Brief instructions en

testo 330-1 , -2

Flue gas analyser

These brief instructions provide an overview over the most important functions of the

product. Before using the product you should absolutely read and follow the operating

instructions! This document describes the products testo 330-1 LL and testo 330-2 LL

with the instrument setting Country version | Great Britain.

Device connections

➀Sensor socket: Connect the sensor before

switching the measuring instrument on or, after

changing a sensor, switch the instrument off and

on again.

➁Flue gas socket: It is possible to change a probe /

sensor even while the measuring instrument is

switched on.

➂Mains unit socket

➃Pressure socket

Replacing the probe module

1Press the key on top of the probe handle and

remove the probe module.

2Plug in the new probe module and engage it in

place.

Emptying the condensate trap

The condensate consists of a weak mix of acids. Avoid contact with the skin. Make

sure that the condensate does not run over the housing.

Do not drain the condensate trap

while the flue gas pump is running!

1Hold the instrument with the condensate outlet

pointing up.

2Open the condensate outlet on the condensate

trap: Pull out approx. 5mm against the stop (➀).

➀➁

➃

➂

➀

3Let the condensate run out into a sink (➁).

4Dab off any remaining drops on the condensate

outlet with a cloth.

5Close the condensate outlet.

The condensate outlet must be completely

closed (marking), as otherwise measuring errors

could be caused by infiltrated air.

Key functions

Switching the measuring instrument on/off: .

Back, cancel function: .

Save data to the clipboard: ➝ (only available when saving to clip-

board is possible).

Saving data ➝ (only available when saving to clipboard is

possible). Data in the clipboard will also be saved.

Printing data: (only available when printing is possible, the printer to be used must

be enabled). Data in the clipboard will also be printed out.

Calling up the function: Select function: , and confirm selection: .

Enter value

List field:

1Select value (numerical value, unit): , and set: , .

2Confirm input: .

Input editor:

1Select value (character): , , , .

2Accept value: .

3Save values: .

Enter smoke pump no./smoke numbers/oil derivative/heat carrier temperature

1➝Measurements ➝➝Smoke number/WTT➝.

Steps 2to 4are only valid if the chosen fuel is an oil.

2 Smoke pump number ➝➝Enter pump number ➝.

3 Smoke number 1 ➝➝Enter value ➝.

4Perform step 3for further smoke numbers and the oil derivative accordingly.

5 Heat carrier temperature ➝➝Enter value ➝.

6Save values: ➝.

SaveOptions

Edit

Edit

Edit OK

OK

OK

OKOK

Next

OK

OK

OK

SaveOptions

ClipboardOptions

➁

Perform draught measurement

A flue gas probe must be connected.

The pressure socket of the instrument must be free (i.e. unpressurized, not closed).

1➝Measurements ➝➝Draught measurement ➝.

2Start measurement: .

- Draught zeroing (5s).

3Position the flue gas probe in the hot spot (area of the highest flue gas temperature).

The display showing the maximum measured flue gas temperature (FT max) helps

when positioning the probe.

- The reading is displayed.

4End measurement: .

5Save values to the clipboard: ➝or .

Perform flue gas measurement

1➝Measurements ➝➝Flue gas ➝.

- Possibly: Gas zeroing (30 s).

2Select fuel ➝.

3Start measurement: .

4End measurement: .

5Save values to the clipboard: ➝or .

Creating a new location

1➝Folder/Location ➝.

2➝ New location ➝.

3 Select location ➝.

4Enter values ➝.

5Perform steps 3and 4for further criteria accordingly.

6.

Enabling location

1➝Folder/Location ➝.

2Select location ➝.

- The location is activated and the menu Measurements is opened.

OK OK

Finished

Next

Edit

Options

SaveClipboardOptions

Clipboard

OK

OK

OK

OK

OK

OK OK

SaveOptions
