Teltonika TMT250 Guide d'installation
TMT250
Mini Tracker Easy
Quick Manual v1.0
Quick Manual v1.0 // TMT250 2
Telematics
CONTENT
Know your device................................................................................................................................................................................................3
Set up your device ..............................................................................................................................................................................................4
PC Connection (Windows)..................................................................................................................................................................................5
How to install USB drivers (Windows) ..............................................................................................................................................................5
Conguration(WINDOWS)..................................................................................................................................................................................6
QUICK SMS CONFIGURATION............................................................................................................................................................................8
Default conguration settings...........................................................................................................................................................................9
Troubleshooting............................................................................................................................................................................................... 10
Mounting recommendations.......................................................................................................................................................................... 10
Led indications ................................................................................................................................................................................................. 11
Basic characteristics ........................................................................................................................................................................................ 11
Safety information ........................................................................................................................................................................................... 14
Certication and Approvals ............................................................................................................................................................................ 16
Warranty ........................................................................................................................................................................................................... 16
Warranty disclaimer ........................................................................................................................................................................................ 17
Quick Manual v1.0 // TMT250 3
Telematics
KNOW YOUR DEVICE
ALARM
BUTTON
BATTERY
SOCKET
MAGNETIC
CONTACTS
CORDS FIXING
HOLE
MICRO SIM
SLOT
RGB LED
ON/OFF
BUTTON
TOP VIEW TOP VIEW (WITHOUT COVER)
Quick Manual v1.0 // TMT250 4
Telematics
SET UP YOUR DEVICE
HOW TO INSERT MICTO-SIM CARD AND CONNECT THE BATTERY
1COVER OPENING 3REMOVING PROTECTION
2COVER REMOVAL
Unscrew 4 screws counterclockwise
4BATTERY CONNECTION 5ATTACHING COVER BACK
Remove the cover. Insert Micro-SIM card as shown
with PIN request disabled or
read Wiki1 how to enter it later
in Teltonika Congurator2. Make
sure that Micro-SIM card cut-o
corner is pointing forward to slot.
1 wiki.teltonika-mobility.com/view/
TMT250_Security_info#SIM_Card
2 wiki.teltonika-mobility.com/view/
Teltonika_Congurator
Connect the battery as shown to the
device.
After conguration, see PC Connection
(WINDOWS)1. When it is done, reattach
the cover and push it in place.
1 Page 5, “PC Connection (Windows)”
Attach device cover back and screw in all
4 screws.
Quick Manual v1.0 // TMT250 5
Telematics
PC CONNECTION (WINDOWS)
HOW TO INSTALL USB DRIVERS (WINDOWS)
1. Please download COM port drivers from here1.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
5. Setup will continue installing the driver and eventually the conrmation window will appear. Click Finish to complete the
setup.
1 wiki.teltonika-mobility.com/images/d/d0/TeltonikaCOMDriver.zip
1. Connect device to computer using Magnetic USB cable or Bluetooth connection:
• Using Magnetic USB cable
• You will need to install USB drivers, see "How to install USB drivers (Windows)1"
• Using Bluetooth
• TMT250 Bluetooth is enabled by default. Turn on Bluetooth on your PC, then select Add Bluetooth or other device >
Bluetooth. Choose your device named – “TMT250_last_7_imei_digits”, without LE in the end. Enter default password 5555,
press Connect and then select Done.
2. You are now ready to use the device on your computer.
1 Page 5, “How to install USB drivers (Windows)”
Quick Manual v1.0 // TMT250 6
Telematics
MS .NET REQUIREMENTS
Operating system MS .NET Framework version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework 4.6.2 32 and 64 bit www.microsoft.com1
1 dotnet.microsoft.com/en-us/download/dotnet-framework
At rst the device will have default factory settings set, unless pre-congured device settings are ordered. These settings should be
changed according to the user’s needs. Main conguration can be performed via Teltonika Congurator1 software. Get the latest
Congurator versions from here2. Congurator operates on Microsoft Windows OS and uses prerequisite MS .NET Framework.
Make sure you have the correct version installed.
1 wiki.teltonika-mobility.com/view/Teltonika_Congurator
2 wiki.teltonika-mobility.com/view/TMT250_Stable_rmware
CONFIGURATION (WINDOWS)
Quick Manual v1.0 // TMT250 7
Telematics
Downloaded Congurator will be in compressed archive.
Extract it and launch Congurator.exe. After launch software
language can be changed by clicking 🌐 in the right bottom
corner. Turn On device by connecting Magnetic USB cable or
pressing Power On button for 2 sec. When device is turned on
LED should start blinking. Then connect device to computer
using Magnetic USB cable. For conguration also can be used
Bluetooth (Device Bluetooth is enabled by default, default
password 5555) connection.
Conguration process begins by pressing on connected device.
Various Status window1 tabs display information about GNSS2,
GSM3, I/O4, Maintenance5 and etc. TMT250 has one user
editable prole, which can be loaded and saved to the device.
After any modication of conguration the changes need to
be saved to device using Save to device button. Main buttons
oer following functionality:
Load from device – loads conguration from device.
Save to device – saves conguration to device.
Load from le – loads conguration from le.
Save to le – saves conguration to le.
Update rmware – updates rmware on device.
Read records – reads records from the device.
Reboot device – restarts device.
Reset conguration – sets device conguration to
default.
Most important congurator section is GPRS – where all
your server and GPRS settings6 can be congured and Data
Acquisition7 – where data acquiring parameters can be
congured. More details about TMT250 conguration using
Congurator can be found in our Wiki8.
After connection to Congurator Status window will be
displayed.
1 wiki.teltonika-mobility.com/view/TMT250_Status_info
2 wiki.teltonika-mobility.com/view/TMT250_Status_info#GNSS_Info
3 wiki.teltonika-mobility.com/view/TMT250_Status_info#GSM_Info
4 wiki.teltonika-mobility.com/view/TMT250_Status_info#I.2FO_Info
5 wiki.teltonika-mobility.com/view/TMT250_Status_info#Maintenance
6 wiki.teltonika-mobility.com/view/TMT250_GPRS_settings
7 wiki.teltonika-mobility.com/view/TMT250_Data_acquisition_settings
8 wiki.teltonika-mobility.com/view/TMT250_Conguration
Quick Manual v1.0 // TMT250 8
Telematics
QUICK SMS CONFIGURATION
Default conguration has optimal parameters present to ensure best performance of track quality and data usage.
Quickly set up your device by sending this SMS command to it:
Note: Before SMS text, two space symbols should be inserted.
GPRS SETTINGS:
2001 – APN
2002 – APN username (if there are no APN username,
empty eld should be left)
2003 – APN password (if there are no APN password,
empty eld should be left)
SERVER SETTINGS:
2004 – Domain
2005 – Port
2006 – Data sending protocol (0 – TCP, 1 – UDP)
« setparam 2001:APN;2002:APN_username;2003:APN_password;2004:Domain;2005:Port;2006:0»
1 2 3 4 5 6
1
2
3
4
5
6
Quick Manual v1.0 // TMT250 9
Telematics
DEFAULT CONFIGURATION SETTINGS
After successful SMS conguration, TMT250 device will synchronize time and update records to congured server. Time intervals
and default I/O elements can be changed by using Teltonika Congurator1or SMS parameters2.
1wiki.teltonika-mobility.com/view/Teltonika_Congurator_Introduction
2wiki.teltonika-mobility.com/view/TMT250_Parameter_list
DEVICE MAKES A RECORD ON MOVING IF ONE OF THESE EVENTS HAPPEN:
MOVEMENT AND IGNITION DETECTION:
MOVEMENT
will be detected by accelerometer
120
seconds passes
TRAVELED DISTANCE
100 meters
ANGLE DIFFERENCE
between last coordinate and current
position is greater than 10° degrees
SPEED DIFFERENCE
between last coordinate and current
position is greater than 10 km/h
DEVICE MAKES A RECORD ON STOP IF: RECORDS SENDING TO SERVER:
1
Hour passes
IF DEVICE HAS MADE A RECORD
120 sec on move and 600 send on stop
Quick Manual v1.0 // TMT250 10
Telematics
TROUBLESHOOTING
TMT250 DOESN’T SEND DATA TO YOUR CONFIGURED SERVER:
• Check if the device is turned on.
• Check if the SIM card is properly inserted.
• Check if the device has registered to the network.
• Data Acquisition settings are congured correctly.
• Check if your APN, Domain and Port are entered correctly and GPRS
IF THE DEVICE IS NOT DETECTED BY THE PC OR CONFIGURATOR WHILE PLUGGED IN:
• Check if the device is turned on and the battery is charged to a
• sucient level.
• Try using a dierent COM port.
• Try dierent Micro-USB cable.
• Reinstall Teltonika COM Driver.
• Reinstall MS .NET Framework.
More information about troubleshooting can be found in here1:
1 wiki.teltonika-mobility.com/view/FAQ
If these recommendations did not help, please contact your sales manager or contact us directly through Teltonika VipHelpDesk.
Find recommendations on how to ll in a query in our FAQ page in the Teltonika Wiki Knowledge base.
MOUNTING RECOMMENDATIONS
We recommend using the device in such a way, that device buttons an LEDs are easily and quickly accessible.
When using the Man-down feature, the device must be stably xed in the congured base position.
