THCS252

20-bits GPIO or high speed Bus signal Transceiver

General description

The THCS252 integrates Serializer and Deserializer

onto a single chip, which supports general purpose

input and output (GPIO) signals through two pairs of

differential signal.

GPIO sampling clock is selectable from external

reference clock or internal oscillator clock.

The 8B10B encoding and decoding adopted by

THCS252 is easy to connect to optical / wireless

communication devices with high robustness and DC

balanced signal.

The built-in adaptive equalizer enables flexible cable

selection.

Application

The THCS252 can applicable to any systems which

have many control signals between PCBs, for

example Multi-function printers, Amusement

machines, Factory Automation and TVs.

Features

Support up to 20-bits GPIO

Not required to input GPIO sampling clock in

internal oscillator clock mode

Full duplex communication by two pairs of

differential signal

Output buffer open-drain or push-pull selectable

Support up to 8-bits low speed GPIO in low

power Standby mode

Integrated adaptive equalizer for long or lossy

media

8B10B encoding and decoding

Configurable digital noise filter

Error detection and indication

External reference clock frequency:

15-100MHz

Spread Spectrum Clock Generator to reduce EMI

Operating single power supply voltage: 1.7 V -

3.6 V

Wide range IO voltage: 1.7V - 3.6V

Operating ambient temperature: -40°C to 85°C

Block diagram

LDO

GPIO

D0/D19

...

D19/D0

REFOUT

TXP

TXN RXP

RXN

RXP TXN

TXP

GPIO

D19/D0

...

D0/D19

THCS252 (Master mode) THCS252 (Slave mode)

LVCMOS I/O

LDO

OSC SSCG PLL

(Serializer)

Formatter

(Deserializer)

LVCMOS I/O

OSCSSCG

PLL

(Serializer)

Formatter

(Deserializer)

REFIN

REFEN

THCS252_Rev.2.01_E

2/31

SC: E

Contents page

General description..................................................................................................................................................1

Application..............................................................................................................................................................1

Features ...................................................................................................................................................................1

Block diagram.........................................................................................................................................................1

1. Pin configuration.............................................................................................................................................3

2. Pin description.................................................................................................................................................4

3. Absolute maximum ratings..............................................................................................................................7

4. Recommended operating conditions ...............................................................................................................7

5. Electrical characteristics..................................................................................................................................8

5.1. Current consumption...............................................................................................................................8

5.2. LVCMOS/Analog input DC specifications .............................................................................................9

5.3. LVCMOS AC characteristics.................................................................................................................10

5.4. CML DC characteristics........................................................................................................................13

5.5. CMLAC characteristics ........................................................................................................................13

6. CML Line Eye diagrams ...............................................................................................................................18

6.1. CML output Eye diagrams.....................................................................................................................18

6.2. CML input Eye diagrams ......................................................................................................................19

7. Function.........................................................................................................................................................20

7.1. Functional overview..............................................................................................................................20

7.2. Power supply.........................................................................................................................................20

7.2.1. Internal regulator output/input function (CAPOUT, CAPINA, CAPINP) ....................................20

7.3. Operating mode.....................................................................................................................................20

7.4. Transmission mode................................................................................................................................21

7.4.1. Full duplex Bi-directional transmission mode...............................................................................21

7.4.2. Unidirectional transmission mode.................................................................................................22

7.5. IO configuration ....................................................................................................................................23

7.5.1. Input and Output digital noise filter ..............................................................................................23

7.5.2. LVCMOS output buffer type configuration...................................................................................23

7.5.3. 5V tolerant I/O...............................................................................................................................23

7.6. Sampling clock configuration................................................................................................................24

7.6.1. Sampling clock selection...............................................................................................................24

7.6.2. Spread Spectrum Clock Generator (SSCG) and REFIN frequency...............................................26

7.7. Error detection and indication...............................................................................................................27

7.8. Standby mode........................................................................................................................................28

8. Package..........................................................................................................................................................29

Notices and Requests.............................................................................................................................................30

THCS252_Rev.2.01_E

3/31

SC: E

1. Pin configuration

OBUF

FILTSEL1

D17 / D2

D16 / D3

D15 / D4

VDD

STANDBY

DIRSEL1

DIRSEL0

REFEN

D19 / D0

D18 / D1

28 27 26 25

TEST2

34 33 32 31 30 2936 35

37 QFN-48 24 D14 / D5

AVDD 38 23 D13 / D6

CAPOUT 39 22 D12 / D7

21 D11 / D8

RXN 41 20 REFIN / REFOUT/ OSCSEL1

RXP 40

19 VDD

TXN 43 18 D10 / D9

CAPINA 42

17 D9 / D10

CAPINP 45 16 D8 / D11

TXP 44

15 D7 / D12

TEST1 47 14 D6 / D13

INT / LOCKN 46

13 D5 / D14

1 2 3 4

RESETN 48

11 12

RESERVED

MSSEL

RF / OSCSEL0

READY

5 6 7 8 9 10

D4 / D15

VDD

SSEN

FILTSEL0

D0 / D19

D1 / D18

D2 / D17

D3 / D16

(TOP VIEW)

49EXPGND

THCS252_Rev.2.01_E

4/31

SC: E

2. Pin description

Name

No.

Type

Description

Refere

nce

TXP 44 CO High-speed CML signal output -

TXN 43 CO High-speed CML signal output -

RXP 40 CI High-speed CML signal input -

RXN 41 CI High-speed CML signal input -

RESETN 48 IL Chip reset

0: Chip reset

1: Chip operation

STANDBY 34 IL Standby mode entry

0:Normal mode operation

1:Standby mode operation

MSSEL 2 IL Master/Slave mode select

0: Master mode

1: Slave mode

FILTSEL1 35 IL digital noise filter select Table 5

DIRSEL0 32 IL DIRSEL0: GPIO direction select Table 2

Table 4

DIRSEL1 33 IL DIRSEL1: GPIO direction select Table 2

Table 4

OBUF 36 IL Output buffer type select

0: open-drain

1: push-pull

REFEN 31 IL

Data sampling clock select (Master mode)

0: Internal oscillator clock

1: External reference clock

CDR clock output enable (Slave mode)

0: REFOUT pin is Hi-Z state

1: CDR clock output from REFOUT pin

REFIN/

REFOUT/

OSCSEL1 20 B

REFIN: (Master mode) External Reference

clock input -

REFOUT: (Slave mode) CDR clock output -

OSCSEL1: (Master mode) Oscillator clock

frequency select Table 9

OSCSEL1: (Slave mode) Hi-Z -

RF/

OSCSEL0 3 IL

RF:(Master mode) input clock edge select Table 10

Figure 14

RF: (Slave mode) output clock edge select

OSCSEL0:(Master mode) Oscillator clock

frequency select Table 9

OSCSEL0: (Slave mode) Set to Low

D0/

D19 7 BT D0(Master mode): Data input -

D19(Slave mode): Data output -

THCS252_Rev.2.01_E

5/31

SC: E

Name

No.

Type

Description

Refere

nce

D1/

D18 8 BT D1(Master mode): Data input -

D18(Slave mode): Data output -

D2/

D17 9 BT D2(Master mode): Data input -

D17(Slave mode): Data output -

D3/

D16 10 BT D3(Master mode): Data input -

D16(Slave mode): Data output -

D4/

D15 11 B D4(Master mode): Data input -

D15(Slave mode): Data output -

D5/

D14 13 B D5(Master mode): Data input -

D14(Slave mode): Data output -

D6/

D13 14 B D6(Master mode): Data input -

D13(Slave mode): Data output -

D7/

D12 15 B D7(Master mode): Data input -

D12(Slave mode): Data output -

D8/

D11 16 B D8(Master mode): Data input -

D11(Slave mode): Data output -

D9/

D10 17 B D9(Master mode): Data input -

D10(Slave mode): Data output -

D10/

D9 18 B D10(Master mode): Data input/output -

D9(Slave mode): Data input/output -

D11/

D8 21 B D11(Master mode): Data input/output -

D8(Slave mode): Data input/output -

D12/

D7 22 B D12(Master mode): Data input/output -

D7(Slave mode): Data input/output -

D13/

D6 23 B D13(Master mode): Data input/output -

D6(Slave mode): Data input/output -

D14/

D5 24 B D14(Master mode): Data input/output -

D5(Slave mode): Data input/output -

D15/

D4 26 B D15(Master mode): Data input/output -

D4(Slave mode): Data input/output -

D16/

D3 27 BT D16(Master mode): Data input/output -

D3(Slave mode): Data input/output -

D17/

D2 28 BT D17(Master mode): Data input/output -

D2(Slave mode): Data output -

D18/

D1 29 BT D18(Master mode): Data output -

D1(Slave mode): Data input -

D19/

D0 30 BT D19(Master mode): Data input/output -

D0(Slave mode): Data input/output -

SSEN 5 BL

SSEN(Master mode): SSCG PLL enable

0: SSCG PLL is disabled

1: SSCG PLL is enabled

SSEN(Slave mode): Set to Low

FILTSEL0 6 BL FILTSEL0: digital noise filter select Table 5

INT/

LOCKN 46 BO INT: Interrupt output when READY=1

0: Error occurred

1(pull-up): No Error

THCS252_Rev.2.01_E

6/31

SC: E

Name

No.

Type

Description

Refere

nce

LOCKN(Master mode): Lock detect input

0: Lock state

1(pull-up): Unlock state

LOCKN(Slave mode): Lock detect output

0: Lock state

1(pull-up): Unlock state

READY 4 B CML Link communication status

0: Unlock state

1: Lock state

TEST1 47 IL TEST1 shall be tied to Ground. -

TEST2 37 AI TEST2 shall be tied to Ground. -

CAPOUT 39 PWR Decoupling capacitor Pin, 1.2V output. Figure 9

CAPINA 42 PWR 1.2V Analog power supply input. Figure 9

CAPINP 45 PWR 1.2V Analog power supply input. Figure 9

VDD 12

25 PWR 1.7-3.6V Digital power supply input for

LVCMOS I/O. -

AVDD 38 PWR 1.7-3.6V Analog power supply input for on-

chip regulator. Figure 9

EXPGND 49 GND Exposed Pad Ground. Must be tied to the PCB

ground plane through an array of vias. -

Pin Type definition

Analog Buffer

CO : CML Output buffer

CI : CML Input buffer

AI : Analog Input buffer

LVCMOS buffer

IL : Low speed schmitt trigger LVCMOS Input buffer

B : LVCMOS Bi-directional buffer

BO : Open-drain LVCMOS Bi-directional buffer

BL : Low speed 5V tolerant schmitt trigger LVCMOS Bi-directional buffer

BT : Low speed 5V tolerant LVCMOS Bi-directional buffer

Power/Ground

PWR : Power supply

GND : Ground

THCS252_Rev.2.01_E

7/31

SC: E

3. Absolute maximum ratings

Parameter

Min

Typ

Max

Unit

Supply voltage(VDD,AVDD) -0.3 - 4.0 V

LVCMOS input voltage -0.3 - VDD+0.3 V

LVCMOS output voltage -0.3 - VDD+0.3 V

5V tolerant Bi-directional buffer input voltage -0.3 - VDD+2.5 V

5V tolerant Bi-directional buffer output voltage -0.3 - VDD+2.5 V

Open-drain output voltage -0.3 - 4.0 V

CML receiver input voltage -0.3 - CAPINA+0.3 V

CML transmitter output voltage -0.3 - CAPINP+0.3 V

Output current -50 - 50 mA

Storage temperature -55 - 125 °C

Junction temperature - - 125 °C

Reflow peak temperature/time - - 260/10 °C/sec

Theta-ja (Junction-to-Ambient) 30.8 [*1] °C/W

Psi-jt (Junction-to-Top of Package) 2.8 [*1] °C/W

Maximum power dissipation @+25°C 3.2 [*1] W

“Absolute maximum ratings” are those values beyond which the safety of the device cannot be guaranteed.

They are not meant to imply that the device should be operated at these limits. The tables of “Electrical

Characteristics” specify conditions for device operation.

*1: Thermal parameters are not guaranteed value. This value assists board and system level designers

4. Recommended operating conditions

Parameter

Min

Typ

Max

Unit

Supply voltage(VDD,AVDD) 1.7 - 3.6 V

Operating ambient temperature -40 - 85 °C

VDD andAVDD supply voltage shall be the same voltage.

THCS252_Rev.2.01_E

8/31

SC: E

5. Electrical characteristics

5.1. Current consumption

Symbol

Parameter

Type

Condition

Min

Typ

Max

Unit

Idd_w1 Normal mode current

Low current use case [*1] PWR AVDD=3.3V

VDD=3.3V - 80 - mA

Idd_w2 Normal mode current

High current use case [*2] PWR AVDD=3.3V

VDD=3.3V - 300 - mA

Idda_stby Standby mode current PWR AVDD=3.3V

VDD=3.3V - 4 - mA

Idda_slp Sleep mode current PWR AVDD=3.3V

VDD=3.3V - 3 - mA

Idda_rst Reset mode current PWR AVDD=3.3V

VDD=3.3V - 3 - mA

PWR : Power supply

*1: Master mode of Unidirectional transmission mode, 20-bits GPIO input, 100MHz of REFIN clock

*2: Slave mode of Unidirectional transmission mode, 20-bits GPIO output, 100MHz of REFOUT clock

THCS252_Rev.2.01_E

9/31

SC: E

5.2. LVCMOS/Analog input DC specifications

Symbol

Parameter

Type

Condition

Min

Typ

Max

Unit

VIH High level input voltage B,BT,

1.7V≦VDD<2.0V 0.65 VDD - VDD V

2.0V≦VDD<3.0V 0.70 VDD - VDD V

3.0V≦VDD≦3.6V 2.0 - VDD V

IL,BL 1.7V≦VDD≦3.6V 0.70 VDD - VDD V

VIL Low level input voltage

B,BT,

1.7V≦VDD<2.0V 0 - 0.35 VDD V

2.0V≦VDD<3.0V 0 - 0.30 VDD V

3.0V≦VDD≦3.6V 0 - 0.8 V

IL,BL 1.7V≦VDD≦3.6V 0 - 0.30 VDD V

AI 1.7V≦VDD≦3.6V 0 - 0.15 VDD V

VOH High level output voltage B,BT,

1.7V≦VDD<2.0V

IOH=-2mA VDD -

0.30 - VDD V

2.0V≦VDD≦3.6V

IOH=-4mA VDD -

0.45 - VDD V

VOL Low level output voltage [*1]

B,BT,

1.7V≦VDD<2.0V

IOL=2mA 0 - 0.30 V

2.0V≦VDD≦3.6V

IOL=4mA 0 - 0.45 V

BO 1.7V≦VDD≦3.6V

IOL=2mA 0 - 0.27 V

IIH Input leak current high IL VIN=VDD -10 - 10 uA

IIL Input leak current low IL VIN=0V -10 - 10 uA

IOZH Output leak current high in

Hi-Z state B,BT,

BL,BO VIN=VDD -10 - 10 uA

IOZL Output leak current low in

Hi-Z state B,BT,

BL,BO VIN=0V -10 - 10 uA

AI : Analog Input buffer

IL : Low speed schmitt trigger LVCMOS Input buffer

B : LVCMOS Bi-directional buffer

BO : Open-drain LVCMOS Bi-directional buffer

BL : Low speed 5V tolerant schmitt trigger LVCMOS Bi-directional buffer

BT : Low speed 5V tolerant LVCMOS Bi-directional buffer

THCS252_Rev.2.01_E

10/31

SC: E

5.3. LVCMOSAC characteristics

Symbol

Parameter

Condition

Min

Typ

Max

Unit

tRSN RESETN low time - 3 - - us

tTCIP REFIN period - 10 - 66.6 ns

tTCH REFIN high time - 0.35 tTCIP 0.5 tTCIP 0.65 tTCIP ns

tTCL REFIN low time - 0.35 tTCIP 0.5 tTCIP 0.65 tTCIP ns

tTS Data input setup to REFIN

Pin type:

B 1.7V≦VDD≦3.6V 2.0 - - ns

Pin type:

1.7V≦VDD<2.25V 25 - - ns

2.25V≦VDD≦2.75V 2.5 - - ns

2.75V<VDD≦3.6V 2.0 - - ns

tTH Data input hold to REFIN - 1.0 - - ns

tTPD Power on to RESETN high

delay - 0 - - ns

tOSC Internal oscillator clock

period

OSCSEL1=0

OSCSEL0=0 41.67 50 62.5 ns

OSCSEL1=1

OSCSEL0=0 20.84 25 31.25 ns

OSCSEL1=1

OSCSEL0=1 10.42 12.5 15.62 ns

tDCP Data sampling clock period REFEN=0 - tOSC - ns

REFEN=1 - tTCIP - ns

tFLTCK Noise filter clock period REFEN=0 10.42 12.5 15.62 ns

REFEN=1 - tTCIP - ns

tTCD Input data to output data

delay (Master mode to

Slave mode)

SSEN=0

FILTSEL1=0

FILTSEL0=0 12 tDCP - 25 tDCP ns

FILTSEL1=0

FILTSEL0=1 19 tDCP - 35 tDCP ns

FILTSEL1=1

FILTSEL0=0 24 tDCP - 43 tDCP ns

FILTSEL1=1

FILTSEL0=1 34 tDCP - 59 tDCP ns

SSEN=1

FILTSEL1=0

FILTSEL0=0 57 tDCP - 110 tDCP ns

FILTSEL1=0

FILTSEL0=1 64 tDCP - 120 tDCP ns

FILTSEL1=1

FILTSEL0=0 69 tDCP - 128 tDCP ns

FILTSEL1=1

FILTSEL0=1 79 tDCP - 144 tDCP ns

tRCP REFOUT period - - tDCP - ns

tRCH REFOUT high time - - 0.5 tDCP - ns

tRCL REFOUT low time - - 0.5 tDCP - ns

tDOUT Data output period - - tDCP - ns

tRS Data output setup to

REFOUT - 0.45 tDCP

- 0.675 - - ns

tRH Data output hold to

REFOUT - 0.45 tDCP

- 2.175 - - ns

tRCD Input data to output data

delay (Slave mode to

Master mode)

FILTSEL1=0

FILTSEL0=0 12 tDCP - 25 tDCP ns

FILTSEL1=0

FILTSEL0=1 19 tDCP - 35 tDCP ns

FILTSEL1=1

FILTSEL0=0 24 tDCP - 43 tDCP ns

FILTSEL1=1

FILTSEL0=1 34 tDCP - 59 tDCP ns

tRRDY RESETN high to READY

high delay - 0 - 10 ms

Table des matières

Autres manuels THine Émetteur-récepteur

THine

THine THCS251 Manuel utilisateur

THine

THine CEL THCV231 Manuel utilisateur

Manuels Émetteur-récepteur populaires d'autres marques

Yaesu

Yaesu FT-7B Manuel utilisateur

Kenwood

Kenwood ProTalk TK-3201 Manuel utilisateur

Texas Instruments

Texas Instruments TLK10232 Manuel utilisateur

Mizuho

Mizuho MX-2 Guide produit

Kenwood

Kenwood TK-3180 Manuel d'utilisation et d'entretien

Blitz

Blitz MJ-398U Manuel utilisateur

Utilicom

Utilicom LongRanger 2050 Manuel utilisateur

Standart

Standart HX290UKA Manuel utilisateur

Altronix

Altronix Pace1PTM Manuel utilisateur

Kirisun

Kirisun PT2208 Manuel utilisateur

ELECRAFT

ELECRAFT KX2 Manuel utilisateur

Zodiac

Zodiac K3 Manuel utilisateur

Assa Abloy

Assa Abloy SecureComm HKC GSM-WIFI U Manuel utilisateur

Kenwood

Kenwood TK-2217 Manuel utilisateur

Siemens

Siemens PSO 4000 Manuel utilisateur

Kenwood

Kenwood TS-590SG Manuel utilisateur

Midland

Midland G8E-BT Manuel

ComNav

ComNav Mariner X2 Manuel utilisateur
