CoaxManager™

User Guide

Content Index

Important safety instructions.................................................................................................................... 4

General installation conditions.....................................................................................................................4

How to use the equipment safely.................................................................................................................4

Electrical safety symbols..............................................................................................................................4

Introduction............................................................................................................................................... 5

Application Description................................................................................................................................ 5

Features.......................................................................................................................................................5

System Requirements .................................................................................................................................5

Supported CoaxDATA Devices.................................................................................................................... 5

Installing CoaxManager Application......................................................................................................... 6

Connecting CoaxDATA Modem to CoaxManager .......................................................................................7

Device Configuration................................................................................................................................ 8

MDU Configuration...................................................................................................................................... 9

Select Transmission medium.....................................................................................................................10

Transmission Mask.................................................................................................................................... 11

Writing Device Settings .............................................................................................................................12

Checking Devices Network.................................................................................................................... 13

Device Info.................................................................................................................................................13

CCO Info....................................................................................................................................................14

Network Topology...................................................................................................................................... 15

Generating traffic to verify network links ...................................................................................................16

Generating Reports for Checking Network State...................................................................................... 16

Setting QoS parameters (Advanced User) ............................................................................................ 18

Default Priorities.........................................................................................................................................18

Priority Levels Assignment.........................................................................................................................19

TTL - Time to Live......................................................................................................................................19

Buffer Allocation, Priority Thresholds.........................................................................................................20

Bandwidth Limit..........................................................................................................................................21

Bandwidth Limit with QoS..........................................................................................................................21

Setting Advanced Configuration ........................................................................................................... 23

IGMP options............................................................................................................................................. 23

Number of Users per Slave........................................................................................................................ 25

Network Mitigation..................................................................................................................................... 28

Factory Defaults Button............................................................................................................................. 29

Advanced Power Management..................................................................................................................29

Advanced MME Features.......................................................................................................................... 30

CoaxManager™User Guide

Important safety instructions

General installation conditions

Before handling or connecting the equipment,please read this manual.

In order to reduce the risk of fire or electric shock, do not expose the equipment to rain or

moisture.

Do not take the cover off the equipment without disconnecting it from the AC power.

Do not obstruct the equipment’s ventilation system.

Please allow air circulation around the equipment.

The equipment must not come into contact with water or even be splashed by liquids. Do not

place containers with water on or near the equipment if it is not adequately protected.

Do not place the equipment near sources of heat or in excessively moisture conditions.

Do not place the equipment where it may be affected by strong vibrations or knocks.

How to use the equipment safely

The powering supply of this product is: 100-264 Vac~ 50/60 Hz.

If any liquid or object falls inside the equipment, please contact a specialized technician.

To disconnect the equipment from the mains, pull from the connector, and never pull from the

cable.

Do not connect the equipment to the mains until all the other connections have been made.

The AC Power socket that is going to be used to connect the equipment should be located

nearby and should be easily accessible.

Electrical safety symbols

This symbol indicates compliance with the requirements of CE mark.

This symbol indicates that the equipment is for indoor use only.

This symbol indicates that the equipment complies with the safety requirements for

class II equipment.

ENGLISH

www.televes.es

Televes

Introduction

Application Description

CoaxManager™ software allows CoaxDATA™ device configuration, setting different modes of operation,

checking installation state and links between devices. CoaxManager™ also allows configuration of QoS

parameters, and other options such as activation of low-power modes for energy efficiency,

Features

Check coax or PLC installation obtaining links status and traffic rates between devices.

Create PDF reports of network status for later analysis.

Allows basic device configuration setting MxU/HomeNetworking operating modes.

Set Network password for create several system networks. You can install up to four masters

(each with a different key) on the same coaxial network.

Allows configuration of QoS parameters supporting four priority levels based on IEEE 802.1Q

VLAN tags or IPv4 ToS (Type of Service).

Supports Advanced Features to configure IGMP, number of users or Low Power Mode.

System Requirements

Application works with Windows 2000/XP/Vista/7/8

Application works on Mac OS X and Linux Operating systems with virtualization based on Oracle

VM VirtualBox software for Windows 2000/XP/Vista/7/8.

Application requires installation of additional Winpcap library (http://www.winpcap.org/install/

default.htm). If library is not installed, CoaxManager auto atically install on your PC.

Syste is fully Plug & Play and requires no installation of any additional software or drivers.

Supported CoaxDATA Devices

Following CoaxDATA devices are supported by application:

•Ref.7689 CoaxDATA™ 200Mbps-HDTV

•Ref.768973 CoaxDATA™ 200Mbps-HDTV 1xEth

•Ref.769201 CoaxDATA™ 1Gbps-HDTV

•Ref.769202 CoaxDATA™ 1Gbps-HDTV with SFP

•Ref.769203 CoaxDATA™ 1Gbps-HDTV 1XEth

•Ref.769301 CoaxData™ 1Gbps-HDTV 3XEth + Wifi

www.televes.es

CoaxManager™User Guide

Installing CoaxManager Application

CoaxManager application installed through an executable that guide the user through the installation

process.

Language selection: This option selects setup language

Follow installer instructions to complete applcation installation. Read carefully license before use

program and approval before continue.

Once installed application will appear on your desktop the icon below:

ENGLISH

www.televes.es

Televes

Connecting CoaxDATA Modem to CoaxManager

After installing application, when CoaxManager start scan all computer ethernet interfaces trying to find

connected devices. In the case of identifying a device already connected, get information associated

therewith.

Application provides two combos NIC Interface and Devices showing interfaces and devices that have

been located within these interfaces. When pressed in combo Devices updates automatically Network

Devices list, showing local device (connected directly through ethernet) and all devices that it has

located within its network. .

Click on Connect/Disconnect Button to select which device you want to configure. Different operations

are available :

•Read Config: Reads connected device configuration. This operation is performed automatically

when connected to a device.

•Write Config: Write configuration on connected device. Configuration is changed through tab

GUIs.

•Factory Defaults: Sets device to factory settings. Be careful with this option since restore to

factory configuration causes lose any settings you made on it. This button has the same effect as

Factory Defaults button located on the front of the modems.

•Help: This manual.

Once connected to device we have access to different tabs that show different information about it.

If you can not connect to device, verify that this is correctly

connected via an Ethenet cable. If there is an intermediate switch or

other network devices, are configured properly.

www.televes.es

CoaxManager™User Guide

Device Configuration

Operation ode setting can be perfor ed through Configuration ta , where shows device info and also

those fields that configure device access ode, network password or trans ission ask.

Device Parameters displays information about device:

•Firmware Version: Version Info of Device Firmware.

•PIB Version: Device PIB Version (Parameters Information Block) . PIB stores user configuration

changes and contains firmware runtime parameters.

•MAC Address: Device MAC Address. All Televes MAC Address start with 00:0E:7C hexadecimal

values and are registered on IEEE.

•DAK key (Device Access key): Key established in the manufacturing process and determines

access to devices when it occurs remotely (via coaxial). Knowledge of this key is essential for

updating/configuring devices remotely, although default DAK key value is always the same, on

manufacturing proccess, simplifying devices configuration.

•NMK key (Network Management Key): Key set by the user and allows creation of different data

networks named AVLN. This 128bit hexadecimal key, is generated based on the Network

Password field value using a hash algorithm. NMK key determines whether a slave can connect

to a master or not and only devices with the same NMK can be connected together.

ENGLISH

www.televes.es

Televes

•NET ID, MDF ID, USR ID: Description fields determining the network name, Televes product

description and user description, done by the installer. Installer can change descriptions that

make sense in the coaxial network as the location of the modem, its role in the network or who is

using it.

•MDU mode: Indicates whether MDU mode is active or not.

•CCo mode (Central coordinator): CCo is responsible for coordinating communications between

devices. There are three options: CCo Auto: Device negociates with other who is CCo, Cco

Never: Device never is CCo, CCo Always: Device is Always CCo.

- On MDU mode: Master is always CCo, and slave never. CCo mode is not configurable.

- On Homenetworking mode: CCo Auto is default mode and CCo is assigned by negociation

between devices. When devices negociate who is CCo, all devices communicate with each other.

On hybrid networks with PLC medium or on networks where communication between all devices

are not guaranteed, installer must configure devices as well CCo never, well CCo Always, and

CCo Always device be connected to the router that gives Internet service . This avoids problems

with the negotiation of CCo Auto mode in case of lack of communication between all devices.

•Disable Device Transmissions: This options allows disable device transmissions and avoids

data transmission on network. Coaxmanager application still connect to device for management

but device cannot transmit data avoiding bandwith consumption.

MDU Configuration

Sets operating mode of the device.

Home Networking: This is default mode setting

at the factory and allows the creation of a local

area network where all devices communicate with

each other. These networks are usually created

when the modem is used to extend internet

services within a house. Default mode that is

retrieved using the Defaults button.

MDU/MTU (Multi-Dwelling/Multi-Tenant Unit). This

mode uses current coaxial network on a building

or house to communicate from the headend with

each of modems installed on coaxial outlets,

providing access to multiple dwellings without can

communicate with each other. In this mode have

two modes, master and slave.

If you select MDU option is necessary to specify which mode you want:

•Master: CoaxDATA operate in master mode and is typically installed in the headend, as

described in CoaxDATA product manual. Master controls when the slaves can access the

medium synchronizing transmissions and avoiding slave conflicts.

•Slave: modem will be installed in a coaxial outlet, as indicated in CoaxDATA product

manual.

www.televes.es

ENGLISH

CoaxManager™User Guide

Select Transmission medium

Sets device transmission medium

•Hybrid Coax+PLC: This option indicates that operation mode is hybrid, where devices

communicate via PLC and Coax. The medium swich on front of device must be on the left and

power LED is set to orange color.

•Only Coax: In this mode of operation only coaxial is used as communication medium. The

medium swich on front of device must be on the right and power LED is set to green color.

•Round Robin Slot(Only MxU): Every Slave have chance to transmit data and reduce probability

of whole network colliding. Enable Round Robin generally enhance the throughput.

•Point to Multipoint (Only MxU): Master have chance to transmit data and reduce probability of

whole network colliding

•Enable Hidden Node(Only MxU): This option changes medium access mechanism of the

devices. Typically medium access method is based on CSMA (carrier sense medium access)

listening and checking medium is avaliable. Devices access to medium when no one else is

transmitting. This mechanism, however, requires that all of the devices can listen all

transmissions of other devices connected to the network. Depending on the coaxial network in

which the system is implemented, there may not listen slaves of other slaves transmissions due

to a high isolation of distribution outlets (> 100dB) and CSMA access mechanism in not valid.

Enable Hidden Node option replaces medium access contention for a token-based system, where

slaves transmit only when the master gives them permission. For this mechanism to work properly, all

devices on the network must have this feature enabled.

With this feature modems access to the medium only when they have permission to do so, providing

better performance in environments where the insulation between slaves is very high. Since the devices

have to get the token for access to the medium, there is a 20% reduction in the total thoughput system.

This feature is enabled by default when user select Coaxial Medum to transmit. Disable only when

isolation between slaves is a known low value.

ENGLISH

www.televes.es

Table des matières

Autres manuels Televes Modem

Televes

Televes RTC 5835 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
