Toshiba STOR.E BASICS 2.5" Manuel utilisateur

User’s Manual

STOR.E BASICS 2.5" (6.4cm)

User’s Manual EN-2

STOR.E BASICS 2.5"

User’s Manual

Table of Contents

Introduction................................................................................................. 3

Check the Components .............................................................................. 3

Safety Instructions ...................................................................................... 3

System Requirements ................................................................................ 4

Installing the drive....................................................................................... 4

Connecting the drive to your computer....................................................... 5

Dismount and disconnect the drive ............................................................ 6

Further Advise ............................................................................................ 6

Frequently Asked Questions ...................................................................... 6

Troubleshooting.......................................................................................... 7

TOSHIBA Support ...................................................................................... 8

Regulatory statements................................................................................ 9

User’s Manual EN-3

STOR.E BASICS 2.5"

Introduction

Thank you for choosing our TOSHIBA STOR.E BASICS 2.5" Hard Disk

Drive.

Please read this User’s Manual carefully, as it contains all relevant

information for installation, usage and maintenance of the drive, as well as

security and safety advice.

In case it does not behave as expected, please refer to the “Frequently

Asked Questions” section at the end of this manual.

Check the Components

This User’s Manual is uploaded on the drive itself. We recommend to

backup the User’s Manual onto a CD or your local hard disk drive, directly

after the drive being installed.

Safety Instructions

In order to avoid malfunction or damage of the drive, please carefully follow

the precautions listed below.

■Make sure that you backup all your data on the drive, as Toshiba is not

responsible for data corruption or data loss. Toshiba will not cover any

data recovery cost.

■Do not

■open the enclosure or drive

■disassemble the drive or parts of it

■place liquids near or on the drive, as it may damage the drive, cause

personal injury or may result in an electrical shock or fire

Warranty Card

STOR.E BASICS 2.5”

(including User’s Manual)

USB 3.0 Micro-B Cable Quick Start Guide

and Warranty Leaflet

WARNING

User’s Manual EN-4

STOR.E BASICS 2.5"

■bump, drop or jar the drive

■move the drive while operating, as data damage may happen

■use other connectors than USB bus powered types

■disconnect cables while operating. Please dismount the drive first!

■expose the drive to temperatures outside the range of 5°C – 35°C

while operating, and temperatures of -20°C – 60°C while switched off

■expose the drive to wet or damp conditions

■cover the drive during operation, as it may become overheated

■Immediately disconnect the drive if

■smoke or an unusual smell is coming from the drive enclosure

■water has entered the drive enclosure or if it becomes wet

■an object has entered the drive enclosure

■the cable has been damaged (in such case replace the cable with a

new one)

If the drive behaves not as expected or you have doubts about the

electrical safety, please contact immediately the TOSHIBA hotline or an

authorised reseller!

System Requirements

■Windows®XP / VISTA®/Windows®7

■One free port of USB 3.0 or USB 2.0

Installing the drive

Some information about bus-powered operation and the supplied USB

cable:

■Your drive is bus-powered. Therefore, there is no need to connect an

external power supply as all needed current will be supplied by the

connected USB port(s).

■Passive USB hubs or USB connectors like keyboards, mice or similar

products cannot be used or connected to the drive.

■Make sure that the connectors will be inserted correctly.

■Never use pressure for connecting the cables. Check the polarity before

connecting!

This product can become hot! Avoid prolonged contact to prevent skin

irritation and/or heat injury.

CAUTION

USB 3.0 is backward compatible with USB 2.0.

NOTE

User’s Manual EN-5

STOR.E BASICS 2.5"

Connecting the drive to your

computer

1. With your computer powered on and fully booted up, plug the USB 3.0

Standard-A connector into a USB port of your host system, or an active

USB HUB.

2. Now, plug the USB 3.0 micro-B connector into the corresponding port of

the drive itself.

Immediately,

■the Power/Data indicator light will illuminate

■the drive will power up

■the drive should mount and a new drive icon should appear in “My

Computer”

1. USB 3.0 Micro-B connector 3. USB 3.0 host

backward compatible to USB 2.0

2. USB 3.0 Standard-A connector

2 3

You may need USB 3.0 Express Card Host Controller for your computer if

the computer doesn't have USB 3.0 port. You also can connect the device

to USB 2.0 port of your computer, However the transfer rate will be

downgraded to that of USB 2.0.

NOTE

User’s Manual EN-6

STOR.E BASICS 2.5"

Dismount and disconnect the drive

It is strongly recommended not to unplug the drive by just unplugging the

cable connection as it may be that data is written to the drive at that time.

Such data will be lost and the drive may be damaged physically!

Please follow the steps below for a safe dismount of the drive (Windows 7).

1. Click the “Hardware and Eject Media – icon”

A pop-up message box will appear listing the external devices

connected to your computer.

2. Select the TOSHIBA drive to eject.

After a few seconds, you will get the notification that it is now safe to

remove the device.

3. Click “OK” and you can unplug the drive now.

Cleaning the drive case / enclosure

Before cleaning the drive, make sure that it’s physically disconnected from

the computer. We suggest to use standard products for cleaning it and to

make sure that possible remaining liquid on the surface will be wiped off.

Further Advise

For any further action of normal operation such as renaming the drive,

backup data, or file management, we suggest to read your operation

system user’s manual.

Also for maintenance tasks such as defragmenting and optimisation we

suggest to refer to the operating system user’s manual.

We also strongly suggest having anti-virus software installed to protect your

data against intended damage caused by virus or trojan programs.

Frequently Asked Questions

Q: Do I need to format my drive after installation?

A: No, as the drive is already formatted during the manufacturing process.

Q: Do I need USB drivers for Windows Vista, XP or Windows 7?

A: No, they are already available with your operating system.

Q: Can I boot my system from the drive?

A: No, because Windows does not support booting from external hard disk

drives.

User’s Manual EN-7

STOR.E BASICS 2.5"

Q: Why doesn’t the drive need a fan?

A: The drives are designed to have optimal heat dissipation, and therefore

no fan is required. This results in a near silent operation.

Q: Why is the capacity of my drive (as shown in Windows) lower than the

drives actual stated capacity?

A: This difference can be explained because of the different methods of

calculating the capacity.

Hard drive manufacturers calculate on the decimal system, while the

operating system calculates in the binary system.

Example decimal:

1GB = 1,000MB = 1,000,000KB = 1,000,000,000 bytes

Example binary:

1GB = 1,024MB = 1,048,576KB = 1,073,741,824 bytes

As a result, a 120GB (decimal) hard disk appears in Windows to have

just 112GB (binary).

Q: Can I use my drive to copy an operating system from one computer to

another?

A: No, you must follow the operating system supplier instructions for

installation. A simple copy does not work.

Q: Does Toshiba offer a data recovery services?

A: Yes, Toshiba offers a Data Recovery Service for external hard drives.

Please check our website www.toshiba-europe.com/services for further

information about this service.

Troubleshooting

My computer does not recognize the disk drive at all.

■Make sure all of your connections are secure.

■If your drive is connected via a USB hub, make sure that it has its own

power supply.

■If using an add-on card, make sure it is working properly and update the

software/firmware. If using Windows XP, make sure you have Service

Pack 1 or later.

Is it dangerous if the drive feels warm whilst in operation?

A: This is normal, and therefore not dangerous.

User’s Manual EN-8

STOR.E BASICS 2.5"

The drive gives me a “Device cannot start.”

A: Two possible reasons. It is either a power problem and you should

check the connections, or the drive has a malfunction and requires

service.

I cannot see my drive in “My Computer”, but it does appear in the Device

Manager.

A: Follow these instructions:

1. Right-click “My Computer”.

2. Select “Manage” in the pop-up menu.

3. Select “Disk Management”.

You should see a list of available storage devices.

4. Check whether your drive is listed.

5. Right-click the right hand box and select “Delete Partition” in the

pop-up menu.

6. Right-click the box and select “Create New Partition” in the pop-up

menu.

7. Then select “Primary Partition” in the partition wizard window. Click

next.

8. A drive letter will be displayed, which you can change. Click next.

9. Confirm to format the drive.

As I try to format the drive, I receive the message “Could not complete

format”.

A: This can be caused by formatting the drive with FAT file system.

Try “NTFS” file system. This should solve the problem.

TOSHIBA Support

Need help?

For the latest driver updates,User’s manuals & FAQs please have a look at

the TOSHIBA options & services support page:

computers.toshiba.eu/options-support

Please see computers.toshiba.eu/options-warranty

for the TOSHIBA hotline numbers.

User’s Manual EN-9

STOR.E BASICS 2.5"

Regulatory statements

CE Compliance

Working Environment

The Electromagnetic Compliance (EMC) of this product has been verified

typically for this product category for a so called Residential, Commercial &

Light Industry Environment. Any other working environment has not been

verified by Toshiba and the use of this product in these working

environments is maybe restricted or cannot be recommended. Possible

consequences of the use of this product in non verified working

environments can be: Disturbances of other products or of this product in

the nearby surrounding area with temporarily malfunction or data loss/

corruption as result. Example of non verified working environments and

related advices:

■Industrial environment (e. g. where 3-phase 380V mains is being used

mainly): Danger of disturbances of this product due to possible strong

electromagnetic fields especially near to big machinery or power units.

■Medical environment: The compliance to the Medical Product Directive

has not been verified by Toshiba, therefore this product cannot be used

as a medical product without further verification. The use in usual office

environments e.g. in hospitals should be no problem if there is no

restriction by the responsible administration.

■Automotive environment: Please search the owner instructions of the

related vehicle for advices regarding the use of this product (category).

■Aviation environment: Please follow the instructions of the flight

personnel regarding restrictions of use.

Additional Environments not Related to EMC

■Outdoor use: As a typical home/office equipment this product has no

special resistance against ingress of moisture and is not strong shock

proofed.

■Explosive atmosphere: The use of this product in such special working

environment (Ex) is not allowed.

This product is CE marked in accordance with the

requirements of the applicable EU Directives.

Responsible for CE marking is Toshiba Europe GmbH,

Hammfelddamm 8, 41460 Neuss, Germany. A copy of the

official Declaration of Conformity can be obtained from

following website: http://epps.toshiba-teg.com.

User’s Manual EN-10

STOR.E BASICS 2.5"

Following information is only valid for EU-member

States:

REACH - Compliance Statement

The new European Union (EU) chemical regulation, REACH (Registration,

Evaluation, Authorization and Restriction of Chemicals), entered into force

on 1 June 2007.

Toshiba will meet all REACH requirements and is committed to provide our

customers with information about the chemical substances in our products

according to REACH regulation.

Please consult the following website

www.toshiba-europe.com/computers/info/reach for information about the

presence in our articles of substances included on the candidate list

according to article 59(1) of Regulation (EC) No 1907/2006 (“REACH”) in a

concentration above 0.1 % weight by weight.

Disposal of products

Notices

TOSHIBA reserves the right to make technical changes. TOSHIBA

assumes no liability for damages incurred directly or indirectly from errors,

omissions or discrepancies between this product and the documentation.

The Toshiba name and its logos are registered trademarks of Toshiba.

Other trademarks mentioned or appearing in this document are the

property of their respective owners. Errors and omissions excepted.

The use of the symbol indicates that this product may not be

treated as household waste. By ensuring this product is disposed

of correctly, you will help prevent potential negative consequences

for the environment and human health, which could otherwise be

caused by inappropriate waste handling of this product. For more

detailed information about recycling of this product, please contact

your local city office, your household waste disposal service or the

shop where you purchased the product.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Toshiba Stockage

Toshiba

Toshiba MG03ACA400 Manuel utilisateur

Toshiba

Toshiba MK2529GSG Manuel utilisateur

Toshiba

Toshiba MK2556GSY Manuel utilisateur

Toshiba

Toshiba XM-7002B Manuel utilisateur

Toshiba

Toshiba FlashAir W-04 Instructions et recettes

Toshiba

Toshiba CANVIO AEROMOBILE Manuel utilisateur

Toshiba

Toshiba HDD2189 Manuel utilisateur

Toshiba

Toshiba TRANSMEMORY U2P Manuel utilisateur

Toshiba

Toshiba HDTB105XK3AA Manuel utilisateur

Toshiba

Toshiba MK3255GSX Guide de configuration

Toshiba

Toshiba MK5002MPL Manuel utilisateur

Toshiba

Toshiba CanvioDTQ112 Manuel utilisateur

Toshiba

Toshiba MK3265GSX Manuel utilisateur

Toshiba

Toshiba AL13SEL900 Manuel utilisateur

Toshiba

Toshiba Canvio 640GB Manuel utilisateur

Toshiba

Toshiba QX7 Mode d’emploi

Toshiba

Toshiba CANVIO PREMIUM Manuel utilisateur

Toshiba

Toshiba FlashAir WLSDTHNSWCAE Manuel utilisateur

Toshiba

Toshiba microSDXC UHS-? Manuel utilisateur

Toshiba

Toshiba Canvio Slim Manuel utilisateur

Toshiba

Toshiba FlashAir W-02 Series Manuel utilisateur

Toshiba

Toshiba MK3259GSXP Manuel utilisateur

Toshiba

Toshiba HDD2166 Manuel utilisateur

Toshiba

Toshiba MK4021GAS Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
