TechniSat TECHNISTAR S6 Guide d'installation et d'utilisation

Please aim the remote control

toward the decoder and operate slowly.

If the decoder fails to respond properly,

we suggest to replace the existing set

of batteries with new ones.

How to re-tune to the new frequency of JSTV HD

TechniSat TECHNISTAR S6

Our frequency has been updated.

If you have a TechniSatTECHNISTARS6, please follow the instructionsbelow to add JSTV HD channels to your decoder.

Number keys

Yellow

Green

Arrow

OPT

＜＜Buttons you need＞＞

If your decoder is currently connected to the TV with a SCART cable, connecting with a HDMI cable will allow you to watch JSTV with a higher resolution.

Please note that changing cables means you need to choose a different TV input channel such as HDMI 1.

Please turn on the power of your TV and decoder, making sure that itis set up so you can watch JSTV as usual.

Press the Menu button on your remote control of TechniSat TECHNISTAR S6 to show the Main menu

on your screen.

In the Main menu, check ‘Channel search’ is highlightedwhite and press the OK button. If another

option is highlighted, use the arrow buttons on your remote control to move the cursor to the top to select

‘Channel search’.

*Main menu doesn’t appear?

•Chances are the wires aren't fully inserted. Please make sure that the cable that is connecting decoder and TV

are inserted firmly on both TV and decoder.

•Or, please check if the right input channel is selected on your TV as you normally use to watch JSTV.

How to tune

（This process will take approximately 10 minutes)

4Use the arrow buttons to select ‘Transponder’ and press the OK button.

Enter the channel information for JSTV HD using the buttons on your remote control.

Satellite：Hot Bird 13.0E ※Not able to change this setting

Transponder freq：11179 ※Use number keys to enter

Polarisation：h ※Press OK and select ‘h’.

Symbol rate：27500 ※Use number keys to enter

Search mode：All channels Press OK and select【All channels】

Inthis screen menu, you can check the status of your satellite reception. For the signal quality,

it is recommendedto havea valueas closeto10db. Incase the qualityislower than8 and the

signal qualityis weakened due to bad weather, please consultwith your technician.

6Using the down arrow button, move the cursor to ‘Start Search’. The channel search will begin when you

press the OK button.

After a few seconds, the search ends and the number of channels newly found will appear.

On this picture, 2 new channels were found.

To register the channels, select ‘Sort manually – TV’ and press the OK button.

On the left of the screen, the search results will appear and to the right, your TV list will appear.

(Sometimes, other new channels will appear on the left side alongside JSTV HD channels.)

Select JSTV 1 HD and add the channel to your TV list on the right by pressing the yellow button

on your remote control. The channel will appear at the bottom of your list on the right side of the screen.

Repeat and add JSTV 2 HD to the TV list.

The new JSTV HD channel numbers will appear on the left side of the channel names. Note down the

channel numbers. In the picture below, the JSTV HD channels are added as No.11 and No.12.

Press Menu button to save your settings and exit Main menu. Press the channel numbers you have

noted in “Step 11”, and please make sure if JSTV HD are shown.

You have successfully added the new channels!

Now you can edit the channels followingthe instruction below
