Tecnosicurezza Pulse Pro Manuel utilisateur

Pulse Pro

User Instructions

2 di 26 IU_PulsePro_08

User instructions

Pulse PRO

Company

Founded in 1983 with the aim of providing a complete range of professional products,

Tecnosicurezza is now a consolidated reality in the field of locks and security systems for safes.

The experience gained in over 35 years of activity in the security sector has allowed the

designing and manufacturing of high technology and reliability systems, which continue to

receive the approval of an increasingly demanding clientele.

TECNOSICUREZZA is present directly on the Italian, Spanish and US markets and, through a

extensive distribution network, in many EU and extra-EU countries.

TECNOSICUREZZA is aimed at national and international customers of primary importance,

such as banks, safe manufacturers, cash in transit companies, mass market retailers and post

offices.

Today TECNOSICUREZZA is a leading company focused on the customers’ needs and

constantly in step with technology.





 IU_PulsePro_08 3 di 26
User instructions

Pulse PRO
Table of contents
COMPANY 2
TABLE OF CONTENTS 3
IMPORTANT NOTES! 5
GENERAL INFORMATION 6
OVERVIEW FUNCTIONS 9
LOCK OPENING 10
PRE-SETUP MODE 10
MANAGER AND STANDARD USERS 10
OVERRIDE USERS 11
CODE CHANGING (FUNCTION 0) 11
INSTALL/DISABLE/DELETE USERS 11
DISABLE/ENABLE USERS (FUNCTION 2) 12
DELETE USERS (FUNCTION 3) 12
BATTERY TEST (FUNCTION 4) 12
TEST MODE (FUNCTION 5) 12
LOCK SETUP (FUNCTION 6) 13
REMOTE OVERRIDE/REMOTE BLOCK 13
HOLD-UP/BOLT OUTPUT 13
DOOR ALARM 14
MANUAL CLOSING 14
BUZZER SILENT 14
DATE FORMAT 14
EXPIRING CODES 15
DELETION OF UNUSED CODES 15
USERS STATUS (FUNCTION 7) 15
AUDIT 16
DOWNLOAD THE AUDIT ON A DALLAS KEY 16
DOWNLOAD THE AUDIT ON PC: 16
CONFIGURATION SELECTION (FUNCTION 8) 17
TIME DELAY (FUNCTION 9) 18
TIME SETTING 18
DATE SETTING 19

4 di 26 IU_PulsePro_08

User instructions

Pulse PRO

EMERGENCY RESCUE CODE (ERC) 19

RESET MODE (WITH RESET BOX) 19

CONFIGURATION NUMBER 20

CONTACTS 26

IU_PulsePro_08 5 di 26

User instructions

Pulse PRO

Important notes!

•Before installing this product, please read carefully the installation and operating

instructions.

•Locks have been designed to correctly operate in a temperature range from -5°C to +

50°C and and in an environment with non-condensing humidity between 25% and 90%.

•The lock must not be oiled/lubricated/greased.

•If installed in normal domestic or office environments, the locks do not require

particular maintenance; in any case, after 10,000 opening/locking cycles, it is

recommended to run a test that verifies the correct and complete operation of the

product.

•Use only DURACELL™ 9 Volt Alkaline batteries, or battery holders with DURACELL™ 1.5

Volt Alkaline batteries. Alternatively, it is possible to use a 12VDC - 1A power adapter

(p.n. N1212) with relative power supply interface (p.n. T6005/W or p.n. T6005).

•A series of multiple beeps indicate a low battery level which need immediate replacing.

•It is strongly recommended to change the default codes before the usage and to keep

safely the new codes.

•Do never use codes easy to be guessed such as 123456, birth dates or others, based on

own personal information.

•After changing a code, perform several opening/closing tests before closing the door.

Should the lock label be removed, warranty is void.

6 di 26 IU_PulsePro_08

User instructions

Pulse PRO

General information

Using your keypad

The keypad automatically switches OFF if no buttons are pressed

within 5s.

Press to cancel an operation. A short beep is produced.

To start a time delay counting (if set), enter an opening combination:

LED flashes every 2s, indicating the counting.

Press to stop a time delay counting.

The open window is indicated by a flashing and a beep alternating at 1s

intervals.

The led is kept ON if the system is in programming mode.

2 short beeps are produced if an operation/ID/code is correct.

A long beep is produced if an operation/ID/code is incorrect.

If an incorrect operation is done, wait for 5s until the keypad switches

OFF before continuing.

A single beep (bad sound) is produced when some setup options of the

lock are enabled.

A long beep plus 3 shorts beeps are produced if an expired code is

entered.

An error beep is produced in case of RTC issue. It is recommended then

to update time and date.

IU_PulsePro_08 7 di 26

User instructions

Pulse PRO

To open or access the menu in dual mode (if set), enter the first user's

combination: the led flashes fastly. Then, enter the second user's

combination.

To stop a dual mode opening, press after having introduced the

first user’s combination and while the led is flashing.

Shortcuts

Press and hold for 2 seconds the button related to the needed function:

= Change Master code (80, 81), Manager (60, 61), users (01-59) and override users (10

or 50-59)

= Users installation

= Enable/Disable Users

= Delete Users

= Battery test

= Test mode

= System setup

= Users status and Audit

= Configuration selection/PC programming through setup software

= Time delay and opening window

= Time and date setting

= Reset

8 di 26 IU_PulsePro_08

User instructions

Pulse PRO

Pre-setup & Configurations

When the lock is in pre-setup mode and connected with the keypad for the first time, a long

series of short beeps plus 2 final short confirmation beeps are produced, to indicate that the

lock has been recognized.

In this mode:

•lock can be simply opened by pressing the button 1. When the bolt is open, the output

connector BAT is enabled;

•only the following options are allowed: Battery Test, Test mode, Date format,

Time and date setting and Configuration selection;

•time and date must be set before the usage otherwise a long beep is produced at every

opening.

WARNING: time and date values can be also entered in pre-setup mode, but only after

selecting the Date format.

Through the keypad, the lock can be set according one among the 80 different configurations,

involving the number of users, the dual mode opening and the Manager management. The PC

is not necessary!

Pulse PRO can be also used with analog locks such as EM2020, EM2050, EM3520, EM3520/S,

EM3550, EM3550/S and EM6050. If the keypad is connected with one of these locks, the

options enabled are only the ones corresponding to the locks properties, hence please refer to

the relative user manuals.

User properties and default codes

Users can be set for opening by entering their own combination created as:

- ID + numeric code;

- ID + numeric code + Dallas key;

- ID + Dallas key.

When programming, it is also possible to set a dual mode opening. Thus, it is necessary to

enter the combinations of the two users involved, in order to open the lock.

Default combinations used are of type ID + numeric code:

1st Master: 80-123456.

2nd Master: 81-123456 (available only for some configurations).

Master can change his code, change a configuration in dual mode with the Manager and set

also the time and date. In some configurations, Master can also manage Manager codes.

1st Manager: 60-123456

2nd Manager: 61-123456 (available only for some configurations).

Manager can perform openings, change his own code, change a configuration in dual mode

with Master, manage all the standard and override users, set a time delay, check a user

configuration and download the lock events. Manager cannot manage the Master code.

IU_PulsePro_08 9 di 26

User instructions

Pulse PRO

Users from 01 to 59: 01-010101, 02-020202 and so on. They always open with time delay if

set.

Override users: depending on the configuration selected, the number of override users can be

from one (10-101010) to 10 max. (from 50-505050 to 59-595959). They always open without

time delay.

ERC code (Emergency Rescue Code) is always built as ID + 8 digits.

1st ERC, random code provided by Tecnosicurezza: 98-98989898.

2nd ERC, random code provided by Tecnosicurezza: 99-99999999.

This user manual describes the standard programming. According such programming and

unless different requests while ordering the product, an opening can be performed by

entering single users codes (no dual mode) and without time delay. Thus, the user manual

must be adapted according the configuration selected.

It is strongly recommended to change the default codes before using the lock.

Overview functions

Lock opening

After entering an opening code, it is possible to open the lock within 3 seconds. It’s no

necessary instead with motorized locks: in this case indeed, the motor moves the bolt which

remains in opening position for about 8 seconds before returning in closing position. In the

manual closing version instead, the bolt can be closed by pressing key for few seconds.

Penalty

Four consecutive wrong codes initiate a four minutes penalty time. During this period, the LED

flashes once every 10s. Each time a key is pressed, a long beep is produced and no operation is

allowed.

Time Delay

Programmable time delay in between 0 and 99 minutes. Programmable open window in

between 1 and 19 minutes.

Dallas Keys

During the installation (function 1), a Dallas key (model 1982, 1990 or 1971) can be associated

to a user or a Manager (no Master) by simply placing it in the Dallas reader after entering the

ID and related code. The user is then identified by a combination built as ID + numeric code +

Dallas key. Multiple Dallas keys with same ID, can be programmed through PC and setup

software, in order to be used for particular applications. Please refer to the user manual

IU_PulsePRO_setup_XX for further information or contact Tecnosicurezza.

10 di 26 IU_PulsePro_08

User instructions

Pulse PRO

Power supply

Lock can be powered with:

•an ALKALINE 9V battery located in the battery compartement below the keypad;

•an internal battery box provided by Tecnosicurezza (6 ALKALINE 1.5 batteries);

•A power adapter (ref. N1212) with power supply interface (ref. T6005/W or T6005)

both provided by Tecnosicurezza.

Low battery warning

A series of multiple beeps indicates a low battery level which needs immediate replacing.

Audit

The lock is able to save the last 5500 operations with time, date, user and operations

description.

Users Status

The current status of the user can be checked through the function 7 when using the keypad.

IMPORTANT

Some options/characteristics reported in this user manual, can only be used if previously

enabled through the setup software. Thus, please refer to the user manual

IU_PulsePRO_setup_XX.

Please contact Tecnosicurezza for further information.

Lock opening

Pre-setup mode

Press to open the lock. 2 short beeps are produced.

Open the lock within 3 seconds.

Manager and standard users

Enter an opening combination. 2 short beeps are produced.

Open the lock within 3 seconds.

If a time delay is programmed, a short beep is produced and the led

flashes once every 2 seconds.

Press to stop the delay counting.

The opening window is indicated by a flashing and a short beep

alternating at 1 second intervals.

Autres manuels pour Pulse Pro

Table des matières

Autres manuels Tecnosicurezza Verrouillage

Tecnosicurezza

Tecnosicurezza Pulse Pro Manuel utilisateur

Tecnosicurezza

Tecnosicurezza TechMaster Manuel utilisateur

Tecnosicurezza

Tecnosicurezza AuditLine T6530/DL Manuel utilisateur

Tecnosicurezza

Tecnosicurezza T6530/DL Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniRotoboIt UR4020 Guide de l'utilisateur

Tecnosicurezza

Tecnosicurezza Pulse Pro T6630/GRP Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniTech T52 Series Manuel utilisateur

Tecnosicurezza

Tecnosicurezza KL3909 Instructions d'installation

Tecnosicurezza

Tecnosicurezza MiniTech Manuel utilisateur

Tecnosicurezza

Tecnosicurezza TechMaster Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniTech Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniTech TSMINI-4 Manuel

Tecnosicurezza

Tecnosicurezza DigiTech Manuel utilisateur

Tecnosicurezza

Tecnosicurezza TechMaster Manuel utilisateur

Tecnosicurezza

Tecnosicurezza T9510/BR Manuel utilisateur

Tecnosicurezza

Tecnosicurezza Pulse Manuel utilisateur

Tecnosicurezza

Tecnosicurezza Pulse Pro Manuel utilisateur

Tecnosicurezza

Tecnosicurezza DigiTech Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniTech Manuel utilisateur

Tecnosicurezza

Tecnosicurezza MiniTech Instructions de fonctionnement

Tecnosicurezza

Tecnosicurezza StraightBolt EM3520 Manuel utilisateur

Tecnosicurezza

Tecnosicurezza TechMaster Manuel utilisateur

Tecnosicurezza

Tecnosicurezza Pulse Manuel utilisateur

Tecnosicurezza

Tecnosicurezza DigiTech Series Manuel utilisateur

Manuels Verrouillage populaires d'autres marques

Magic

Magic 105 Manuel utilisateur

Gantner

Gantner GAT NET.Lock 7020 System Guide rapide

Wittkopp

Wittkopp Insys 7202 Manuel utilisateur

Dorma

Dorma Studio Classic Manuel utilisateur

Securam

Securam ECSL-601 Manuel utilisateur

Sudhaus

Sudhaus 3003 Manuel utilisateur

Safety 1st

Safety 1st 48517 Manuel utilisateur

Pado

Pado FDS-10 Manuel utilisateur

Esco

Esco systeQ Series Manuel utilisateur

COMPX

COMPX National D8951 Manuel utilisateur

secureo

secureo Key Box Manuel utilisateur

Stock Loks

Stock Loks C8713 Manuel utilisateur

COMPX

COMPX 1T-058 Manuel du propriétaire

Auslock

Auslock T11 Manuel utilisateur

ELCOM

ELCOM 7205 Manuel utilisateur

Stealth SAFES

Stealth SAFES ShadowVault Manuel utilisateur

Knox

Knox KeySecure 5 Manuel utilisateur

Kwikset

Kwikset 48334/01 Manuel utilisateur
