Technaxx®
Video Sport Sunglasses Full HD 1080P TX–25
User Manual
Declaration of Conformity: www.technaxx.de/ (in bottom bar “Konformitätserklärung”)
Before using the device the first time, read the user manual carefully.
Features
Real time video recording with sound in brilliant image quality
HD camera lens wth 142° wide-angle and 5 Megapixel CMOS sensor
Video resolution Full HD 1920x1080P with 25fps, AVI format
Photo resolution interpolated 15M pixel 4480 x 3360, JPEG format
Interchangeable sun protection lenses UV400 in 3 colours
Built-in rechargeable Lithium-Ion-Polymer battery 400mAh
Supports MicroSD memory cards up to 32GB (Class 10 is recommended)
User friendly one-button operation
Easy connection with PC/Notebook, no driver needed
Elegant, stylish, sporty design
Package Contents: Video Sport Sunglasses Full HD 1080P TX–25, USB cable,
Power adaptor 5V DC 1A, Protective case with zipper and hand loop, 1 pair of dark
grey/yellow/blue lenses, Cleaning cloth, User Manual
Structure
Changing of the glasses
Changing of the glasses is very easy. Hold the center of a glass with clean fingers and
klick it out of the frame, first one side, then the other. Please do it carefully, because
the little pins on both side of the glass could break when handle the glass too roughly.
Also handle the glasses themselves with care, otherwise scatches could appear.
Charging the built-in battery
Connect the device to a USB port on your PC or plug it into AC power with the
included power adapter. While charging the red LED is blinking constantly. When the
red LED turns to a solid red light the battery is fully charged. Charging time of 4 hours
is recommended.
Attention: Video recording or taking pictures only is possible, when
a MicroSD* card is inserted into the MicroSD card slot.
[* The card is not included in delivery!]
Formating a MicroSD card – Important Hints !
Insert a MicroSD* card and turn on device. In case the micro card is not (!) compatible
with the system, the red LED turns on but blinks very slowing for 20 seconds. That is a
kind of warning system that you have to format the MicroSD card before using.
Attention: When formatting a MicroSD card, all information on the card
will be deleted. Therefore please save them before formatting!
Press the ON/OFF button, then the red LED flashes very fast to format the card. After
formatting, you can start other operations. If there is no action during a time period of
20 seconds, the device will shut down automatically.
Start to use the sunglasses
(1) Insert a MicroSD card (max. 32GB, recommended is Class 10 high speed or
above).
(2) Press the button No. 1 (ON-OFF/Recording/Play) for a few seconds, until the red
LED is on to start up the device.
(3) Then the red LED is on and starts blinking. The device starts automatically
recording a video when the MicroSD card is Windows FAT32 formatted. Otherwise
the device turns off after 3–5 seconds!
(4) To power OFF the device, press and hold down the ON/OFF button for a few
seconds, until the red LED turns off.
Recording a Video
(1) Press the ON/OFF button and the device turns on and starts BLINKING RED. You
are now recording a Video.
(2) Press the ON/OFF button again to stop the recording. The RED LED now is
SOLID RED. When the LED is SOLID RED press the button once to take a picture or
you can hold button for 3 seconds and release to start recording a video again.
(3) Every 10 minutes the device saves one file automatically.
(4) If no operation in standby status in 2 minutes, the device will shut down
automatically.
Taking Photos
To take photos when device in standby mode, press the ON/OFF button once to take
one photo. The red LED blinks one time to indicate it is capturing and saving your
photo, then the red LED returns to solid red light.
Viewing files on a computer
To view your files on a computer, simply connect the device with the enclosed USB
cable to a USB port of a computer.
It will connect as a removable drive, and depending on the settings on your PC, it
may automatically notify that a new hardware has been detected. If so, select
Open Folder to View Files.
If it is not (!) automatically detected, click Start on your desktop. Select “My Computer”
if you are using Windows, or “Computer” if your are using Windows Vista or WIN7.
The device should be listed as a Removable Disk under the “Devices with Removable
Storage” section.
Using the device as a Webcam
To use the device as a webcam, you first have to take out the MicroSD card from the
MicroSD card slot and plug the device into a computer’s USB port. Then search for
the “Standard Camera“ under “My Computer” or search under your Skype “Video
setting”. If the connection is correct then a webcam screen will appear on your
computer. No audio recording is possible!
Setting Time and Date
(1) In standby status, connect the device to a computer with the enclosed USB cable
until the drive appears.
(2) Click on the drive into the root directory.
(3) In the root directory create a time.txt document file, input to the current date and
time with the format of: year.month.day hour:minute:second
Setting Time and Date: (Example: 2013.03.14 05:50:01 or
year month day hour:minute:second 2013 03 14 05:50:01)
(4) To delete the time stamp from video and photo, input a date and time which is NOT
the actual date and time.
Example: today is the 2014.03.10 10:00:00 and you put in – as an example –
2012.01.26 20:30:01, then the date/time stamp will be deleted from video and photo at
next recording.
Setting video resolution
(1) In standby status, connect the device to computer via USB cable until the drive
appears, click on the drive into the root directory.
(2) In the root directory create a size.txt document file, input a number “1” to get the
video resolution of 1280x720P with 50fps, input a number “0” to get the video
resolution of 1920x1080P in 25fps, input number “2” to get the video resolution of
1440x1080P with 30fps.
The system will be default with 1440x1080P 30fps specifications.
Viewing a video
If you plan on viewing your files on your computer, we suggest using VLC Player. The
most recent version can be downloaded at no cost from http://www.videolan.org.
Troubleshooting
Q: The device seems to have frozen and don’t reacting when any buttons are pressed.
A: This usually occurs if the device receives too many commands in too short a time.
To reset the device, press the ON/OFF button for a few seconds until the device will
turn OFF.
Q: The device’s red LED is blinking faster for 10 seconds and then it turns off
automatically. The device goes into stand-by mode.
A: It occurs when the MicroSD card is full. Store the information to other storage
media and empty your current MicroSD card.
Q: The device’s red LED remains shining for 10 seconds and then it turns off
automatically. The device goes into stand-by mode.
A: It occurs when no MicroSD card was inserted. Insert a MicroSD card (up to 32GB).
Q: The device’s red LED is blinking fast for 4 seconds and then it turns off
automatically. The device goes into stand-by mode. (If no battery power is left, the
device will shut down automatically.)
A: The device is in low battery status. Charge the battery by using the USB cable or
the power charger.
Q: When playing back my video, I can hear audio, but cannot see any picture.
A: This most often occurs if your computer’s media player has trouble with your files.
Try using VLC player, which can be downloaded for free at http://www.videolan.org.
Technical Specifications
Lens and Sensor
HD wide angle 142° and 5 megapixels CMOS sensor
Video resolution
Full HD 1920x1080P with 25fps, AVI format
Optional
Video resolutions
1440x1080P 30fps, AVI format
720P 1280x720P 50fps, AVI format
Full HD 1920x1080P 25fps, AVI format
Photo resolution
15M pixel 4480 x 3360, JPEG format
Audio
Pure audio recording is not possible, only with video recording
Memory card
MicroSD* up to 32GB (Class 10 is recommended)
[*not included in delivery]
Battery
Built-in rechargeable lithium-ion-polymer battery 400mAh
Battery charging time
~ 1,5 hour (chargeable via USB connection)
Battery playing time
Video recording ~ 1 hour
Frame material
ABS + PC
USB
MINI 8Pin
Power adapter
5V DC 1A
Power consumption
< 0,8 W
Operating systems
Windows 8.1, 8, 7, Vista, XP and compatible with MAC
Media Player Software
Windows Media Player, Real Player, Stormcodec
Weight / Dimensions
56g / (L) 16,5 x (W) 7,7 (folded bows) x (H) 4,8cm
Security and Disposal Hints for Batteries: Hold children off batteries. When a child swallowed a battery go to a doctors place
or bring the child into a hospital promptly! Look for the right polarity (+) and (--) of batteries! Always change all batteries. Never
use old and new batteries or batteries of different types together. Never short, open, deform or load up batteries! Risk of injury!
Never throw batteries into fire! Risk of explosion!
Hints for Environment Protection: Packages materials are raw materials and can be recycled. Do not disposal old
devices or batteries into the domestic waste. Cleaning: Protect the device from contamination and pollution (use a
clean drapery). Avoid using rough, coarse-grained materials/solvents/other aggressive cleaner. Wipe the cleaned
device. Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry.
Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
