P H A S E R®8 4 0

COLOR PRINTER

PhaserShare

®Networking

Setup Guide

Phaser

840 Color Printer

PhaserShare

Networking Setup Guide

V2 March 1999

063-3178-00

Tektronix, Inc.

Unpublished rights reserved under the copyright laws of the United States. Contents of this publication may not be

reproduced in any form without permission of Tektronix, Inc.

Tektronix

, Phaser

, PhaserShare

, the TekColor logo, ColorStix

, ColorCoat

, and Made For Each Other

are

registered trademarks of Tektronix, Inc. Finepoint™, PhaserLink™, PhaserPrint™, the TekColor name, and

PhaserSym™ are trademarks of Tektronix, Inc.

Adobe

and PostScript

are trademarks of Adobe Systems Incorporated which may be registered in certain

jurisdictions.

Apple

, AppleTalk

, LocalTalk

, EtherTalk

, TokenTalk

, and Macintosh

are registered trademarks of Apple

Computer, Inc.

SGI™ is a trademark of Silicon Graphics, Inc.

SPARC

is a registered trademark of SPARC International, Incorporated. SPARCstation™ is a trademark of SPARC

International, Inc., licensed exclusively to Sun Microsystems, Inc.

The Tektronix Phaser 840 Color Printer is certiﬁed as a NetWare print server device, on both 3.12 and

4.1

NetWare systems. Bindery mode is also certiﬁed to comply on both 3.12 and 4.1

NetWare

systems. NetWare NDS is certiﬁed on 4.1

NetWare systems.

Novell® and NetWare® are registered trademarks of Novell, Inc.

UNIX

is a registered trademark in the United States and other countries, licensed exclusively

through X/Open Company, Ltd.

Times™, Helvetica™ and Palatino™ are trademarks of Linotype-Hell AG and/or its subsidiaries.

Other marks are trademarks or registered trademarks of the companies with which they are

associated.

PANTONE

Colors generated by Phaser Color Printers are four- and/or three-color process simulations and may not

match PANTONE-identiﬁed solid color standards. Use current PANTONE Color Reference Manuals for accurate

colors.

PANTONE Color simulations are only obtainable on these products when driven by qualiﬁed Pantone-licensed

software packages. Contact Pantone, Inc. for a current list of qualiﬁed licensees.

Pantone, Inc.’s check-standard trademark for color reproduction and color reproduction materials.

Setup Guide

iii

1 Introduction

Before you begin network configuration 2

Printing a Configuration Page 2

Printer management 3

If you need more information 4

2 Connecting Your Printer to a Network

PhaserShare Series B Ethernet interface 5

PhaserShare Series B Token Ring card 9

PhaserShare Series B LocalTalk card 16

3 EtherTalk, LocalTalk, and TokenTalk Configuration

Configuration overview 19

Finding the printer’s name in the Chooser 20

4 Novell NetWare Configuration

Installing the PhaserShare Administrator 21

Using the Quick Configuration Wizard 22

Setting IPX frame types from the front panel 24

5 TCP/IP Configuration (UNIX)

Adding the printer to the host table 25

Assigning a print queue to the printer 25

Example installation for a typical BSD UNIX system 27

Printer configuration 29

Extracting files from unix.tar 30

6 Windows 95 and Windows 98: PhaserPort Software

TCP/IP configuration for a PC 31

Setting the printer’s IP address 32

PhaserPort software installation 32

Adding a port for a new printer 34

Adding a port to an existing printer 35

Changing a port’s IP address 36

Contents

PhaserShare Networking

7 Windows NT

Setting the printer’s IP address 37

Adding a Windows NT 4.0 driver on a Windows NT 4.0 server or workstation 37

Adding a Windows NT 4.0 driver on an NT 3.51 server 41

Adding a Windows NT 3.x driver 43

8 Setting the Printer’s IP Addressing Parameters

Setting IP parameters from the front panel 48

Setting IP parameters: RARP or BOOTP 49

Setting IP parameters: DHCP 51

Supported BOOTP/DHCP fields 53

Setting IP parameters: PostScript utility file (UNIX only) 54

Setting IP parameters: PhaserLink Printer Management Software 56

DNS 57

9 PhaserLink Printer Management Software

Accessing printer information from a browser 59

PhaserLink Printer Management software help files 60

Setting printer parameters: PhaserLink software pages 61

Information Forwarding 61

Index

Setup Guide

Chapter

Introduction

This guide provides information to help you quickly install the Tektronix

Phaser 840 color printer in the following environments:

■

EtherTalk, LocalTalk, and TokenTalk

■

Novell NetWare

■

UNIX

■

Windows 95 and Windows 98

■

Windows NT

For detailed networking information, including troubleshooting, see the online

manual on your printer’s CD-ROM, or see the

PhaserShare Networking Manual

PDF format on your printer’s CD-ROM.

For information on installing Tektronix printers in DOS environments, see the

printer’s CD-ROM or network utilities diskettes. They contain PostScript utility

ﬁles that can be sent to the printer for network conﬁguration in DOS

environments. They also contain a DOS application, NWSET, for printer

conﬁguration on NetWare networks.

For information on how to use the DOS conﬁguration ﬁles, see the

README

ﬁles on the printer’s CD-ROM and network utilities diskettes. PC users: the

README

ﬁle for PostScript utility ﬁles is in the

UTILS

directory; the

README

ﬁle for NWSET is in the

NETWARE

directory. (Macintosh users: the

ReadMe

ﬁle

for PostScript utility ﬁles is in the

Network Utilities

folder).

For information on installing into OS/2 environments, see the online manual on

your printer’s CD-ROM, or see the

PhaserShare Networking Manual

in PDF format

on your printer’s CD-ROM.

Introduction

PhaserShare Networking

Before you begin network conﬁguration

■

Set up your printer and connect it to the network. See your printer’s user

documentation for information about setting up the printer. For

information about connecting the printer to the network, see Chapter 2 of

this manual, “Connecting Your Printer to a Network”.

■

Install the Tektronix driver for your printer on every Macintosh and PC

that will send print jobs to the printer. For details on driver

installation, see your printer’s user documentation.

■

For NetWare environments.

To speed the setup process and avoid

conﬂicts, familiarize yourself with the components of your network.

You should know which version(s) of NetWare are installed, which

versions of client software are used, and the network topology (frame

types, routers, hubs, and cabling).

Printing a Conﬁguration Page

Your printer’s Conﬁguration Page supplies useful information for installing and

conﬁguring the printer on a network.

Printing a Conﬁguration Page

When the front panel displays

READY TO PRINT

, press the

down-arrow button until

is highlighted. Press

Select

Press the down-arrow button until

Printer Configuration

highlighted. Press

Select

Press the down-arrow button until

Print Configuration Page

highlighted. Press

Select

Introduction

Setup Guide

Printer management

After your printer is up and running on the network, you can take advantage of

the following features that aid you in managing your printer over the network:

■

Job accounting.

The printer stores a log ﬁle containing information

about jobs printed. The ﬁle is a list of job accounting records. Each

record contains ﬁelds such as user name, job name, pages printed, job

times, and toner used. Job accounting is available through the

PhaserShare Administrator and PhaserLink Printer Management

software.

■

PhaserLink Status Notiﬁcation.

PhaserLink Printer Management

Software provides PhaserLink Status Notiﬁcation, which allows the

printer to automatically send email to the system administrator and

others when the printer requires attention (for example, when printer

errors, warnings, and alerts occur, or when service is required).

■

Usage Proﬁle reports.

The printer can generate reports detailing

printer usage. These

Usage Proﬁle reports

include information on many

aspects of printer usage, including ink or toner used, number of pages

printed, and media types used. You can print these reports from the

front panel or PhaserLink Printer Management software, or you can

obtain them automatically via email.

■

PhaserLink PDF Direct Printing.

This feature provides

drag-and-drop printing of PDF and PostScript ﬁles from your web

browser in Windows 95 and Windows 98 environments. Just drag any

hotlink for a PDF or PostScript ﬁle from the browser to the PhaserLink

PDF Direct Printing icon on the desktop to print the ﬁle on your

Tektronix printer. There is no need to access the URL or open the ﬁle.

■

Intelligent Ready.

With Intelligent Ready, the printer can monitor

usage and automatically warm up when you are most likely to need it.

You can turn Intelligent Ready on or off from the printer’s front panel.

Using PhaserLink Printer Management Software, you can control

when the printer automatically warms up.

For more information on these features, see the

PhaserShare Networking Manual

on the printer’s CD-ROM.

Introduction

PhaserShare Networking

If you need more information

You may need more information about troubleshooting your network

installation or using the printer. The following sources are available:

PhaserShare networking manual.

Provides detailed networking information

for system administrators, including troubleshooting; available in PDF format

on the printer’s CD-ROM. A printed copy of this manual can be ordered from

Tektronix (part number 071-0180-01).

Online user manual

. Provides complete information on using your printer,

including printer care, printer features, and networking; provided in HTML

format on the printer’s CD-ROM. It is also available on the Tektronix web site.

PhaserShare Administrator online help.

Provides detailed descriptions of all

program functions and dialog boxes.

PhaserLink Printer Management Software online help

. HTML ﬁles supplied

on the printer’s CD-ROM. See “PhaserLink Printer Management software help

ﬁles” on page 60.

Readme ﬁles

. Provided on the printer’s CD-ROM and diskettes. They contain

information about PostScript utility ﬁles and DOS applications that can be used

for conﬁguring and using your printer in DOS environments. Some utility ﬁles

for Macintosh are also provided.

World Wide Web

. User documentation and other printer information is

available from the Tektronix web site:

www.tek.com/Color_Printers/support/colcare.html

Technical support hotline.

In the U. S. and Canada, call 1-800-835-6100,

Monday through Friday, 6:00 am to 5:00 pm PST. For international numbers, see

the printer’s user guide or visit:

www.tek.com/Color_Printers/cgi-bin/CPIDlocProcessor

Autres manuels pour Phaser 840

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Tektronix Imprimante

Tektronix

Tektronix Z740/DX - Phaser 740 Extended Color Laser... Manuel utilisateur

Tektronix

Tektronix Phaser 350 Manuel utilisateur

Tektronix

Tektronix Phaser 200E Guide de configuration

Tektronix

Tektronix Phaser 440 Manuel utilisateur

Tektronix

Tektronix Phaser 300i Manuel utilisateur

Tektronix

Tektronix Phaser 140 Manuel utilisateur

Tektronix

Tektronix Phaser 140 Mode d’emploi

Tektronix

Tektronix Phaser 850 Manuel utilisateur

Tektronix

Tektronix PHASER 380 Manuel utilisateur

Tektronix

Tektronix 1235N - Phaser Color Laser Printer Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Tektronix

Tektronix PHASER 380 Manuel utilisateur

Tektronix

Tektronix Phaser 340 Manuel utilisateur

Tektronix

Tektronix Phaser 750DX Manuel

Tektronix

Tektronix Z850 Mode d’emploi

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Tektronix

Tektronix Phaser 750DP Manuel utilisateur

Tektronix

Tektronix Z780GN - Phaser 780 Graphics Color Laser... Manuel du propriétaire

Tektronix

Tektronix Phaser 850 Manuel utilisateur

Tektronix

Tektronix Phaser 540 Manuel utilisateur

Tektronix

Tektronix Phaser 780 Color Manuel utilisateur

Tektronix

Tektronix Phaser 560 Manuel utilisateur

Tektronix

Tektronix Phaser 220e Manuel utilisateur

Tektronix

Tektronix Phaser 750DP Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur
