Tenda 4G180 Manuel utilisateur

Quick Installation Guide

4G LTE Mobile Wi-Fi

4G180

Package contents

• Mobile Wi-Fi × 1 • Li-ion Battery × 1 • SIM Card Adapter × 1

• USB Cable × 1 • User Manual × 1

Please read this guide before you start with the quick setup upon the first use.

You can see the product name and model on the product label.

This guide instructs how to install and connect the device. For more information

such as the description of symbols displayed on relevant materials, please visit

www.tendacn.com.

Contents

01 / English

09 / Nederlands

15 / Melayu

21 / Русский

27 / Polski

33 / Čeština

39 / Deutsch

45 / Español

51 / Français

57 / Italiano

63 / Română

69 / ไทย

75 / Vietnamese

English

LED indicators

StatusLED Description

Solid green

Blinking green

Solid red

Connected to the internet.

Signal detected,but no internet access.

No signal.

Solid green

Blinking green

Solid red

Remaining battery percentage is above 25%.

Charging the battery.

Blinking green

for 5 times

Blinking green

Off

There are unread SMS messages.

No unread SMS messages.

Solid on

Blinking

Off

No device is connected to the Wi-Fi network.

The Wi-Fi network is disabled.

Blinking red Remaining battery percentage is below 20%.

Signal

Battery

Message

Wi-Fi

Remaining battery percentage is between

20% and 25%.

New SMS message is received or the

storage is full.

There is at least one device connected to

the Wi-Fi network,or a WPS negotiation is

in process.

English

WPS

Buttons/

Port/Slot

Reset3

Description

SIM card slot

Power button.

• Hold it for about 3 seconds to turn on/off the

Hotspot.

• Press it once to turn on its LED indicators.

WPS button.

When the WPS function is enabled,the Wi-Fi

LED indicator will blink.

Hold the button down for about 3 seconds to

enable the WPS function.Enable the WPS

function on a WPS-supported device to establish

a WPS negotiation.

Reset button.

Hold the button using a sharp object for about 6

seconds to reset the Hotspot.

SD card slot4

Insert your SD card here to increase storage

space.

Insert your SIM card here.

Micro USB

input port

6Used to charge the Hotspot, or to provide wired

device internet access using the USB cable.

No.

Buttons/Ports/Slots

English

Install SIM card and battery

❶

4GLTE

Mobile Wi-Fi

❷

SSID: Tenda_xxxxxx

Wi-Fi Key: xxxxxxxx

❸

❹

4GLTE

Mobile Wi-Fi

Open from the lower left

corner

Slide and flip to open, and

then insert a micro SIM (3FF)

card into the slot.

Metal connectors

English

Turn on the Hotspot

Solid green

Hold the button till all LED indicators flash once.

When the Hotspot is connected to the internet, you will find:

If the Hotspot is not connected to the internet after a long time, refer to Q1 in FAQ.

Tips

English

Access the internet

For the computer connected in a wired manner for the first time, you need to manually

install the CD drive popped up on the computer before you can access the internet.

If you cannot access the internet, refer to Q2 in FAQ.

If you cannot log in to the web UI, refer to Q3 in FAQ.

Tips

•

To access the internet through the Hotspot:

You can log in to the web UI by visiting 192.168.0.1 to further

configure the Hotspot.

Wireless: Connect your wireless device to the Wi-Fi network of

the Hotspot with the SSID and Wi-Fi key at the top of the

device after opening the back cover.

Wired: Connect a PC or laptop to the Hotspot using the USB

cable.

•

SSID: Tenda_XXXXXX

Wi-Fi Key: XXXXXX

SSID: Tenda_xxxxxx

Wi-Fi Key: xxxxxxxx

English

Charge your Hotspot

With no battery installed, 4G180 can still be powered on as long as it is connected to a

power supply device (such as a power adapter, laptop or portable charger) with the

USB cable.

If you need to use 4G180 with a power supply device always connected, you can

remove the battery for protection to extend its lifespan.

After the battery is fully charged, you can remove the charger to avoid shorter battery

lifespan caused by overcharge.

Tips

•

Method 1: Connect to a power socket (5V 1A).

Method 2: Connect to a computer by using the USB cable.

5V 1A

English

FAQ

Q2: I cannot access the internet. What should I do?



A2: Try the following solutions:

Ensure that the Hotspot is connected to the internet. If not,

refer to Q1.

Ensure that your wired device is connected to the Hotspot

properly and set to obtain an IP address automatically.

Try with your wireless device closer to the Hotspot.

Ensure that your wireless device is connected to the Wi-Fi

network of the Hotspot.

Ensure that your SIM card is pre-paid and has enough

balance.

Check if your SIM card is locked with a PIN code. If so,

contact your ISP for the PIN code, visit the web UI (default:

192.168.0.1) on a connected device, and follow the

instructions on the web UI to unlock the SIM card.

Try another SIM card.

Q1: The Hotspot is not connected to the internet after a

long time. What should I do?

A1: Try the following solutions:



 Reset the Hotspot.

Q3: I cannot log in to the web UI. What should I do?



A3: Try the following solutions:

For wired devices: Ensure that the wired device, such as a

computer, obtains an IP address automatically.

Ensure that you entered 192.168.0.1 correctly in the

address bar of a browser.

Try another browser or with another device.

- Ensure that you connect your device to the Wi-Fi network

of the Hotspot.

- Ensure that you have disabled the mobile data (if any) of

your wireless device.

For wireless devices:

If the problem persists, reset the Hotspot and try again.

Start a web browser on a connected device and visit

192.168.0.1 to log in to the web UI.

Change Network Name (SSID) and Wi-Fi Key (or Pass

Phrase) as required.

Find Network Settings and choose Wi-Fi Settings.

Enter the login password (default: admin) and click Login.

Q4: How to change the Wi-Fi name (SSID) and Wi-Fi key?

A4: Follow the steps below:

❶

❷

❸

❹

Q5: How to reset the Hotspot?

A5: Follow the steps below:

Hold the button using a sharp object for about 6 seconds.

Find the Reset hole in the lower part of the Hotspot.

Remove the back cover.

❶

❷

❸
