Tenda TEH1026G Manuel utilisateur

24+2G Gigabit Ethernet Switch

BRIEF INTRODUCTION PRODUCT FEATURES

Wired

Model No.:TEH1026G

All For Better NetworkAll For Better Network

All For Better Network

The TEH1026G is a hybrid switch offering 24 10/100M ports and

two 10/100/1,000M ports. It supports auto MDI/MDIX and store-

and-forward switching, and has an 8.8Gbps backplane bandwidth.

The TEH1026G is a specially designed solution for keeping traffic

moving in medium-sized network groups that will be accessing

one or two servers heavily via the Gigabit ports, like in some school

or enterprise deployments. Administrators might also consider

deploying TEH1026Gs that are connected via Gigabit ports to two

separate groups within 300 feet of each other as a practical and

cost-effective alternative to fiber for their cooperation.

Complies with IEEE 802.3x full-duplex and flow control

Provides 24 10/100Mbps LAN ports,2 10/100/1000Mbps

LAN ports

Supports UPnP,NMA auto-negotiation

Integrated 4,000 MAC address table

Non-blocking,Store-and-forward switching

24+2G Gigabit Ethernet Switch

Expand your networking Easy to use

Store-and-forward

WHAT THIS PRODUCT DOES

BENEFITS

TECHNICAL SPECIFICATIONS

All For Better NetworkAll For Better Network

All For Better Network

Shenzhen Tenda Technology Co., Ltd.

Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,

Bao’an District, Shenzhen, P.R. China 518108

Tel: 0086.755.2765.7180 Fax: 0086.755.2765.7178

E-mail: [email protected] Http: www.tenda.cn

Obligation-free statement

PACKAGE CONTENTS

MINIMUM REQUIREMENTS

Internet Explorer 5.5 or Firefox 1.0

Network Adapter

Wired

Tenda is the registered trademark of Shenzhen Tenda

Technology Co. LTD in CHINA and certain other countries.

are trademarks or registered trademarks of their

respective holders.

The maximum performance for wireless is derived from IEEE Standard 802.11 specifications. Actual

performance can vary, including lower wireless network capacity, data throughput rate, range and

coverage. Performance depends on many factors, conditions and variables, including distance from

the access point, volume of network traffic, building materials and construction, operating system

used, mix of wireless products used, inter ference and other adverse conditions.

Check the product package and contents for specific features supported. Specifications are subject to

change without notice.

Model No.:TEH1026G

To have dedicated bandwidth on point to point

connections with every computer and to therefore run

in Full duplex with no collisions.

Plug and Play;

Provides two gigabit ports for unlink

Easy to use

TEH1026G 24+2G Gigabit Ethernet Switch

Power Cord

User Guide

2 Mounting Ears

8 Screws

4 Rubber Feet

32 to 104 F (0 to 40 ) º ºC

10 to 90% Noncondensing

-40 to 158 (-40 to 70ºC) ºF

5 to 90% Noncondensing

437mmX177mmX43mm (17.2"X7.0"X1.7")

2.29Kg

Protocols and Standards

Power Supply

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

Dimension (WXDXH)

Gross Weight

Certificate CE, RoHS

IEEE802.3, IEEE802.3u and IEEE802.3ab,IEEE 802.3x

AC160-264V,47-63Hz

MAC Address Table Size 4K

Transmission Method Store-and-Forward

10Base-T:Cat.3 or 3e UTP; 100Base-TX:Cat.5 UTP;1000Base-T: Cat.5e UTP

Switching Fabric Non-blocking

Transmission Media

Interface

24 10/100Mbps RJ45 Ports,2 10/100/1000Mbps RJ45 Ports

Housing Material Metal

Packet Buffer 1.5M
