Thank you for purchasing this Synology product! Before setting up your new Synology NAS, please check the
package contents to verify that you have received the items below. Also, make sure to read the safety instructions
carefully to avoid harming yourself or damaging your Synology NAS.
Note: All images below are for illustrative purposes only, and may dier from the actual product.
Package Contents
Main unit x 1 AC power cord x 2
Before You Start 1
Chapter
4Chapter 1: Before You Start
Synology FS3410 at a Glance
Front
Rear
No. Article Name Location Description
1 Power Button and
Indicator
Front
1. Press to power on your Synology NAS.
2. To power o the Synology NAS, press and hold until you hear
a beep sound and the Power LED starts blinking.
2 STATUS Indicator Displays the status of the system. For more information, see
"Other LED Indicators".
3 ALERT Indicator Displays warnings regarding fan or temperature. For more
information, see "Other LED Indicators".
4 Beep O Button Press to deactivate the beep that sounds when a malfunction
occurs.
5 Drive Status Indicator Displays the status of drive. For more information, see "Other
LED Indicators".
6 Drive Tray Install drives (hard disk drives or solid state drives) here.
7 Rail Kit Release Tab Push in and hold to release your Synology NAS from the rail kit
lock.1
1For more information about the rail kit installation, please refer to the Quick Installation Guide that comes with the rail kit.
5Chapter 1: Before You Start
No. Article Name Location Description
8 PSU Fan
Rear
Disposes of excess heat and cools the PSU.
9 Power Port Connect power cord here.
10 PSU Indicator Displays the status of the power supply unit (PSU). For more
information, see "Other LED Indicators".
11 Console Port This port is reserved for manufacturing use only.
12 PCI Express
Expansion Slot Supports two PCIe x8 add-on network interface cards.
13 1GbE LAN Port Connect RJ-45 network cables here.
14 10GBase-T LAN Port Connect RJ-45 network cables here.
15 USB 3.2 Gen 1 Port Connect external drives or other USB devices to the Synology
NAS here.
16 Management Port This port is used for out-of-band management only.
17 RESET Button
1. Mode 1: Press and hold until you hear a beep sound to restore
the IP address, DNS server, and password for the admin
account to default.
2. Mode 2: Press and hold until you hear a beep, release the
button immediately, then press and hold again until you hear
three beeps to return the Synology NAS to "Not Installed"
status so that DiskStation Manager (DSM) can be reinstalled.
For detailed information on how to reset your Synology NAS,
please refer to this article.
6Chapter 1: Before You Start
System Modes and LED Indicators
System Modes and Denitions
There are 7 system modes in Synology NAS. The System modes and their denitions are as below:
System mode Denition
Powering on
Synology NAS is powering on when you press the power button or restarting when
you run operations in DSM. During the boot up process, the device also performs
hardware initialization, such as hardware reset or BIOS initialization.
Shutting down Synology NAS is shutting down as a result of pressing the power button or operation
in DSM.
DSM not ready
DSM is not ready for use. This could either be:
• Synology NAS is powered on, but DSM is not properly installed.
• Synology NAS is currently powering on and initializing services necessary for
DSM to fully function.
• The attached UPS device has insucient power; DSM stops all services to
prevent data loss (enters safe mode).
DSM is ready for use DSM is fully functioning and users can sign in.
Application
Certain packages/services (e.g., USB Copy and Find me service) while in operation
will control the actions of the LED. After the operation is complete, the LED indicator
will return to its normal state.
Powered o Synology NAS is powered o.
Identify System Modes
You can identify the system mode through the POWER and STATUS LED indicators. Please refer to below table
for more details.
System mode
LED Indicator
POWER STATUS
Blue Green Orange
Powering on Blinking O O
Shutting down Blinking Static O
DSM not ready Static Blinking O
DSM is ready for use Static Static O
Application Static Switching
Powered o O O O
7Chapter 1: Before You Start
Transitions between System Modes
To better understand the transition between system modes, please refer to below examples:
•
Powered on with no DSM installed:
Powered o > Powering on
> DSM not ready
•
Powered on with DSM installed:
Powered o > Powering on > DSM not ready > DSM is ready for use
•
Shutdown Synology NAS:
DSM is ready for use
>
Shutting down > Powered o
•
Power failure with UPS attached:
DSM is ready for use > DSM not ready (due to power failure, DSM enters safe mode) > Shutting down >
Powered o > Powering on (power has recovered, DSM will reboot) > DSM not ready > DSM is ready for use
8Chapter 1: Before You Start
Other LED Indicators
LED Indicator Color Status Description
ALERT Orange Blinking Fan failure/Over temperature
O System normal
Drive Status Indicator
(on tray)
Green Static Drive ready and idle
Blinking Accessing drive
Red Static
Locating drive
Drive deactivated by user
Port disabled1
Removing this drive will cause
system damage; this is the only drive
with DSM installed.
O No internal drive
PSU Indicator (Delta)
Green Static Power supply unit normal
Blinking Power supply unit standby
Orange Static Power supply unit failed/unplugged
O Power supply unit o
PSU Indicator (Lite-On)
Green Static Power supply unit normal
Blinking Power supply unit standby
Orange Static Power supply unit failed
O Power supply unit o
Rear 1GbE LAN
(on left side of jack)
Green
Static Network connected
Blinking Network active
O No network
Rear 1GbE LAN
(on right side of jack)
Green Static 1 Gbps connected
Orange Static 100 Mbps connected
O 10 Mbps connected/No network
Rear 10GbE LAN
(on left side of jack)
Green
Static Network connected
Blinking Network active
O No network
Rear 10GbE LAN
(on right side of jack)
Green Static 10 Gbps connected
Orange Static 1 Gbps connected
O No network
Note:
1 Please try to restart your Synology NAS or re-insert the drives, then run the HDD/SSD manufacturer's
diagnostic tool to check the health status of the drives. If you can sign in to DSM, please run the built-in
S.M.A.R.T. test to scan the drives. If the problem remains unresolved, please contact Synology Technical
Support for help.
2 If the ALERT LED continuously blinks orange, this indicates there are system errors such as fan failure,
system overheating, or volume degrade. Please sign in to DSM for detailed information.
9Chapter 1: Before You Start
Hardware Specication
Item FS3410
CPU Intel Xeon D-1541
RAM DDR4 16 GB
Compatible Drive Type 2.5" SATA SSD x 24
External Port USB 3.2 Gen 1 x 2
LAN Port
• 1GbE (RJ-45) x 4
• 10GBase-T (RJ-45) x 2
• 1GbE RJ-45 for OOB x 1
PCIe Slot Gen3 x8 slot (x8 link) x 2
Size (H x W x D) (mm)
• 88 x 482 x 724 (with server ears)
• 88 x 430.5 x 692
Weight (kg) 15.0
Agency Certication • FCC Class A • CE Class A • UKCA • BSMI Class A
• EAC • VCCI • CCC • RCM • KC • UL • RoHS Compliant
Scheduled Power On/O Yes
Wake on LAN Yes
Environment Requirement
• Line voltage: 100V to 240V AC
• Frequency: 50 / 60Hz
• Operating Temperature: 32 to 95˚F (0 to 35˚C)
• Storage Temperature: -5 to 140˚F (-20 to 60˚C)
• Relative Humidity: 5% to 95% RH
Note: Model specications are subject to change without notice. Please refer to www.synology.com for the latest information.
10 Chapter 1: Before You Start
Spare Parts
Visit www.synology.com/products/spare_parts if you need to replace system fans, disk trays, or power supply
units.
Model Name Picture Description
Disk Tray (Type R4) 2.5" Drive Tray
FAN 80*38_2 System Fan 80*80*38 mm
PSU 550W-RP Module_1 Redundant PSU Module 550W
RKS-02 Sliding rails
Optional Accessories
With Synology accessories, you can customize your Synology NAS to t dierent business environments without
worrying about compatibility and stability. Visit www.synology.com/compatibility for more information.
