Q - S e r i e s V i d e o M o d u l e s P r o d u c t M a n u a l , R e v . H
Page 3
Table of Contents
PREFACE 4
About Thinklogical 4
Note and Warning Symbols 5
1. INTRODUCTION 6
1.1 Product Overvie 6
2. SYSTEM FEATURES 7
2.1 General System Features 7
2.2 The Q-Series Chassis Line 7
3. THE Q-SERIES VIDEO SYSTEM 8
3.1. Types of Connectors 8
3.1.1. Fiber Cable 8
3.1.2. Transmitter 8
3.1.3. Receiver 8
4. THE Q-SERIES VIDEO MODULES 12
4.1. Single-Link and Dual-Link DVI & RGB/DVI Modules 12
4.2. Velocity Q-Series HDCP Compliant Video Modules 17
4.2.1. Velocity Q-Series HDCP Compliant Video Module Part Numbers 18
4.2.2. Velocity Q-Series HDCP Compliant Video Module Front Panel Vie s 18
4.3. Fiber Connections to the Q-Series Video Modules 19
4.3.1. Single Fiber Operation, Single-Link Video 19
4.3.2. Dual Fiber Operation, Single-Link Video 19
4.3.3. Three and Four Fiber Operation, Dual Video 19
4.3.4. T o and Four Fiber Operation, Redundant Video 19
4.3.5. T o and Three Fiber Operation, Dual-Link Video 20
4.4. Supplied Cables 20
4.5. Dry Contact Alarm 22
4.6. Q-Series Video Module Audio Specifications 22
4.7. Q-Series Video Modules Technical Specifications 23
4.8. Status Indicator LEDs 24
4.9. Firm are and FPGA Updates 25
5. REGULATORY SAFETY COMPLIANCE 26
5.1 Safety Requirements 26
Symbols Found on the Product 26
Regulatory Compliance 26
North America 26
Australia & Ne Zealand 26
European Union 26
Standards ith hich Our Products Comply 26
5.2 Supplementary Information 27
Product Serial Number 27
Connection to the Product 28
6. HOW TO CONTACT US 28
6.1 Customer Support 28
Website 28
Email 28
Telephone 29
Fax 29
6.2 Product Support 29
6.2.1 Warranty 29
6.2.2 Return Authorization 30
Our Address 30
APPENDIX A: Quick Start Guides 31
APPENDIX B: VQM-10 AV+ Supported Analog Resolutions 35
APPENDIX C: VQM-10 AV+ LCD Menu Options (Q-4300 Q-2300 Chassis) 36
APPENDIX D: RJ45 to DB9 Adapter Pin-outs 43
APPENDIX E: EDID and DDC for Standard and HDCP Modules 45
