Topfield TF 5000 CI Manuel utilisateur

TOPFIELD

TF 5000 CI

TF 5100 CI

User Guide

Digital Satellite Receiver

Common Interface

Contents iii

Contents

1 Introduction 1

1.1 Features ............................... 1

1.2 Controlling the digital receiver .................. 2

1.2.1 The front panel ....................... 3

1.2.2 The remote control ..................... 4

1.3 What is common interface? .................... 6

2 Setup 7

2.1 Unpacking .............................. 7

2.2 Safety precautions ......................... 7

2.3 Rear panel connections ....................... 9

2.4 Connecting up your digital receiver ............... 10

2.4.1 Connecting the antenna .................. 10

2.4.2 Connecting to your television .............. 11

2.4.3 Connecting to your video cassette recorder ....... 13

2.5 Switching on for the ﬁrst time ................... 13

2.5.1 Inserting batteries in the remote control ......... 13

2.5.2 Powering on and checking picture ............ 14

iv Contents

3 Preference Settings 15

3.1 Language settings .......................... 15

3.2 Video and audio settings ...................... 16

3.2.1 Television standard .................... 16

3.2.2 Colour model ........................ 17

3.2.3 Video cassette recorder .................. 17

3.2.4 Television aspect ratio ................... 18

3.2.5 Sound mode ........................ 18

3.2.6 Radio frequency output .................. 19

3.3 Local time setting .......................... 19

3.4 Parental control ........................... 20

3.5 Adjusting the on-screen display .................. 22

4 Service Search 24

4.1 Searching broadcasting services .................. 24

4.1.1 Conﬁguring LNB settings ................. 24

4.1.2 Conﬁguring DiSEqC 1.2 settings ............. 27

4.1.3 Conﬁguring USALS settings ............... 28

4.1.4 Searching services ..................... 29

4.2 Editing the transponder list .................... 32

4.3 Resetting to factory settings .................... 33

4.4 Resetting to installer settings ................... 33

5 Daily Usage 35

5.1 Volume control ........................... 35

5.2 Watching television ......................... 35

5.2.1 The services list ....................... 35

5.2.2 The favourite services list ................. 37

5.2.3 Viewing programme information ............ 38

5.2.4 Selecting audio tracks ................... 39

Contents v

5.2.5 Selecting subtitle tracks .................. 39

5.2.6 Viewing teletext ...................... 39

5.3 Viewing electronic programme guide .............. 39

5.4 Watching multifeed programme ................. 41

5.5 Making timer events ........................ 41

6 Listing Services 43

6.1 Editing the services list ....................... 43

6.2 Editing the favourite list ...................... 45

6.3 How to use on-screen keyboard .................. 47

6.4 Transferring receiver data ..................... 47

7 Firmware Update 49

7.1 Checking the ﬁrmware information ............... 49

7.2 From your computer via RS-232 port ............... 51

7.3 From another digital receiver via RS-232 port .......... 52

Index 53

Chapter 1

Introduction

The TF 5000 CI/TF 5100 CI digital receiver is fully compliant

with the international Digital Video Broadcasting (DVB) stan-

dard, and can receive digital broadcasts. For its operation you

need an antenna, which must be installed appropriately.

NOTE

In general we equate a channel with a frequency. Unlike ana-

logue broadcasts, however, digital broadcasts are not all as-

signed to their own frequencies; instead, multiple television

broadcasts are transmitted through a single frequency. The fre-

quency in digital broadcasting is usually called transponder. To

reduce confusion in this manual, the word

service

is preferably

used than

channel

as a term to indicate one television or radio

broadcast.

1.1 Features

The TF 5000 CI/TF 5100 CI digital receiver has the following

features:

•

Supports DiSEqC 1.0, DiSEqC 1.1, DiSEqC 1.2 and US-

ALS.

2 Introduction

• Can store up to 5000 television and radio services.

• You can edit the services list.

• You can create favourite lists of your favourite services.

•

You can view information about the current television or

radio programme.

•

Has an electronic programme guide that provides an

overview of scheduled programmes.

•

You can update the ﬁrmware of the digital receiver to the

latest version, provided by the manufacturer.

1.2 Controlling the digital receiver

The digital receiver can be operated with the remote control

and the buttons on the front panel.

NOTE

When the digital receiver is off but plugged into a wall outlet,

we say that it is in standby mode; on the other hand, when it is

on, it is in operation mode. Even when you are not using the

digital receiver, you should keep it plugged into a wall outlet

to be in standby mode so that it can run timer events at any

time.

1.2 Controlling the digital receiver 3

1.2.1 The front panel

The front panel of the digital receiver has buttons to control the

digital receiver, and speciﬁc lamps and a display to indicate its

status. The following indicates what they mean.

STANDBY

CHANNEL

VOLUME

TV/STB

REMOTE

STANDBY

button switches the digital receiver between

standby mode and operation mode.

CHANNEL

buttons switch to previous or next service.

They are also used to navigate in menus and interactive

screens.

VOLUME

buttons decrease or increase the volume.

They are also used to change values for menu options.

TV/STB

lamp lights up while your video recorder operates

instead of the digital receiver. See

3.2.3 for more

details.

REMOTE

lamp lights up whenever you press a button on

the remote control.

STANDBY

lamp lights up while the digital receiver is in

standby mode.

Front display

displays the current time in standby mode,

and displays the current service in operation mode.

4 Introduction

Pull the right edge of the front panel to open the ﬂap. You have

to insert your subscription card into the front slot to watch pay

services.

1.2.2 The remote control

SAT N/P



button switches the digital receiver

between standby mode and operation

mode.



switches the output of the TV

SCART socket between the digital re-

ceiver and the device connected to the

VCR SCART socket. See

3.2.3 for

more details.



Numeric buttons are used to enter a

service number for service change or to

specify values for menu options.



switches between the current ser-

vice and the previously viewed one.









displays the main menu. It is

also used to return to the previous

menu from a submenu.









displays the services list. See

5.2.1

for more details. It is also used to select

a menu item.









V−









V+

buttons decrease or increase

the volume. They are also used to

change values for menu options.









P−









P+

buttons switch to previous or next service.

They are also used to navigate in menus and interactive

screens.









EXIT is used to exit the current screen.
