technetix AIMA-FPAS Manuel d'exploitation
AIMA-FPAS
RF FORWARD
PATH AMPLIFIER-
STANDARD
Online
Email: customer.service.[email protected]
Website: technetix.com
2018-08/EN V2
Technetix Group Limited
Product user manual
2018-08/EN V2
Product user manual
AIMA-FPAS
Technetix Group Limited
Contents
1 About this manual .....................................................................................................................................................1
1.1 Chapter overview.........................................................................................................................................................................................1
1.2 Related documentation.............................................................................................................................................................................1
1.3 Document conventions.............................................................................................................................................................................1
1.4 Technical support........................................................................................................................................................................................1
2 Precautions.................................................................................................................................................................2
3 Overview.....................................................................................................................................................................3
3.1 Product description ....................................................................................................................................................................................3
3.2 Product key features.................................................................................................................................................................................3
3.3 Specifications..............................................................................................................................................................................................4
3.3.1 Block diagram.................................................................................................................................................................................5
3.4 Order details................................................................................................................................................................................................6
4 Module characteristics .............................................................................................................................................6
4.1 Module appearance and port layout ....................................................................................................................................................6
4.1.1 Overview............................................................................................................................................................................................6
4.1.2 FPAS-S Front panel layout..........................................................................................................................................................7
4.1.3 FPAS-S Rear panel layout...........................................................................................................................................................8
4.1.4 FPAS-D Front panel layout .........................................................................................................................................................7
4.1.5 FPAS-D Rear panel layout...........................................................................................................................................................8
5 Installation ..................................................................................................................................................................9
5.1 Preparatory work for installation ............................................................................................................................................................9
5.2 Unpacking....................................................................................................................................................................................................9
5.3 Module installation ....................................................................................................................................................................................10
5.4 Check module LEDs .................................................................................................................................................................................11
5.5 Test the RF input signal............................................................................................................................................................................11
6 Module configuration & alarm setup .....................................................................................................................12
6.1 Port configuration screen .........................................................................................................................................................................12
6.2 Alarms monitoring .....................................................................................................................................................................................14
6.2.1 Alarm status pages.......................................................................................................................................................................14
2018-08/EN V2
Product user manual
AIMA-FPAS
Technetix Group Limited
6.2.2 Module operating voltage and temperature alarm ..........................................................................................................15
6.2.3 Module port alarms .....................................................................................................................................................................16
6.2.4 Alarm monitoring configuration...............................................................................................................................................17
6.2.5 Input/Output status monitoring ...............................................................................................................................................18
6.3 Logs management.....................................................................................................................................................................................19
6.4 Device upgrade..........................................................................................................................................................................................20
6.5 Restoring factory defaults .......................................................................................................................................................................21
6.6 Reboot...........................................................................................................................................................................................................23
7 Troubleshooting.........................................................................................................................................................24
Appendix A: Default alarm limit settings......................................................................................................................25
Appendix B: Factory default settings............................................................................................................................25
12018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
1 About this manual
1.1 Chapter overview
1. About this manual: Preface
2. Precautions
3. Overview: Application module overview, including the module features, technical specifications, and
ordering information.
4. Module characteristics: The appearance of the equipment, port and introduction of other components
5. Installation: Installation procedure
6. Module configuration & alarms: Web management configuration instructions.
7. Troubleshooting
8. Product warranty
9. Declaration of conformity.
10. Appendix A: Default alarm limit parameters
11. Appendix B: Factory default settings
1.2 Related documentation
The following documents may be used in conjunction with this manual:
■AIMA3000 - Product user manual
■AIMA ASMM - Product user manual
■AIMA3000 NMS web management system product user manual
■NMS3-EPSM - Basic inventory management
■NMS3-EPSM - Basic alarm management
■NMS3-EPSM - Basic system management
■NMS3-EPSM - Basic template management
1.3 Document conventions
Before you use the manual, please familiarise yourself with the format used in this manual.
‘*’Asterisk: Points marked with an asterisk means there is a corresponding note on the page.
1.4 Technical Support
If you need help in the process of setting up and maintaining an FPAS, please contact Technetix's technical
support sta:
Europe:
Technetix BV
Kazemat 5
NL-3905 NR Veenendaal
P.O. Box 385
NL-3900 AJ Veenendaal
The Netherlands
Phone: +31 318 58 59 59
Email: customer.service.[email protected]
22018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
2 Precautions
WARNING!
This equipment is intended for indoor applications. To prevent fire or electrical shock, or
damage to the equipment, do not expose units to water or moisture.
■You should carefully read and thoroughly understand the contents of the manual before installing
and using this equipment.
■At any time, there may be dangerous voltage inside the device.
■DO NOT power up before the cover and the panels of the equipment are installed and the
enclosure is closed.
Cleaning
Only use a damp cloth to clean the front panel. Use a soft dry cloth to clean the top of the unit.
DO NOT use any spray cleaners or chemicals of any kind.
Outage or overload requiring service and repairs
Unplug the unit and refer the servicing to qualified service personnel only.
Servicing and repairs
DO NOT attempt to service this unit yourself. Refer all servicing needs to qualified service personnel only.
32018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
3 Overview
3.1 About the Product
The RF Forward Path Amplifier - Standard (FPAS) is designed to plug into the latest generation of Advanced Intelligent
Multi-services Access platforms - AIMA3000.
The FPAS accepts forward-path RF signals from 45 MHz to 1218 MHz through the RF input port. The module provides an
adjustable gain of 20 dB with a single output port.
Electronic gain and slope controls allow the module to be customised for many situations.
The forward-path version provides Automatic Gain Control (AGC). The FPAS can also be conveniently monitored and
controlled through a computer connected to one of the Ethernet ports via the ASMM module.
All module settings are retained in non-volatile memory to ensure trouble-free operation. Bulk updating, automatic uploading
and downloading of configuration files can be done when using the NMSE web-based management system.
3.2 Product Key Features
■Plug-and-play AIMA3000 platform module
■Forward-path version (45 MHz to 1000 MHz) supports PAL, CENELEC, and NTSC up to 127 channels
■Supports both analog and digital transmissions
■High linearity, superior low noise profile and minimal distortion
■Automatic gain control (AGC) or manual gain control (MGC)
■Electronic gain and slope control
■Configurable alarm thresholds at a customer’s request
■Alarm monitoring through the NMSE and the ASMM’s Web Interface
■Broadband GaAs amplifier technology
■Remote firmware upgrade and auto upload/download of configuration files through the ASMM web interface or using
the NMSE
■Bulk firmware updates through the NMSE
■FCC, CE and RCM(1) compliant
(1) See Declaration of Conformity for current status.
42018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
3.3 Specifications
RF performance
RF bandwidth 45 - 1218 MHz
RF flatness ± 0.75 dB
Noise Figure (NF) ≤ 9 dB
RF Input level 10 dBmV per channel
RF Output level 40 dBmV per channel (rating)
Maximum 30 dB
Minimum gain 10 dB
Gain Adjustment range 0 dB to 10 dB (input gain control)
0 dB to 10 dB (output gain control)
Slope adjustment range 0 dB to 9 dB
AGC range (max) 10 dB
AGC accuracy ±0.5 dB over AGC range
RF impedance 75 Ω
RF return loss > 16 dB
RF test point relative to RF output port -20 ± 1 dB
RF connectors Single: 2 x GSK-type female
Dual: 4 x GSK-type female
RF test points 2 x mini-SMB
Alarms and status Front-panel LEDS, SNMP traps
Path isolation > 65 dB
Link Performance (1)
CNR > 60 dB
CSO > 75 dB
CTB > 75 dB
Notes:
(1) Loaded with 77ch NTSC, RF input=10 dBmV (70 dBuV), Gain=30 dB
General
Power supply Powered via AIMA3000 backplane
Power consumption Single: < 10.6 W
Dual: < 24 W
Operating temperature -5 - 55°C
Operating humidity 90% (Non-condensing)
Storage temperature -25 - 70°C
Storage humidity 90% (non-condensing)
Dimensions (W*D*H) 24.6 * 410 * 152.5 mm
Weight Single: 0.88 kg
Dual: 0.98 kg
Supported network management options NMSE or through ASMM’s Web interface
52018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
3.3.1 Block Diagram
Figure 3-1 Block diagram FPAS-S
Figure 3-2 block diagram FPAS-D
Table 3-1 FPAS-S block diagram glossary
Parameters Glossary RF
INPUT RF input
ATT Attenuator
TP RF IN -20 dB RF -20 dB input test point
SLOPE Slope control
RF OUTPUT RF output
TP RF OUT -20 dB RF -20 dB output test point
Input gain Input gain
62018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
3.4 Order details
A-FPAS-[Y]-[Z] Forward-Path Amplifier - Standard
Options:
Y Ports
S Single
D Dual
Z Bandwidth
1G 45 - 1000 MHz (Standard)
12 45 - 1218 MHz
Parameters Glossary RF
Output gain Output gain
TO BACKPLANE AND COMMS Data bus
CPU Central processing unit
Parameters Glossary
RF INPUT1 RF1 input
RF INPUT2 RF2 input
ATT Attenuator
TP RF IN -20 dB RF -20 dB input test point
SLOPE Slope control
RF1 OUTPUT RF1 output
RF2 OUTPUT1 RF2 output
TP RF OUT -20 dB RF -20 dB output test point
Input Gain Input gain
Output Gain Output gain
TO BACK PLANE AND COMMS Data bus
CPU Central processing unit
Table 3-2 FPAS-D block diagram glossary
72018-08/EN V2 Technetix Group Limited
Product user manual
AIMA-FPAS
AIMA-FPAS Product User Manual
Pacific Broadband Networks 15 January 2015 Page 11 of 36
4 Module Characteristics
4.1 Module Appearance and Port Layout
4.1.1 Overview
Figure 4-1 Module Appearance
Front Panel
Rear Panel
Figure 4-1 module appearance
4 Module characteristics
4.1 Module appearance and port layout
4.1.1 Overview
