Operator’s Manual

IMPORTANT: Read this manual carefully. It contains information about your

safety and the safety of others. Also become familiar with the controls and

their proper use before you operate the product.

International English (GB)

FORM NO. 3321-934

Wheel

Horse



17–44 HXLE

Lawn Tractor

Model No. 71280 – 9900001 & Up

The Toro Company – 1998

Introduction

Thank you for purchasing a Toro product.

All of us at Toro want you to be completely satisfied

with your new product, so feel free to contact your

local Authorized Service Dealer for help with service,

genuine Toro replacement parts, or other information

you may require.

Whenever you contact your Authorized Service

Dealer or the factory, always know the model and

serial numbers of your product. These numbers will

help the Service Dealer or Service Representative

provide exact information about your specific

product. You will find the model and serial number

plate located in a unique place on the product as

shown below

1856

1. Model

and Serial Number Plate

(under the seat)

For your convenience, write the product model and

serial numbers in the space below.

Model No:

Serial No.

Read this manual carefully to learn how to operate

and maintain your product correctly. Reading this

manual will help you and others avoid personal injury

and damage to the product. Although Toro designs,

produces and markets safe, state-of-the-art products,

you are responsible for using the product properly

and safely. You are also responsible for training

persons who you allow to use the product about safe

operation.

The Toro warning system in this manual identifies

potential hazards and has special safety messages that

help you and others avoid personal injury, even death.

DANGER, WARNING and CAUTION are signal

words used to identify the level of hazard. However,

regardless of the hazard, be extremely careful.

DANGER signals an extreme hazard that will cause

serious injury or death if the recommended

precautions are not followed.

WARNING signals a hazard that may cause serious

injury or death if the recommended precautions are

not followed.

CAUTION signals a hazard that may cause minor or

moderate injury if the recommended precautions are

not followed.

Two other words are also used to highlight

information. “Important” calls attention to special

mechanical information and “Note” emphasizes

general information worthy of special attention.

The left and right side of the machine is determined

by sitting on the seat in the normal operator’s

position.

Contents

Page

Safety 2.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Safe Operation Practices for Ride-on

(riding) Rotary Lawnmower Machines 2

. .

Safe Operating Practices 2

. . . . . . . . . . . . . .

Sound Pressure Level 4

. . . . . . . . . . . . . . . . .

Sound Power Level 4

. . . . . . . . . . . . . . . . . .

Vibration Level 4

. . . . . . . . . . . . . . . . . . . . .

Slope Chart 5

. . . . . . . . . . . . . . . . . . . . . . . . .

Symbols Glossary

. . . . . . . . . . . . . . . . . . .

Symbols Glossary

. . . . . . . . . . . . . . . . . . .

Symbols Glossary

. . . . . . . . . . . . . . . . . . .

Gasoline and Oil 10

. . . . . . . . . . . . . . . . . . . . . . . .

Recommended Gasoline

. . . . . . . . . . . . . .

Stabilizer/Conditioner 11

. . . . . . . . . . . . . . . .

Filling the Fuel Tank 11

. . . . . . . . . . . . . . . . .

Check Engine Oil Level 11

. . . . . . . . . . . . . . .

Operation 12

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Think Safety First 12

. . . . . . . . . . . . . . . . . . .

Controls 12

. . . . . . . . . . . . . . . . . . . . . . . . . . .

Parking Brake 12

. . . . . . . . . . . . . . . . . . . . . . .

Positioning the Seat 13

. . . . . . . . . . . . . . . . . .

Headlights 13

. . . . . . . . . . . . . . . . . . . . . . . . .

Using the Blade Control (PTO) 13

. . . . . . . . .

Setting the Height-of-Cut 14

. . . . . . . . . . . . . .

Page

Starting and Stopping the Engine 14

. . . . . . .

The Safety Interlock System 16

. . . . . . . . . . .

Operating–in–Reverse 16

. . . . . . . . . . . . . . . .

Testing the Safety System 17

. . . . . . . . . . . . .

Pushing the Machine by Hand 18

. . . . . . . . . .

Driving Forward or Backward 19

. . . . . . . . . .

Stopping the Machine 19

. . . . . . . . . . . . . . . .

Tips for Mowing Grass 20

. . . . . . . . . . . . . . .

Maintenance 21

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Service Interval Chart 21

. . . . . . . . . . . . . . . .

Greasing and Lubrication 22

. . . . . . . . . . . . . .

Tire Pressure 22

. . . . . . . . . . . . . . . . . . . . . . . .

Brake 23

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Wiring Diagram 24

. . . . . . . . . . . . . . . . . . . . .

Fuse 25

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Headlights 25

. . . . . . . . . . . . . . . . . . . . . . . . .

Battery 26

. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Spark Plug 28

. . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Tank 29

. . . . . . . . . . . . . . . . . . . . . . . . . .

Fuel Filter 30

. . . . . . . . . . . . . . . . . . . . . . . . . .

Air Cleaner 30

. . . . . . . . . . . . . . . . . . . . . . . . .

Engine Oil 32

. . . . . . . . . . . . . . . . . . . . . . . . .

Cleaning and Storage 35

. . . . . . . . . . . . . . . . .

Troubleshooting 36

. . . . . . . . . . . . . . . . . . . . . . . . .

Safety

Safe

Operation Practices for

Ride-on (riding) Rotary

Lawnmower Machines

This machine meets or exceeds European

Standards in effect at the time of production.

However, improper use or maintenance by the

operator or owner can result in injury. To reduce

the potential for injury, comply with these safety

instructions and always pay attention to the safety

alert symbol, which means CAUTION,

WARNING, or DANGER—“personal safety

instruction.” Failure to comply with the

instruction may result in personal injury or death.

Safe

Operating Practices

This product is capable of amputating hands and feet

and throwing objects. Always follow all safety

instructions to avoid serious injury or death.

Training

1. Read the instructions carefully. Be familiar with

the controls and the proper use of the equipment.

2. Never allow children or people unfamiliar with

these instructions to use the lawnmower. Local

regulations may restrict the age of the operator.

3. Never mow while people, especially children, or

pets are nearby.

4. Keep in mind that the operator or user is

responsible for accidents or hazards occurring to

other people or their property.

5. Do not carry passengers.

6. All drivers should seek and obtain professional

and practical instruction. Such instruction should

emphasize:

•the need for care and concentration when

working with ride-on machines;

•control of a ride-on machine sliding on a

slope will not be regained by the application

of the brake. The main reasons for loss of

control are:

insufficient wheel grip;

being driven too fast;

inadequate braking;

the type of machine is unsuitable for its

task;

lack of awareness of the effects of

ground conditions, especially slopes;

incorrect hitching and load distribution.

Preparation

1. While mowing, always wear substantial

footwear and long trousers. Do not operate the

equipment when barefoot or wearing open

sandals.

2. Thoroughly inspect the area where the

equipment is to be used and remove all objects

which may be thrown by the machine.

3. WARNING – Fuel is highly flammable.

•Store fuel in containers specifically

designed for this purpose.

•Refuel outdoors only and do not smoke

while refuelling.

•Add fuel before starting the engine. Never

remove the cap of the fuel tank or add fuel

while the engine is running or when the

engine is hot.

Safety

•If fuel is spilled, do not attempt to start the

engine but move the machine away from

the are of spillage and avoid creating any

source of ignition until petrol vapors have

dissipated.

•Replace all fuel tanks and container caps

securely.

4. Replace faulty silencers.

5. Before using, always visually inspect to see that

the blades, blade bolts and cutter assembly are

not worn or damaged. Replace worn or damaged

blades and bolts in sets to preserve balance.

6. On multi–bladed machines, take care as rotating

one blade can cause other blades to rotate.

Operation

1. Do not operate the engine in a confined space

where dangerous carbon monoxide fumes can

collect.

2. Mow only in daylight or in good artificial light.

3. Before attempting to start the engine, disengage

all blade attachment clutches and shift into

neutral.

4. Use care when pulling loads or using heavy

equipment.

•Use only approved drawbar hitch points.

•Limit loads to those you can safely control.

•Do not turn sharply. Use care when

reversing.

•Use counterweight(s) or wheel weights

when suggested in the instruction

handbook.

5. Watch out for traffic when crossing or near

roadways.

6. Stop the blades before crossing surfaces other

than grass.

7. When using any attachments, never direct

discharge of material toward bystanders nor

allow anyone near the machine while in

operation.

8. Never operate the lawnmower with damaged

guards or without safety protective devices in

place.

9. Do not change the engine governor settings or

overspeed the engine. Operating the engine at

excessive speeds may increase the hazard of

personal injury.

10. Before leaving the operator’

s position:

•disengage the power take-off and lower the

attachments;

•change into neutral and set the parking

brake;

•stop the engine and remove the ignition and

“Key Choice” keys.

11. Disengage drive to attachments, stop the engine,

and disconnect the spark plug wire(s) or remove

the ignition key

•before cleaning blockages or unclogging

chute;

•before checking, cleaning or working on the

lawnmower;

•after striking a foreign object. Inspect the

lawnmower for damage and make repairs

before restarting and operating the

equipment;

•if the machine starts to vibrate abnormally

(check immediately).

12. Disengage drive to attachments when

transporting or not in use.

13. Stop the engine and disengage drive to

attachment

•before refuelling;

•before removing the grass catcher;

Safety

•before making height adjustment unless

adjustment can be made from the operator’s

position.

14. Reduce the throttle setting during engine run-out

and, if the engine is provided with a shut-off

valve, turn the fuel off at the conclusion of

mowing.

Slope Operation

1. For operation on slopes:

•Never mow side hills over 5_

•Never mow uphill over 10_

•Never mow downhill over 15_

2. Remember there is no such thing as a “safe”

slope. Travel on grass slopes requires particular

care. To guard against overturning:

•do not stop or start suddenly when going up

or downhill;

•

engage clutch slowly

, always keep machine

in gear, especially when travelling

downhill;

•machine speeds should be kept low on

slopes and during tight turns;

•stay alert for bumps and hollows and other

hidden hazards;

•never mow across the face of the slope,

unless the lawnmower is designed for this

purpose.

Maintenance and storage

1. Keep all nuts, bolts and screws tight to be sure

the equipment is in safe working condition.

2. Never store the equipment with fuel in the tank

inside a building where fumes may reach an

open flame or spark.

3. Allow the engine to cool before storing in any

enclosure.

4. To reduce the fire hazard, keep the engine,

silencer, battery compartment and petrol storage

area free of grass, leaves, or excessive grease.

5. Check the grass catcher frequently for wear or

deterioration.

6. Replace worn or damaged parts for safety.

7. If the fuel tank has to be drained, this should be

done outdoors.

8. On multi-bladed machines, take care as rotating

one blade can cause other blades to rotate.

9. When machine is to be parked, stored or left

unattended, lower the cutting means unless a

positive mechanical lock is used.

Sound

Pressure Level

This unit has an equivalent continuous A-weighted

sound pressure at the operator ear of: 87 dB(A), based

on measurements of identical machines per Directive

84/538/EEC and amendments.

Sound

Power Level

This unit has a sound power level of: 100 Lwa, based

on measurements of identical machines per

procedures outlined in Directive 84/538/EEC and

amendments.

Vibration

Level

This unit has a maximum hand-arm vibration level of

10.0 m/s2and whole body vibration level of 0.4 m/s2,

based on measurements of identical machines per EN

1033 and EN 1032.

Safety

Slope

Chart

Read all safety instructions on pages 2–8.

Safety

Symbols

Glossary

Read operator

’

s manual

Rotating blade can cut off

toes or fingers. Stay clear

Thrown or flying objects–

Whole body exposure

Thrown or flying objects–

Rotary side-mounted mower

Dismemberment–Mower

in rearward motion

Do not open or

remove safety shields

while engine is running

Stay a safe distance

from the machine

Machine rollover

side hill

up hill

down hill

Stay a safe distance

from the mower

Machine rollover

Safety alert symbol

of blade as long as engine

is running

Keep deflector shield in place

Consult Technical Manual for

proper service procedures

Safety alert symbol

Keep children a safe distance

from machine

Severing toes or foot–

mower blade

Severing fingers or hand–

mower blade

Operating in reverse not

allowed unless deactivated

by ”Key Choice” key

Safety

Symbols Glossary

Cutting element–

basic symbol

Cutting element–

height adjustment

Cutting unit-raised

Cutting unit–lower

Crushing of fingers

or hands–Force applied

from side

Kickback or upward

motion–Stored energy

Shut off engine & remove key

before performing maintenance

or repair work

Riding on this machine is allowed

only on a passenger seat & only

if the driver

’s view is not hindered

Severing of hand–

Rotating knives

Severing of foot–

Rotating knives

Cutting or entanglement

of foot–Rotating auger

Severing of fingers or hand–

impeller blade

Stay a safe distance

from the snowthrower

Keep a safe distance from

snowthrower

ractors must be equipped

with 45kg rear wheel weight

with this attachment installed

Machine rollover

ROPS snowthrower

Neutral

First gear

Second gear

Third gear up to

Reverse

maximum # of

forward gears

High

Low

Machine travel direction–

combined

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Toro Tondeuse à gazon

Toro

Toro GrandStand Multi Force 78597 Manuel utilisateur

Toro

Toro 74162 Manuel utilisateur

Toro

Toro 30551 Manuel utilisateur

Toro

Toro 74226 Z255 Z Master Manuel utilisateur

Toro

Toro GrandStand 74549 Manuel utilisateur

Toro

Toro GrandStand HDX Manuel utilisateur

Toro

Toro Groundsmaster 300 Series Manuel utilisateur

Toro

Toro Recyler 20373 Manuel utilisateur

Toro

Toro TimeCutter 77404 Manuel utilisateur

Toro

Toro 04472 Manuel utilisateur

Toro

Toro 30243 Groundsmaster 223D Manuel utilisateur

Toro

Toro 20959 Manuel utilisateur

Toro

Toro 74234 Manuel utilisateur

Toro

Toro RT600 Manuel utilisateur

Toro

Toro Super Recycler 20039 Manuel utilisateur

Toro

Toro Recycler 22170 Manuel utilisateur

Toro

Toro Reelmaster 5610-D Manuel utilisateur

Toro

Toro Z500 Series Z Master Manuel

Toro

Toro 74191 Manuel utilisateur

Toro

Toro 30651 Manuel utilisateur

Toro

Toro LX420 13AX60RG744 Manuel utilisateur

Toro

Toro 2656 Manuel utilisateur

Toro

Toro TITAN ZX 5400 Manuel utilisateur

Toro

Toro Flex-Force Power System 21356 Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuel d'utilisation

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur

Yard-Man

Yard-Man 3700-0 Manuel utilisateur
