TECOM SA505 Manuel utilisateur
SA505 Bluetooth Stereo Headphone User'sGuide 1
User Manual for SA505
Bluetooth Stereo Headphones
BT3070 Bluetooth Stereo Headphone User's Guide 2
CAUTION: Avoid using SA505 headphone with the volume turned up for a long
time. Doing so can damage your hearing. It is advisable to keep the volume at a
moderate level at all times.
Copyright © 2005, TECOM Co., Ltd All rights reserved.
User’s Guide
SA505 Bluetooth Universal Stereo Headphone
Third Edition (December 2005)
SA505 Bluetooth Stereo Headphone User'sGuide 3
Table of Contents
I. About SA505 Stereo Headphone......................................................................... 4
1.1、BT3070 Stereo Headphone Overview........................................................ 4
1.2、General Features ......................................................................................... 5
II. Setup SA505 Headphone...................................................................................... 6
2.1、Turn on/off stereo headphone..................................................................... 6
2.2、Pairing with devices.................................................................................... 6
2.3、Connecting BT3070 headphone with multiple devices............................ 11
2.4、Charging headphone ................................................................................. 11
III. Play Music with SA505 Headphone.................................................................. 13
IV. Make/Answer Calls with SA505 Headphone ................................................... 15
V. The LED Indicator Mean..................................................................................... 17
SA505 Bluetooth Stereo Headphone User'sGuide 4
I. About SA505 Stereo Headphone
1.1、SA505 Stereo Headphone Overview
< Left side >
< Right side >
Blue/ Red Status
LED Indicator
Volume Up Play/ Pause/ Stop/
Pairing Button
Volume Down
Forward Backward
Retractable
Microphone
Orange LED
Charging Indicato
r
Power On/ Off
Floating Slider
Mini USB
Charging Socke
t
SA505 Bluetooth Stereo Headphone User'sGuide 5
1.2、General Features
Phone Call: SA505 is equipped with a retractable microphone and
supports Bluetooth hand-free profile for wireless
phone call.
Music Streaming: SA505 supports Bluetooth A2DP (Advanced Audio
Distribution Profile). User can enjoy omni-direction
high quality wireless music play up to 15 meters away.
Remote Control: SA505 supports Bluetooth AVRCP (Audio Video
Remote Control Profile). User may use SA505
interface to control music play remotely.
Clarity: Advanced DSP (Digital Signal Processing) technology
is incorporated for noise reduction and echo
cancellation during wireless phone conversation.
Others Up to 5 Bluetooth phones or MP3 players can be
paired with single SA505.
Standby time up to 400 hours.
Supports continuous music play up to 8 hours and
continuous talking up to 10 hours.
One-push the retractable microphone for picks up
a call.
SA505 Bluetooth Stereo Headphone User'sGuide 6
II. Setup SA505 Headphone
2.1、Turn on/off stereo headphone
Put the Power On/Off Floating Slider to ON
side for turning on your headphone – when the
headphone is opened, a short tone will be heard
and the LED indicator will flash slowly in blue.
Put the Power On/Off Floating Slider to OFF
side for turning the headphone off.
2.2、Pairing with devices
Before using SA505 headphone you must pair up with Dongle or/and mobile
phone or other bluetooth enabled devices.
Put the headphone into pairing mode
Press and hold the Play button (about 5
seconds) until the LED indicator flash blue
and red alternately – 2 short tones will be
heard.
Set your Dongle or mobile phone or other device to “discover” the BT3070
headphone and then pair with it.
Please follow Dongle /or phone or other devices instruction guide.
Tecom Dongle for example: (Operating System: Windows XP pro. SP2)
SA505 Bluetooth Stereo Headphone User'sGuide 7
Steps Actions Illustration
1 Double click “My Bluetooth
Places” icon on the desktop first.
2 Click “View the device in range”
3 Click “Search for device in
range” to discover the BT3070
headphone.
4 Dongle will find the BT3070
headphone, right click to find out
its related services.
5 It will require the PIN code,
please confirm with PIN = 0000
(4 zero’s).
In case of unsuccessful pairing please repeat above steps.
SA505 Bluetooth Stereo Headphone User'sGuide 8
Nokia 6230 for example:
Steps Actions Illustration
1 Click “Menu” button first.
2 Select “Settings”.
3 Select “Connectivity”
SA505 Bluetooth Stereo Headphone User'sGuide 9
4 Select “Bluetooth”
5 Select “Paired devices”
6 Please click “New” to search for the
BT3070 headphone.
SA505 BluetoothStereo Headphone User'sGuide 10
7 Mobile phone will find the BT3070
headphone. Please click “Pair” to pair with
the BT3070 headphone.
8 Mobile phone will require the passcode
(PIN code), please confirm with passcode
= 0000 (4 zero’s) and then click “OK”.
9 Click “Connect” to connect with the
BT3070 headphone.
When connected, mobile phone’s operating tone will automatically be
transferred to your headphone.(Depend on mobile’s type, some of mobiles may
be fail to hear operate tone from BT3070 after connected.)
