Thermador - SMW272 Specifications

SMW272

27" Triple Oven with Professional Handles

Appearance

Flat Flush Frame

Sens-A-Touch™ Electronic Control In Glass

Oven Capacity - Cubic Feet, Upper or Single Oven 2.1

Oven Capacity - Cubic Feet, Lower 3.6

Performance

4 Cooksmart™ Combination Cooking Models -

Microwave Power Levels 10

Warming Drawer

Dual Element Bake Lower Oven

Variable Broil Lower Oven

Third Element Convection Lower Oven

Convection - Roast Lower Oven

Convection - Broil -

Sabbath Mode

Temperature Probe -

Timed & Delay Timed Mode

Variable 140 - 210 (Degrees F)

450 Watt Element Concealed Below Drawer

Convenience

Self-Cleaning Oven(s)

Interior Venting

Motorized Door Lock(s)

Minute Timers 2

Child Lock-Out Care and Use Manual

Rack Positions 6

Number of Racks 3

Dual-Level Halogen Lights A/M

1/2 Rack for Stacking Items Included

Ball Bearing Drawer Glides

Concealed "Moist or Dry" Vent Control

"ON" Light Visible With Drawer Closed

General Information

Microwave Wattage 1100

Broil/Bake Wattage 3600/2600

Warming Drawer Wattage 450

Third Element Wattage 2750

Dual-Rated 120/208-240 Volts, 3-Wire, 60HZ

AMPS 30

Approximate Shipping Weight (LBS.) 250

Thermador - SMW272 Specifications

Dimensions

Overall Dimensions - A*† 55 3/4

Overall Dimensions - B*† 26 3/4

Overall Dimensions - C* 23 7/8

Overall Dimensions - D* ** 22

Upper / Single Oven Interior Dimensions - Height -

Upper / Single Oven Interior Dimensions - Width -

Upper / Single Oven Interior Dimensions - Depth -

Lower Oven Interior Dimensions - Height 16 1/4

Lower Oven Interior Dimensions - Width 22

Lower Oven Interior Dimensions - Depth 17 1/2

Custom Panel Dimensions - Height -

Custom Panel Dimensions - Depth -

Overall Dimensions

Sens-A-Touch is a trademark of Touch Sensor Technologies

Notes: All height, width and depth dimensions are shown in inches. For a detailed listing of approved cooktop

models for this installation please refer to oven installation instructions.

*Please refer to installation instructions prior to making cutout.

**Largest door.

†Add 1/16" height and 1/8" width for stainless steel models (S-Series only.)

All models are UL approved. Select 30" models are CUL approved for sales in Canada. For immediate critical

installation dimensions by fax, use your fax handset and call (775) 833-3600. Use code #8030 for a directory

of Thermador products.
