THORLABS TSP01 Manuel utilisateur

Environmental Measurement

TSP01

Operation Manual

2018

Version:

Date: 1.4

21-Nov-2018

Foreword

Contents 3

1 General Information 4

41.1 Ordering Codes and Accessories

2 Getting Started 5

52.1 Parts List

52.2 Requirements

52.2.1 Hardware Requirements 52.2.2 Software Requirements

62.3 Software Installation

3 Operating Instructions 7

73.1 Quick Start 113.2 Detailed GUI Description

113.2.1 Controls

123.2.2 Settings

133.2.3 Tab Measurement 133.2.4 Tab Table

143.2.5 Tab Graph

143.2.6 Graph Display Option Menus

153.2.7 Logging Panel 163.2.8 Save Data

163.2.9 Load Data

173.2.10 Export Settings

173.2.11 Import Settings 183.2.12 Device Information

4 Write Your Own Application 19

194.1 WYOA for TSP01 RevB Sensors

194.1.1 Driver Installation and Location for TSP01 RevB Sensors 214.1.2 Changing the Driver for TSP01 RevB

224.2 WYOA for Previous-Revision Sensors

234.2.1 Driver Installation and Location for Previous-Revision TSP01 sensors

254.2.2 Command Reference 254.2.2.1 IEEE488.2 Common Commands

264.2.2.2 SCPI Command Reference

5 Maintenance and Service 29

295.1 Version Information

6 Troubleshooting 30

7 Appendix 31

317.1 Technical Data

327.2 List of Acronyms

337.3 Safety

347.4 Certifications and Compliances 357.5 Warranty

357.6 Copyright and Exclusion of Reliability

367.7 Thorlabs Worldwide Contacts

We aim to develop and produce the best solutions for your

applications in the field of optical measurement techniques. To help

us to live up to your expectations and constantly improve our

products, we need your ideas and suggestions. We and our

international partners are looking forward to hearing from you.

Thorlabs GmbH

Warning

Sections marked by this symbol explain dangers that might result in

personal injury or death. Always read the associated information

carefully before performing the indicated procedure.

Please read this advice carefully!

This manual also contains "NOTES" and "HINTS" written in this form.

Attention

Paragraphs preceded by this symbol explain hazards that could

damage the instrument and the connected equipment or may cause

loss of data.

Note

TSP01

1 General Information

The TSP01 is a device of the size of a USB thumb drive that can be plugged to any USB port

for reading up to three different temperature values and relative humidity.

The combined humidity and temperature sensor is embedded into the USB stick, a second

NTC temperature sensor TSP-TH is included and can be connected to the housing. A third op-

tional temperature sensor can be plugged to the USB housing. External temperature sensors

can be an additional Thorlabs TSP-TH or any other NTC type sensor. The Thorlabs TSP01 Ap-

plication software allows to enter individual NTC parameters, such as R0 (reference resist-

ance), T0 (reference temperature) and the B coefficient.

The TSP01 can be run and data can be displayed in the Thorlabs TSP01 Application software

as a separate GUI. Alternatively, the TSP01 can be run from the Thorlabs' Beam Profiler Soft-

ware.

Further, users have the choice to write a separate application or use a third party GUI. For this,

please see the chapter Write-Your-Own-Application .

Attention

Please find all safety information and warnings concerning this product in the chapter Safety

in the Appendix.

1.1 Ordering Codes and Accessories

TSP01

Temperature and Humidity USB Sensor Probe with external temperature

sensor

TSP-TH

External temperature probe for TSP01

2 Getting Started

2.1 Parts List

Inspect the shipping container for damage.

If the shipping container seems to be damaged, keep it until you have inspected the contents

for completeness and tested the TSP01 mechanically and electrically.

Verify that you have received the following items within the package:

1. TSP01: Temperature and Humidity USB Sensor Probe

2. TSP-TH: External Temperature Probe for TSP01

3. USB Extension Cable, 1.8 m

4. Quick Reference

2.2 Requirements

The TSP01 is controlled and data read out is monitored through software on a connected PC.

Users have the choice to either use the Thorlabs TSP01 Application software as a separate

GUI or to run the TSP01 from other Thorlabs' software such as the Beam Profiler Software.

Users are also free to write a separate application or use a third party GUI. For this, please see

the chapter Write-Your-Own-Application .

The following are the requirements for the PC to be used for remote operation of the TSP01.

2.2.1 Hardware Requirements

CPU

1 GHz or higher

RAM

512 MB or more

Graphic Card

at least 32 MB memory

Graphic Resolution

min. 1024 x 768

Hard Disc

min. 100 MB of available disk space (32 bit)

min. 100 MB of available disk space (64 bit)

Interface

free USB 2.0 port, USB cable according the USB 2.0

specification

2.2.2 Software Requirements

The TSP01 software is compatible with the following operating systems:

·Windows®XP (32-bit) SP3

·Windows®Vista (32-bit, 64-bit)

·Windows®7 (32-bit, 64-bit)

·Windows®8.1 (32-bit, 64-bit)

·Windows®10 (32-bit, 64-bit)

Note

As of 12/2018, Thorlabs introduces the TSP01 revision B. These revised TSP01 devices are

labeled "RevB" on the underside and use an instrument driver that no longer requires NI-

VISA™. For operation of the previous version of the TSP01 without the RevB label, NI-VISA™

(version 5.1 or higher) is required for the driver.

TSP01

The NI-VISA™engine can be installed from the following sources:

·The software CD shipped with previous-revision TSP01 sensors (not labeled RevB). The in-

staller includes NI-VISA™.

·The National Instruments' website www.ni.com

2.3 Software Installation

Please download the TSP01 Application from the software tab on the TSP01 website.

Attention

Do not connect the TSP01 to the PC during software installation! Please make sure that the in-

stallation is carried out completely, including the reboot requests.

·Save the ZIP file to your computer and unpack the archive.

·Double click the setup.exe to install Shield Wizard.

·Read and accept the End-user License Agreement.

·Note the Readme Information during the installation process:

"V 2.0: - Temperature sensor TSP01 RevB supported (includes a new library TLTSPB)

- NIVISA Runtime removed from installer. "

NI-VISA™ has been removed from the installer since it is not required for TSP01 sensors

labeled "RevB". TSP01 sensors without the RevB label will require the installation of NI-VISA™

software.

3 Operating Instructions

After installation of the software connect the TSP01 to a free USB 2.0 port.

Note

The TSP01 should always be positioned away from heat and humidity sources that are not of

interest for the measurement to prevent background. For this, the 1.8 m USB cable is supplied

to position the TSP01 away from the PC/HUB.

The operating system recognizes a USB device and automatically installs the device drivers.

Start the GUI from the desktop icon.

For detailed information on how to use the TSP01 Application software, please see

the chapter Detailed GUI Description .

3.1 Quick Start

This chapter gives a short overview on how to use the TSP01 Application. A detailed descrip-

tion of the GUI can be found in the chapter Detailed GUI Description .

At the first connect, you will be prompted to select the pre-

ferred unit for temperature display. Confirm your choice

with "OK". The software now automatically connects to the

TSP01 and the actual temperature and relative humidity

are displayed as measured on the internal sensor. If an ex-

ternal sensor is connected, it will be recognized and en-

abled automatically, and the temperature of the external

sensor is now displayed.

TSP01

Tab Measurement

The Measurement tab displays the actual mea-

surement values of all enabled sensors in numeri-

cal values and within a bar.

The bar indication range can be set individually in

the Settings menu. Additionally, two limits can

be defined for each bar that control the bar color

(blue - green - red) depending on the actual value

with respect to these two limits.

Logging Panel

·Logging Control: Choose between: manual start/stop, timed log-

ging or logging of a number of samples.

·Measurement Interval: Set the logging interval (time between two

measurements) between 1 and 10000 seconds.

·Averaging: Averaging unchecked: A single measured value per

selected measurement interval will be logged.

Averaging checked: All values that are measured each second

within the selected measurement interval will be averaged and

only this average value will be logged. Only one single value will

be logged for both options.

·Time Axis Scale: Three selections are available: time in seconds,

time in hh:mm:ss and time stamp (date and time). The complete

time stamp will be displayed only in the Table Tab.

·Start / Stop Logging: This is a toggle button to start / stop log-

ging.

·Results: In this pane logging statistics are displayed.
