Theben 201 0 090 Manuel utilisateur
1103023505 / 05.2010 © Theben HTS
Art. Nr. 201 0 090
Presence detector
compact passage
Bedienungsanleitung 2
Notice d´utilisation 22
Installation manual 42
Manual de instrucciones 62
Istruzioni per l′uso 82
Gebruikershandleiding 102
Bruksanvisning 122
Bruksanvisning 142
Käyttöohje 162
Betjeningsvejledning 182
DK
D
F
GB
E
I
NL
S
N
FIN
4242
English Installation manual
Presence detector
compact passage
Table of contents
1.Safety ..................................................43
2. Function and performance characteristics. . . . . . . . . . . . . . . . . . . . . . . 44
3.Fittingandconnection......................................45
4.Start-up.................................................47
5.Additionalwiringexamples ..................................51
6.Testmode...............................................54
7. Technical specications.....................................55
8.Warrantydeclaration....................................... 57
9.Troubleshooting...........................................58
4343
GB
Thank you for purchasing an Theben HTS presence detector and putting
your trust in us.
1. Safety
DANGER !
Any work on electrical systems must exclusively be carried out by qualied
electricians or instructed persons under the direction and supervision of a
qualied electrician in accordance with the relevant electrotechnical rules!
Any national safety regulations regarding the manipulation of electrical sys-
tems must be observed! The voltage supply must be disconnected prior
to installation!
CAUTION !
The device is maintenance-free. The warranty terminates if the device is
opened or entered with any kind of object.
Designated use
The presence detector is solely intended for the purpose contractually spe-
cied between the manufacturer and the user. Any other or extended use
has to be regarded as not complying with the designated use. The manufac-
turer is not liable for any resulting damage.
4444
2. Function and performance characteristics
The presence detector compact passage is used for a comfortable and efci-
ent light as well as HVAC control within a corridor.
The switching contact A «Light» switches on the lighting in case of
presence and insufcient brightness, and off in case of absence or sufcient
brightness. In addition, the lighting can be switched manually by means of
push-buttons.
●Switching contact «Light»: relays 230V
●Manual control by push-button or switch
●Semi or fully automatic operation
●Push-button function: room / corridor
● Suitable for uorescent lamps, compact uorescent lamps, halogen,
incandescent lamps and LEDs
●Pulse function for staircase lighting timer
The switching contact B «Presence» controls heating, ventilation and air-
conditioning systems. The contact closes in case of presence, a switch-on
delay allows a delayed switching on. The contact can also be used for room
surveillance purposes. Using reduced sensitivity, it only responds on very
distinct movements.
●Switching contact «Presence», potential-free relay
●Adjustable switch-on delay and switch-off delay
●Surveillance function
4545
GB
3. Fitting and connection
3.1 Presence detection
The ideal mounting height is 2,0 - 3,5m. The sensitivity of the detector de-
creases with increasing mounting height. The detection ranges of multiple
detectors should overlap in their fringe zone. Ensure the horizontal installa-
tion of the detector.
M´height radial (r) tangential (t)
2,0m 56 m216,0m x 3,5m ± 1m 105 m230,0m x 3,5m ± 1m
2,5m 72 m218,0m x 4,0m ± 1m 120 m230,0m x 4,0m ± 1m
3,0m 90 m220,0m x 4,5m ± 1m 135 m230,0m x 4,5m ± 1m
3,5m 100 m220,0m x 5,0m ± 1m 150 m230,0m x 5,0m ± 1m
Because of the virtually horizontal detection of compact passage to both
directions, the detection range of tangential (t) movements of persons is
different to the range of radial (r) movements towards the detector.
Detection range (mounting height 3,0m)
t
15m 12 10 8 6 4 2 0 2 4 6 8 10 12 15
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
2
1
0
1
2
r
Lux
0
3
2
1
4646
3.2 Light measurement
The detector measures articial light
and daylight reected directly bene-
ath the detector (beam width approx.
± 30°).
The mounting location is used as the
reference for the lighting levels.
With indirect lighting, the articial light at the detector’s mounting location
should not exceed 2000 Lux (Brightness value > 2000 Lux).
3.3 Connection
A concealed housing should be
used for ush-mounted tting of the
presence detector compact passage.
A surface frame is available for sur-
face mounting.
NL
S A
P
B2B1
compact
power
Master
N
L
Presence (e.g. HVAC)
4747
GB
4. Start-up
The detectors are supplied ready for operation with a factory setting of recom-
mended standard values.
The QuickSet plus service remote control for starting-up the system is opti-
onally available. With the remote control all potentiometer values can be set
from a distance.
4.1 Settings for switching contact A «Light»
Potentiometer
Brightness threshold “LUX” Scale
●Transfer zones (no working area) approx. 2
●Bright transfer zones approx. 4
●Deactivation of brightness measurement “on”
Depending on the installation location,
natural light intensity, furniture, reec-
tion characteristics of the room and the
furniture it may be necessary to correct
the settings by 1-2 steps on the scale.
For ease of setting up, we recommend
the service remote control QuickSet plus.
4848
Switch-off delay time
●Transfer areas approx. 5min.
●In the range between 2 - 15min the switch-off delay varies according to
its self-learning behavior. The set values <2min or >15min remain xed.
●«Pulse»: staircase lighting timer control (0.5s “on” / 10s “off”)
DIP switch
Fully / Semi-automatic mode
●«auto»: Fully automatic mode. The lighting is switched on automatically.
●«man»: Semi-automatic mode. The lighting must be switched on manually.
Push-button function: room / corridor
●«room»: Manual switching on/off possible.
●«corridor»: Detector is used as staircase lighting timer.
No manual switching-off possible.
Push-button/Switch control
●Optional push-button or switch operation.
●Multiple push-buttons on one control input possible.
●Use illuminated push-buttons with PEN conductor connection only.
4949
GB
4.2 Settings for switching output B «Presence»
Switch-off delay time for presence
●The pre-set values remain unchanged (no self-learning effect).
Switch-on delay time for presence
●In case of presence, the contact does not close before the set switch-on
delay has elapsed.
●0 = Contact closes immediately in case of presence.
●Room surveillance function; the contact closes only in case of
distinct movements (effective protection against false alarms).
10s
5050
4.3 Behaviour on switching on
Whenever the sensor module is plugged onto the power module or the unit
is energised, the detector goes through tree phases which are indicated by
an LED.
1. Start-up phase (30sec)
● LED ashes every second, both contacts are closed
(light and presence on)
●In case of absence, both contacts open after 30sec.
2. Service phase (10min)
●The «Light» contact reacts instantaneously on brightness in order to
check the brightness threshold.
● If the brightness is insufcient the lighting is switched on (LED on),and if
the brightness is sufcient the lighting is switched off (LED off).
●During the service phase, switching of the lighting occurs fully automati-
cally (no semi-automatic mode).
●The service phase terminates earlier by actuating the push-button or the
remote control.
3. Operation
●The detector is ready for operation (LED off).
