Toro 2024 Guide de démarrage rapide

FormNo.3413-630RevB

2024DirectionalDrill

ModelNo.23800—SerialNo.313000501andUp

ModelNo.23800A—SerialNo.315000001andUp

ModelNo.23800C—SerialNo.315000001andUp

ModelNo.23800TE—SerialNo.315000001andUp

ModelNo.23800W—SerialNo.315000001andUp

SoftwareGuide

Readthisinformationcarefullytolearnhowtooperate

andmaintainyourproductproperlyandtoavoid

injuryandproductdamage.Youareresponsiblefor

operatingtheproductproperlyandsafely.Readyour

Operator’sManualformoreinformation.

Monitor

HomeScreenOptions

MainInformationScreen

Thisistherstscreenthatappearsaftertheinitial

splashscreen.T onavigatebetweenscreens,usethe

leftandrightarrows.

g207713

Figure1

1.Drillspeed(rpm)4.Enginespeed(rpm)

2.Rotarytorque5.Drilling-uidowrate

3.Thrustforce6.Drilling-uidpressure

g207712

Figure2

1.Pipefunctions5.Enginetemperaturegauge

2.Fuelgauge6.Enginedroop

3.Limitsettingoptions7.Horn

4.Selectpiperow8.Thrustforce,drillspeed

(rpm),orrotarytorque

adjustment

Pushbutton1toswitchbetweenthepipefunctions:

pullpipe,pushpipe,neutral.

Pushbutton5toswitchbetweenthrustforce,drill

speed(rpm),androtarytorque.

Usebuttons6and7tosetlimitsforthedrillspeed

(rpm),rotarytorque,andthrustforce.

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3413-630*B

g210057

Figure3

1.Pullpipe4.Thrustforce

2.Pushpipe5.Drillspeed(rpm)

3.Rotarytorque

SmartTouch™HomeScreen

SmartTouchmodeallowstheoperatortoloadand

unloadpipesfromtherodboxwithlessjoystick

operationtoreduceoperatorfatigue.

UsetheCarriageSettingsScreen(page12)toturn

SmartTouchmodeonandoff.

Note:ThePush/PullIconwillhaveagreen

backgroundwhenSmartT ouchmodeisonanda

ribbonwillappearatthebottomofthescreenshowing

asequenceofthesteps.

Important:NeverswitchbetweenPush/Pull

modesduringthechosenoperation.Useneutral

(manual)modetoswitchbetweenPush/Pull;refer

toCarriageSettingsScreen(page12)toturn

SmartTouchmodeoff.

PullingPipeinSmartTouchMode

StarttheSmartT ouchmodewiththecamassemblyin

thehomeposition(row3ofthepipebox).

Important:Ensurethatyouholdthelowersection

ofthecamrockerswitch,ontheleftjoystick,

completelydownuntiltheactioniscompletein

eachstep(Figure4).

g210060

Figure4

Holdtheuppersectionofthecamrockerswitch,

ontheleftjoystick,completelydownuntilall

actionsarecompletetogotothepreviousstepin

thesequence(Figure5).

g210061

Figure5

1.Pushbutton1toselectthepullpipeoption

(Figure6).

2.Pushbuttons2and3toselecttherowwhere

youwanttoplacethepipe(Figure6).

g210062

Figure6

1.Pullpipe2.Selectpiperow

3.Holdthelowersectionoftherockerswitch

(Figure8)untiltheelevatorlowers,thecam

assemblyrotatestowardtheoperatorstation,

andthearmsfullyextend(Figure9).

g210518

Figure7

g210462

Figure8

g210517

Figure9

4.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure10).

g210520

Figure10

5.Breakthepipeconnection;refertoRemoving

DrillPipesintheOperator’sManual.

6.Holdtheupperbuttononthejoysticktogripthe

pipe(Figure11andFigure12)andreleasethe

button.

g210533

Figure11

g210519

Figure12

7.Holdthelowersectionoftherockerswitch

(Figure14)untilthearmsfullyretract(Figure

15).

g210522

Figure13

g210462

Figure14

g210521

Figure15

8.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure16).

g210524

Figure16

9.Holdthelowersectionoftherockerswitch

(Figure17)untilthecamassemblyrotatestothe

selectedrowunderthepipebox(Figure18).

g210462

Figure17

g210523

Figure18

10.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure19).

g210526

Figure19

11.Holdthelowersectionoftherockerswitch

(Figure20)untiltheelevatorputsthepipeback

inthepipeboxandthecamrotatestothehome

position(Figure21).

g210462

Figure20

g210525

Figure21

12.Releasetherockerswitchtostartthepull-pipe

processagain.

PushingPipeinSmartTouchMode

StarttheSmartT ouchmodewiththecamassemblyin

thehomeposition(row3ofthepipebox).

Important:Ensurethatyouholdthelowersection

ofthecamrockerswitch,ontheleftjoystick,

completelydownuntiltheactioniscompletein

eachstep(Figure22).

g210060

Figure22

Holdtheuppersectionofthecamrockerswitch,

ontheleftjoystick,completelydownuntilall

actionsarecompletetogotothepreviousstepin

thesequence(Figure23).

g210061

Figure23

1.Pushbutton1toselectpushpipe(Figure24).

2.Pushbuttons2and3toselecttherowwhere

youwanttogetthepipe(Figure24).

g210063

Figure24

1.Pushpipe2.Selectpiperow

3.Holdthelowersectionoftherockerswitch

(Figure26)untilthecamassemblyrotatesto

theselectedrowandthepipelowersintothe

opening(Figure27).

g210464

Figure25

g210462

Figure26

g210463

Figure27

4.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure28).

g210466

Figure28

5.Holdthelowersectionoftherockerswitch

(Figure29)untilthecamassemblyfullyrotates

forwardtotherackandtheelevatorsliftthe

remainingpipeintothepipebox(Figure30).

g210462

Figure29

g210465

Figure30

6.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure31).

g210467

Figure31

7.Holdthelowersectionoftherockerswitch

(Figure32)untilthearmsextend(Figure33).

g210462

Figure32

g210528

Figure33

8.Releasetherockerswitchtoproceedtothenext

stepinthesequence(Figure34).

g210530

Figure34

9.Makethepipeconnection;refertoAddingDrill

PipesintheOperator’sManual.

10.Holdthelowerbuttononthejoystick(Figure

35)toreleasethepipe(Figure36)andrelease

thebutton.

g210527

Figure35

g210529

Figure36

11.Holdthelowersectionoftherockerswitch

(Figure38)untilthearmsretractandthecam

assemblyreturnstothehomeposition(row3)

(Figure39).

g210532

Figure37

g210462

Figure38

g210531

Figure39

12.Releasetherockerswitchtostartthepush-pipe

processagain.Thecamassemblywillgoto

therowpickedinstep2ofPullingPipein

SmartTouchMode(page2).

HoursScreenOptions

MachineHoursScreen

Toaccessthisscreenpushbutton1ontheHours

screen.

Thisscreenshowstheoperatinghoursofthe

machine.Machine1cannotbechanged.Machine

2canbereset.

Button5showsthetotalenginehours.

Button6showsenginehoursthatcanberesetby

pushingbutton8.

g207716

Figure40

DrillingFluid(Mud)UseScreen

Toaccessthisscreenpushbutton2ontheHours

screen.

Thisscreenshowsthedrillinguid(mud)useofthe

machine.T otaldrillinguid(mud)cannotbechanged.

Dailydrillinguid(mud)canbereset.

g204519

Figure41

1.Resetbutton

LubricationandMaintenanceScreens

Toaccessthisscreen,pushbutton3ontheHours

screen.

Thesescreensprovidetheuserwiththedaily

maintenanceschedulesandthe50-hour,250-hour,

500-hour,and1,000-hourincrements.

Toresetthemaintenanceinterval,navigatetothe

MaintenanceandParametersOptionsScreen(page

13).

Pushbuttons5through8forthecorresponding

serviceintervalandthenpushtheOKbutton3times.

Pushthefollowingbuttonstoattainthesubsequent

maintenanceschedule:

•Button3—10-hour/Dailymaintenanceschedule

(Figure42)

•Button5—50-hourmaintenanceschedule(Figure

43)

•Button6—250-hourmaintenanceschedule(Figure

44)

•Button7—500-hourmaintenanceschedule(Figure

45)

•Button8—1,000-hourmaintenanceschedule

(Figure46)

g034777

Figure42
