Eddy Serial

User Guide

Ver 2.1.1.1

2010. 06.25

Revision History

Revision Date Document Version Pages Description

Feb-5-2009 2.1.0.1 All Initial release by shlee

Sep-10-2009 2.1.0.2 4,5,6 Added WiFi

Nov-11-2009 2.1.0.3 2,3,5 Append Eddy-S4M

Jun-06-2010 2.1.1.1 All Open Linux Version

Added Eddy-BT

Table of Contents

Chapter 1. Introduction ...............................................................................................................................5

1.1 About this manual....................................................................................................................................................5

1.2 Who should read this manual.....................................................................................................................................5

1.3 Contents.................................................................................................................................................................5

1.4 Eddy Documents ..................................................................................................................................................... 6

1.5 Technical Support .....................................................................................................................................................7

Chapter 2. Getting Started...........................................................................................................................8

2.1 Overview............................................................................................................................................................... 8

2.2 Eddy-CPU v2.1 ........................................................................................................................................................ 8

2.3 Eddy-DK v2.1 (Development Kit)................................................................................................................................ 9

2.4 Eddy-S4M v2.1.......................................................................................................................................................11

2.5 Eddy-S4M-DK v2.1 (Development Kit) ........................................................................................................................13

2.6 Eddy-S4M-JiG v2.1 (Testing Board)........................................................................................................................... 14

2.7 Eddy-WiFi v 2.1......................................................................................................................................................15

2.8 Eddy-BT v2.1..........................................................................................................................................................17

2.9 Eddy Software Architecture...................................................................................................................................... 18

2.10 Main Features....................................................................................................................................................... 18

2.11 Applications............................................................................................................................................................19

Chapter 3. Hardware Description.................................................................................................................. 20

3.1 Eddy-CPU .............................................................................................................................................................20

3.2 Eddy-DK v2.1 .........................................................................................................................................................21

3.3 Eddy-S4M v2.1...................................................................................................................................................... 23

3.4 Eddy-S4M-DK v2.1.................................................................................................................................................24

3.5 Eddy-S4M-JIG v2.1................................................................................................................................................. 25

3.6 Eddy WiFi v2.1....................................................................................................................................................... 26

3.7 Eddy BT v2.1.........................................................................................................................................................28

Chapter 4. Integration............................................................................................................................... 30

4.1 Connection Guide....................................................................................................................................................30

4.2 First-time Bootup ..................................................................................................................................................30

4.3 Connecting to Eddy with IP address...........................................................................................................................30

4.4 Using MCI slot & USB Host Port ............................................................................................................................... 33

Chapter 5. Configuration via Web..................................................................................................................36

5.1 Connection............................................................................................................................................................ 36

5.2 Setup Menu.......................................................................................................................................................... 37

5.3 Network Settings...................................................................................................................................................39

5.4 Serial Settings....................................................................................................................................................... 41

5.5

Wireless Settings ...................................................................................................................................................44

5.6 Peripheral Settings .................................................................................................................................................47

5.7 DIO Settings..........................................................................................................................................................50

5.8 SNMP Settings........................................................................................................................................................51

5.9 Change Password ................................................................................................................................................... 52

5.10 Update Firmware ................................................................................................................................................... 53

5.11 Factory Default...................................................................................................................................................... 54

5.12 Save & Reboot .....................................................................................................................................................54

Chapter 6. Configuration via Telnet................................................................................................................56

6.1 Connection............................................................................................................................................................ 56

6.2 View commands..................................................................................................................................................... 56

6.3 Network commands................................................................................................................................................ 57

6.4 WiFi commands...................................................................................................................................................... 59

6.5 Serial Commands....................................................................................................................................................60

6.6 Username/Password Commands................................................................................................................................. 61

6.7 System Commands.................................................................................................................................................. 62

Chapter 7. apendix ...................................................................................................................................63

7.1 Firmware Updates via FTP........................................................................................................................................ 63

7.2 Ordering Information...............................................................................................................................................64

7.3 FCC Statement .......................................................................................................................................................64

Eddy User's Guide

Chapter 1. Introduction

Eddy, SystemBase Embedded Device Server Module, is an optimized minimal CPU module for developing an industrial embedded device. This manual introduces

general factions for the Eddy.

1.1 About this manual

This manual guides that users are able to develop Eddy for a device server including the function that transfers from serial data to LAN. Setting Eddy’s

configurations, status monitoring, firmware update, and other administration work are also included, H/W level integration and S/W setting information can also

be found.

1.2 Who should read this manual

This guide is designed for Eddy users and administrators. It is strongly recommended that anyone trying to apply, use, and maintain Eddy read this document.

It will be a great starting point for any administrator who wants to easily monitor and control Eddy and its connected devices.

1.3 Contents

Chapter 1. Introduction is a preface with general information and introductory notices.

Chapter 2. Getting Started gives a brief introduction to Eddy series, including features and applications.

Chapter 3. Hardware Descriptions explains the layout and pin specifications with block diagram and drawings.

Chapter 4. Integration assists you connecting Eddy to serial and network environment. It covers first time boot-up and status check procedures.

Chapter 5. Configuration via Web provides ways to configure and to connect Eddy via web browser.

Chapter 6. Configuration via Telnet provides commands and its explanation to configure and to connect Eddy via web Telnet.

Chapter 7. Appendix provides firmware update guides and detailed technical specifications.

Eddy User's Guide

1.4 Eddy Documents

The following table summarizes documents included in the Eddy document set.

Document Description

Eddy Serial User Guide Eddy’s Configuration, and Management Information

Eddy DK Guide

Programmer’s application development guide, including in-depth approach to compiling,

linking, creating and uploading firmware

API reference is included with a list of available functions

for customized application programming

LemonIDE User Guide User manual about Eddy integrated development environment of Window/Linux based on Eclipse

Portview User Manual Guide for SystemBase device server management application Portview

COM Port Redirector

User Manual Guide for SystemBase COM Port Redirector

TestView

User Manual Guide for SystemBase test program TestView

General information on Eddy or embedded device servers can be obtained at our website at http://www.sysbas.com/. Latest documents, software and

firmware downloads are available.

Other relevant documents are as follows:

Document Description

Eddy-CPU Spec Sheet Eddy-CPU spec description

Eddy-S4M Spec Sheet Eddy-S4M spec description

Eddy-WiFi Spec Sheet Eddy-WiFi spec description

Eddy-BT Spec Sheet Eddy-BT spec description

LemonIDE Spec Sheet integrated development environment description

Eddy White Paper An introductory reading for anyone new to embedded device server, which focuses on

background, history, market environment, and technology

All documents are updated promptly, so check for the recent document updates. The contents in these documents are subject to change without a prior

notice.

Eddy User's Guide

1.5 Technical Support

You can reach our tech support by following 3 ways;

1. Visit the Eddy official community site at http://www.embeddedmodule.com and go to ‘Technical Support’ menu. FAQ and questions can be reviewed

and submitted.

2. E-mail our technical support team to tech@sysbas.com. Any kind of inquiries, requests, and comments are welcomed.

3. Call us at our customer center at 82-2-855-0501 for immediate support.

Our technical support team will kindly help you get over with the problem.

Eddy User's Guide

Chapter 2. Getting Started

Welcome to Eddy! This chapter includes Eddy series overview, main and distinctive features, package contents for each product, and application fields.

2.1 Overview

There are two categories in Eddy; Eddy-CPU module, Eddy Development Kit (DK).

Eddy-CPU modules include category of socket type Eddy-CPU and Mini PCI type Eddy-S4M.

Eddy-DK includes DK board for Eddy-CPU exclusive, JIG and DK board for Eddy-S4M exclusive.

The Eddy-CPU module includes default applications for serial and LAN communication, and supports plug-and-play features. By switching to the custom mode,

users can program any application and upload it on to the module. This application then is executed on the module. In order to write and compile

programmer’s source code, Software Development Kit (SDK) LemonIDETM is required.

SDK is included in the DK package. Please refer to Programming Guide and LemonIDETM user’s manual included in the Development Kit for detailed

information on the SDK.

SDK is not necessary for users using Eddy in default presettings.

2.2 Eddy-CPU v2.1

Eddy-CPU is an embedded module based on ATMEL AT91SAM9260-CJ processor with 32MB SDRAM, 4MB or 8MB Flash Memory, 1 Ethernet port with

10/100Mbps, 16 bit address / 8 bit data bus interface supporting external device connection, and maximum 17 programmable IO pins. Programmers can easily

implement any device drivers with referring to library type example codes and evaluation kit circuit diagrams.

User can design their own customized device using example sources and Evaluation Kit circuit.

Eddy-CPU is implemented on a small form factor (42 * 25mm) with on-board memory and integrated 10/100Mbps network interface. Developers can minimize

time and cost spent on developing application products.

Feature Type

CPU ARM926EJ-S (210 MHz)

Memory 8MB Data Flash, 32 MB SDRAM

Hardware

External I/F 19 Bit / 16 Bit Data Bus

Eddy User's Guide

Feature Type

Ethernet I/F 10/100 Base-T Auto MDI/MDIX

UARTs 4 Port, Support up to 921.6 Kbps

(1 : Full Signal, 2,3,4, : RxD, TxD, RTS, CTS only)

USB 2.0 FS 2 Host /1 Device Port, 2.0 FS (12Mbps)

ADC 4-Channel 10 Bit ADC

TWI(I2C) Master, Multi-Master and Slave Mode

SPI 8- to 16-bit Programmable Data Length

Four External Peripheral Chip Selects

GPIO Max. 56 Programmable I/O Pins

Power Input 3.3 V (200 mA Max)

Dimensions 25 x 48.5 x 6.2 mm

Weight 8.3 g

Protocol TCP, UDP, Telnet, ICMP, DHCP, TFTP, HTTP, SNMP 1&2, SSH, SSL

Ethernet 10/100Mbps MAC / PHY

Network

Network Connection Static IP, DHCP

O/S Linux Kernel 2.6.21

Mgt Tools SNMP, Web, PortView

Uploads TFTP, FTP, Web

Software

Dev Tools LemonIDE & SDK

Operating Temp -40 ~ 85 ℃

Storage Temp -60 ~ 150 ℃

Environmental

Humidity 5 ~ 95% Non-Condensing

Approvals

CE Class A,

FCC Class A,

RoHS compliant

2.3 Eddy-DK v2.1 (Development Kit)

Eddy Development Kit (Eddy DK) helps programmers to test and customize their own Eddy applications easily. The kit includes evaluation board, all necessary

connectors, and programming environment with documentations and guidelines. Please refer to Eddy DK Manual included in the Development Kit for detailed
