TARGUS MOBILE DOCKING

STATION WITH VIDEO

Introduction

Congratulations on your purchase of the Targus Mobile

Docking Station with Video. This portable expansion

module allows you to connect through a single USB

connection up to 4 USB devices, monitor, network

(Ethernet/LAN) connection, speakers, microphone and a

serial device.

The docking station also offers Targus Always On

technology, Targus Power Port providing twice the USB

spec for high power devices, and USB ports that are widely

spaced for larger adapters. Targus Always ON provides

power to the USB ports even when the notebook is shut-

down, disconnected from the docking station or in

hibernate/stand-by mode. This allows USB devices that

charge via the USB port to keep charging under any

circumstance.

Features

Heat dissipation by natural convection:

Place the back edge of your laptop on the rubber pads of

the Docking Station. Most laptops dissipate heat through

the bottom and the more air that’s allowed to flow under the

bottom, the better chance that heat will dissipate by natural

convection.

Comfort

The raised platform provides a more comfortable position

for hands and increased airflow for better cooling.

Targus Mobile Docking Station with Video

The Docking Station provides the following ports:

• 15-pin VGA (Supports 1024 x 768 at 16 bit colour)

• Two 3.5 mm Audio: (1) stereo out and (1) microphone in

• RS232 Serial

• RJ-45 Ethernet 10/100

•TwoUSB2.0(White)

• Two USB Power Ports (Black) - Providing up to 1Amp

Package Contents

In addition to this user’s guide, the package contains:

• Targus Mobile Docking Station with Video

• High-speed USB 2.0 upstream cable

• Driver software CD

• AC power adapter (Required)

System Requirements

Hardware

• PC with an Intel®Pentium®processor or equivalent

•CD-ROMdrive

• USB version 2.0 port

• AC power source (AC adapter required)

NOTE: When connected to a USB version 1.1 port on

your computer, the Docking Station’s performance

level will be less than optimal and the video port will

not function properly. For best results, connect it to

a USB version 2.0 port.

Operating System

•Windows

®2000 - Service Pack 2 or greater

•Windows

® XP - Service Pack 1 or greater

Targus Mobile Docking Station with Video

NOTE: To download latest service packs, please visit

your computer manufacturer’s website or Microsoft’s

download centre:

http://support.microsoft.com/default.aspx?scid=fh%3BEN-

US%3Bsp

Installing the Device and Drivers

To use the Targus Docking Station, you must first install the

driver onto your computer. Connect the docking station to

your computer and Windows plug-and-play will install the

hardware drivers for each port.

WARNING: You must install the Docking Station

software BEFORE connecting it to your computer.

Otherwise, the Docking Station will not work

properly.

Installing the Docking Station Driver

Installing the docking station driver enables your operating

system to recognize the docking station and its ports once

it’s connected.

1 Turn on your computer.

2 Insert the driver software CD into your computer’s CD-

ROM drive.

3 If setup does not begin automatically, click Start, Run,

then enter D:\Setup.exe (where D: is the path of your

CD-ROM drive) and then click OK.

4 Follow any on-screen instructions to complete the

installation.

5ClickFinish and restart your computer when prompted.

Targus Mobile Docking Station with Video

Connecting the Docking Station to Your

Computer

After installing the docking station software, you are ready

to connect the docking station to your computer. To do this:

1 Connect the supplied AC power adapter to the AC

power jack on the docking station.

2 Connect one end of the USB cable to the docking

station and the other end into an available USB 2.0 port

on your computer.

NOTE: The docking station will not function properly

without the AC adapter plugged into an AC outlet.

Do not connect any devices to the docking station

until the installation is completed.

Installing the Default Device Drivers

Once you connect the docking station to your computer,

the default drivers begin installing for each of the ports.

Some hardware devices may prompt you to install the

drivers.

To install the drivers:

1 Select Install the software automatically (Recom-

mended) and click Next.

The Found New Hardware Wizard program begins

installing the hardware drivers.

The Completing the Found New Hardware Wizard

screen appears.

2ClickFinish and repeat as needed for each device.

3 Restart your computer.
