Toshiba warranty policy for full details.)

2 to 3kVA Tower

1 to 1.5kVA Tower

1 to 3kVA Rackmount 2U (Pictures showed 3kVA)
