Tektronix P5200 Manuel utilisateur

P5200

High Voltage Differential Probe

ZZZ

Instruction Manual

*P070901806*

070-9018-06

P5200

High Voltage Differential Probe

ZZZ

Instruction Manual

www.tektronix.com

070-9018-06

owned by Tektronix or its subsidiaries or suppliers, and are protected by national

Tektronix products are covered by U.S. and foreign patents, issued and pending.

Information in this publication supersedes that in all previously published

material. Speciﬁcations and price change privileges reserved.

TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

Contacting Tektronix

Tektronix, Inc.

14200 SW Karl Braun Drive

P.O. Box 500

Beaverton, OR 97077

USA

For product information, sales, service, and technical support:

In North America, call 1-800-833-9200.

Worldwide, visit www.tektronix.com to ﬁnd contacts in your area.

Warranty

Tektronix warrants that this product will be free from defects in materials and

workmanship for a period of one (1) year from the date of shipment. If any such product

proves defective during this warranty period, Tektronix, at its option, either will repair

the defective product without charge for parts and labor, or will provide a replacement

in exchange for the defective product. Parts, modules and replacement products used by

Tektronix for warranty work may be new or reconditioned to like new performance. All

replaced parts, modules and products become the property of Tektronix.

In order to obtain service under this warranty, Customer must notify Tektronix of the

defect before the expiration of the warranty period and make suitable arrangements for the

performance of service. Customer shall be responsible for packaging and shipping the

defective product to the service center designated by Tektronix, with shipping charges

prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to

a location within the country in which the Tektronix service center is located. Customer

shall be responsible for paying all shipping charges, duties, taxes, and any other charges

for products returned to any other locations.

This warranty shall not apply to any defect, failure or damage caused by improper use or

improper or inadequate maintenance and care. Tektronix shall not be obligated to furnish

service under this warranty a) to repair damage resulting from attempts by personnel other

than Tektronix representatives to install, repair or service the product; b) to repair damage

resulting from improper use or connection to incompatible equipment; c) to repair any

damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a

product that has been modiﬁed or integrated with other products when the effect of such

modiﬁcation or integration increases the time or difﬁculty of servicing the product.

THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE

PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED.

TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’

RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE

SOLE AND EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR

BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE

LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL

DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS

ADV

ANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.

[W2 – 15AUG04]

Table of Contents

General Safety Summary ............................................... ii

Service Safety Summary................................................ iv

Compliance Information................................................. v

EMC Compliance ................................................... v

Safety Compliance ................................................ vii

Environmental Considerations .................................... ix

Features and Accessories ................................................ 1

Getting Started............................................................ 5

Installation ........................................................... 5

Functional Check.................................................... 6

Operating Basics.......................................................... 7

Operating the Probe Safely......................................... 7

Operating Characteristics and Probing Techniques............. 10

Speciﬁcations ........................................................... 15

Warranted Characteristics ........................................ 15

Typical Characteristics............................................ 16

Nominal Characteristics .......................................... 17

User Service ............................................................ 19

Cleaning............................................................ 19

Packaging for Shipment .......................................... 19

Performance Veriﬁcation............................................... 21

Construction of Modiﬁed BNC Adapter ........................ 22

Setup................................................................ 23

Amplitude Accuracy .............................................. 24

Rise Time .......................................................... 26

DC CMRR ......................................................... 27

Replaceable Parts. . .... ..... . ... . .... . ... . . .... .... . . ... . .... . ... . . .... . 29

Parts Ordering Information....................................... 29

Using the Replaceable Parts List. .... .... . .... .... . . ... . .... . ... . 30

P5200 Instruction Manual i

General Safety Summary

Review the following safety precautions to avoid injury and prevent

damage to this product or any products connected to it.

To avoid potential hazards, use this product only as speciﬁed.

Only qualiﬁed personnel should perform service procedures.

To Avoid Fire or Personal Injury

Connect and Disconnect Properly. Connect the probe output to the

measurement instrument before connecting the probe to the circuit

under test. Connect the probe reference lead to the circuit under test

before connecting the probe input. Disconnect the probe input and the

probe reference lead from the circuit under test before disconnecting

the probe from the measurement instrument.

Ground the Product. This product is indirectly grounded through the

grounding conductor of the mainframe power cord. To avoid electric

shock, the grounding conductor must be connected to earth ground.

Before making connections to the input or output terminals of the

product, ensure that the product is properly grounded.

Observe All Terminal Ratings. To avoid ﬁre or shock hazard, observe all

ratings and markings on the product. Consult the product manual for

further ratings information before making connections to the product.

Do Not Operate Without Covers. Do not operate this product with covers

or panels removed.

Do Not Operate With Suspected Failures. If you suspect that there is

damage to this product, have it inspected by qualiﬁed service personnel.

Avoid Exposed Circuitry. Do not touch exposed connections and

components when power is present.

ii P5200 Instruction Manual

General Safety Summary

Do Not Operate in Wet/Damp Conditions.

Do Not Operate in an Explosive Atmosphere.

Keep Product Surfaces Clean and Dry.

Provide Proper Ventilation. Refer to the manual’s installation instructions

for details on installing the product so it has proper ventilation.

Terms in this Manual

These terms may appear in this manual:

WARNING. Warning statements identify conditions or practices that could

result in injury or loss of life.

CAUTION. Caution statements identify conditions or practices that could

result in damage to this product or other property.

Symbols and Terms on the Product

These terms may appear on the product:

DANGER indicates an injury hazard immediately accessible as you

read the marking.

WARNING indicates an injury hazard not immediately accessible

as you read the marking.

CAUTION indicates a hazard to property including the product.

The following symbol(s) may appear on the product:

P5200 Instruction Manual iii

Service Safety Summary

Only qualiﬁed personnel should perform service procedures. Read

this Service Safety Summary and the General Safety Summary before

performing any service procedures.

Do Not Service Alone. Do not perform internal service or adjustments

of this product unless another person capable of rendering ﬁrst aid and

resuscitation is present.

Disconnect Power. To avoid electric shock, switch off the instrument

power, then disconnect the power cord from the mains power.

Use Care When Servicing With Power On. Dangerous voltages or currents

may exist in this product. Disconnect power, remove battery (if

applicable), and disconnect test leads before removing protective panels,

soldering, or replacing components.

To avoid electric shock, do not touch exposed connections.

iv P5200 Instruction Manual
