Symbol P370 Manuel utilisateur

P370/470 RF Scanners

Quick Reference Guide

2 P370/470 RF Scanners

Symbol reserves the right to make changes to any product to improve reliability,

function, or design.

Symbol does not assume any product liability arising out of, or in connection with,

the application or use of any product, circuit, or application described herein.

No license is granted, either expressly or by implication, estoppel, or otherwise

under any patent right or patent, covering or relating to any combination, system,

apparatus, machine, material, method, or process in which Symbol products

might be used. An implied license exists only for equipment, circuits, and

subsystems contained in Symbol products.

Symbol and the Symbol logo are registered trademarks of Symbol Technologies,

Inc. Other product names mentioned in this manual may be trademarks or

registered trademarks of their respective companies and are hereby

acknowledged.

Symbol Technologies, Inc.

One Symbol Plaza

Holtsville, N.Y. 11742-1300

http://www.symbol.com

Warranty

For the complete Symbol hardware product warranty statement, go to:

http://www.symbol.com/warranty.

Patents

This product is covered by one or more patents. For patent information go to:

http://www.symbol.com/patents.

Quick Reference Guide 3

Introduction

The P470/370 cordless RF scanners bring new flexibility and economy to data

capture and data management in both industrial and retail operations. The

scanner communicates with your host computer through radio transmission

instead of through a cable. With the RF scanner, you are free to scan and transmit

without a physical cable, from as far away as 100 feet (30.5 meters) even without

a direct line of sight. This lets you take the scanner to where the work is, whether

on the loading dock, the plant floor, the warehouse, or the POS checkout area.

There are several versions available:

-P470: cordless retail scanner.

-P370: cordless industrial scanner.

-P370 ALR: cordless industrial ALR scanner.

This Quick Reference Guide provides basic instruction on the set up and use of

the Phaser P370/P470 RF scanners.

Refer to PL 370/470 RF Cradle Quick Reference Guide (p/n 72-38494-xx) for

information on setting up the PL 370/470 RF cradle.

To quickly get you started with your new scanner:

1. Charge the scanner in the cradle.

2. Power up the scanner.

3. Follow the Quick Startup Instructions (see page 6).

4. Use the test bar codes to ensure the scanner is working properly (see page 7).

Charging the Scanner in the Cradle

Powering Up the Scanner

To turn the scanner on, press the “Enter” key or pull the trigger. The scanner is

brought out of sleep mode and into scanning mode.

Charge Status

Indicator Light

To charge the scanner, insert the scanner into

the cradle so the nose of the scanner and tip of

the handle seat into the receptacles. The

scanner displays “UNIT CRADLED” when

properly inserted in the cradle.

The battery charges automatically. A full charge

of a depleted battery takes approximately 3-1/2

hours. The charge status indicator light on the

back of the cradle blinks then becomes solid

when the battery is fully charged.

4 P370/470 RF Scanners

Scanning

Consult the P470/P370 RF Scanners Product Reference Guide (p/n 72-38495-xx)

for programming instructions. If you need assistance, contact your local supplier

or the Symbol Support Center.

To scan:

1. Ensure the battery is charged.

2. Ensure the bar code is in the correct scanning range.

3. Aim and press the trigger. When the scanner has read the symbol:

-a beep sounds.

-the LED above the display turns green.

-the red laser turns off.

Aiming

Hold at an Angle

Do not hold the scanner directly over the bar code. Laser light reflecting directly

back into the scanner from the bar code is known as specular reflection. Specular

reflection can make decoding difficult.

The scanner can tilt up to 65° forward or back and achieve a successful decode.

Simple practice quickly shows what tolerances to work within.

Scan

Beam

1.Successful Scanning 2.Possible Specular Reflection 3.Successful Scanning

65° 65°

Scan

Beam

Shaded area

represents

dead zone (+-2°)

Bar Code Bar Code Bar Code

Quick Reference Guide 5

Scan the Entire Symbol

-The scan beam must cross every bar and space on the symbol (as in the

left bar code below).

-Hold the scanner farther away for larger symbols.

-Hold the scanner closer for symbols with bars that are close together.

Changing the Battery

When a battery is fully charged, it generally lasts up to 10 hours without being

returned to the cradle. By returning it to the cradle during the day, this time is

extended.

If a significant decrease in battery life is noticed and does not correspond to

increased usage, consider replacing the battery.

Removing the Battery

1. Slide the battery release latch down using center indent and remove the

battery compartment cover.

2. Slide the battery toward the bottom of the scanner and then pull the bottom of

the battery back and out of the scanner.

Replacing the Battery

1. Place the top portion of the battery (curved side up, contacts toward top) into

the scanner and then slide it up the handle.

2. Replace the battery compartment cover.

3. Slide the release latch up to secure the cover in place.

Battery

Compartment

Cover

Battery

Release

Latch

6 P370/470 RF Scanners

Quick Startup Instructions

The table that follows includes an index of startup instructions to help get you

started quickly. The index is listed in a step-by-step order beginning with step 1,

Setting up the System. This index references pages in the P470/P370 RF

Scanners Product Reference Guide (p/n 72-38495-xx). The Product Reference

Guide is included on the CD shipped with the scanner. It is also available on the

Symbol Web site at: http://www.symbol.com/manuals.

Mandatory steps are designated by an asterisk (*). If an item has multiple pages

referenced, the most important reference is in bold.

Topic PRG Page

1. Setting Up the System

• Connecting the cradle to a host * 2-1

-RS-232 connection 2-2

-Synapse connection (keyboard wedge, USB, etc.) 2-3

• Charging the battery * 1-3, 2-8

• Pairing the scanner with the cradle * 2-6

-RF channel 3-8, 5-13, C-1

-Coexisting in Spectrum24 environments 2-7

2. Using the Default Applications

• Overview of Scan and Transmit application* 3-2

• Keypad operation 3-2, 3-3, 3-22

• Eliminating repetitive scanning 3-4

• Selecting the host communication protocol 3-2, 3-8, 5-8

-- RS-232 baud rate 5-81

3. Programming an Advanced Data Formatting Rule Using

123Scan

3-17

4. Troubleshooting Problems

• Troubleshooting table 3-24

• Communication errors 3-5, D-2

• Beeper indications and default application error codes 4-7

• Cradle LED indications 4-3

Quick Reference Guide 7

Test Symbols

Code 39

13 Mil UPC

Code 128

EAN-8

8 P370/470 RF Scanners

Regulatory Information

All Symbol devices are designed to be compliant with rules and regulations in locations they

are sold and are labeled as required.

Any changes or modifications to Symbol Technologies equipment, not expressly approved by

Symbol Technologies, could void the user's authority to operate the equipment.

Do NOT attempt to charge damp/wet mobile computers or batteries. All components must be

dry before connecting to an external power source.

Country Approvals

Regulatory markings are applied to the device signifying the radio (s) are approved for use in

the following countries: United States, Canada, Australia, Japan and Europe.

Please refer to the Symbol Declaration of Conformity (DoC) for details of other country

markings. This is available at http://www2.symbol.com/doc/.

Operation of the device without regulatory approval is illegal.

Health and Safety Recommendations

Ergonomic Recommendations

-Reduce or eliminate repetitive motion.

-Maintain a natural position.

-Reduce or eliminate excessive force.

-Keep objects that are used frequently within easy reach.

-Perform tasks at correct heights.

-Reduce or eliminate vibration.

-Reduce or eliminate direct pressure.

-Provide adjustable workstations.

-Provide adequate clearance.

-Provide a suitable working environment.

-Improve work procedures.

Vehicle or Forklift Installation

RF signals may affect improperly installed or inadequately shielded electronic systems in

motor vehicles (including safety systems). Check with the manufacturer or its representative

regarding your vehicle. You should also consult the manufacturer of any equipment that has

been added to your vehicle.

Position your device within easy reach. Be able to access your device without removing your

eyes from the road.

CAUTION Only use Symbol approved and UL Listed accessories, battery packs and

battery chargers.

CAUTION In order to avoid or minimize the potential risk of ergonomic injury follow

the recommendations below. Consult with your local Health & Safety

Manager to ensure that you are adhering to your company's safety

programs to prevent employee injury.



Quick Reference Guide 9

Warnings for Use of Wireless Devices

Please observe all warning notices with regard to the usage of wireless devices.

Potentially Hazardous Atmospheres

You are reminded of the need to observe restrictions on the use of radio devices

in fuel depots, chemical plants etc. and areas where the air contains chemicals or

particles (such as grain, dust, or metal powders) and any other area where you

would normally be advised to turn off your vehicle engine.

Safety in Hospitals

Wireless devices transmit radio frequency energy and may affect medical

electrical equipment.

Wireless devices should be switched off wherever you are requested to do so in

hospitals, clinics or health care facilities. These requests are designed to prevent

possible interference with sensitive medical equipment.

Pacemakers

Pacemaker manufacturers recommended that a minimum of 15cm (6 inches) be

maintained between a handheld wireless device and a pacemaker to avoid

potential interference with the pacemaker. These recommendations are

consistent with independent research and recommendations by Wireless

Technology Research.

Persons with Pacemakers:

-Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker

when turned ON.

-Should not carry the device in a breast pocket.

-Should use the ear furthest from the pacemaker to minimize the potential for

interference.

If you have any reason to suspect that interference is taking place, turn OFF your

device

Hearing Aids

The wireless device may interfere with some hearing aids. In the event of

interference you may want to consult your hearing aid supplier to discuss

solutions.

Other Medical Devices

Please consult your physician or the manufacturer of the medical device, to

determine if the operation of your wireless product may interfere with the medical

device.

10 P370/470 RF Scanners

FCC / EU RF Exposure Guidelines

Safety Information

The device complies with Internationally recognized standards covering Specific

Absorption Rate (SAR) related to human exposure to electromagnetic fields from

radio devices.

Reducing RF Exposure - Use Properly

It is advisable to use the device only in the normal operating position.

Handheld Devices

To comply with FCC RF exposure requirements, this device must be operated in

the hand with a minimum separation distance of 20 cm or more from a person's

body. Other operating configurations should be avoided.

Laser Devices

Complies with 21CFR1040.10 and 1040.11 except for deviations pursuant to Laser Notice No.

50, dated July 26, 2001.

EN60825-1:1994+ A1:2002 +A2:2001

IEC60825-1:1993+A1:1997+A2:2001

The laser classification is marked on one of the labels on the device.

Class 1 Laser devices are not considered to be hazardous when used for their intended

purpose. The following statement is required to comply with US and international regulations:

Class 2 laser scanners use a low power, visible light diode. As with any very bright light

source, such as the sun, the user should avoid staring directly into the light beam. Momentary

exposure to a Class 2 laser is not known to be harmful.

Scanner Labeling

CAUTION Use of controls, adjustments or performance of procedures other than

those specified herein may result in hazardous laser light exposure.



CAUTION

LASER LIGHT-DO NOT STARE INTO BEAM

630-680 nM LASER 1.0 mW MAX OUTPUT

CLASS II LASER PRODUCT

LASERLICHT - NICHT IN DEN STRAHL BLICKEN, LASER KLASSE 2

LUMIERE LASER-NE PAS REGARDER DANS LE FAISCEAU

APPARIELA LASER DE CLASSE 2. CAUTION-LASER LIGHT DO NOT

STARE INTO BEAM. IEC CLASS 2 LASER PRODUCT 630-680mW LASER

Autres manuels pour P370

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Symbol Lecteur de codes-barres

Symbol

Symbol LS 7708 Manuel d'installation et d'exploitation

Symbol

Symbol LS 3408 Manuel d'installation et d'exploitation

Symbol

Symbol LS3578-FZ - Symbol - Wireless Portable Barcode... Manuel utilisateur

Symbol

Symbol LS 2104 Manuel d'installation et d'exploitation

Symbol

Symbol LS4000P Series Manuel utilisateur

Symbol

Symbol LS4278 Manuel utilisateur

Symbol

Symbol LS 4208 Manuel utilisateur

Symbol

Symbol Phaser P460 Manuel d'installation et d'exploitation

Symbol

Symbol LS 4005i-I573 Manuel utilisateur

Symbol

Symbol LS 4208 Manuel utilisateur

Symbol

Symbol ORG SPT 1550 Manuel d'installation et d'exploitation

Symbol

Symbol LS2208-SR20001R Manuel utilisateur

Symbol

Symbol LS4278 Manuel utilisateur

Symbol

Symbol LS 3603 Manuel d'installation et d'exploitation

Symbol

Symbol MiniScan MS-220X Guide de configuration rapide

Symbol

Symbol LS1203 Manuel utilisateur

Symbol

Symbol LS 6004 Mode d'emploi

Symbol

Symbol LS 400 series Manuel d'installation et d'exploitation

Symbol

Symbol LS 4208 Manuel utilisateur

Symbol

Symbol PSM20i Manuel utilisateur

Symbol

Symbol LS9203 Manuel d'installation et d'exploitation

Symbol

Symbol DS 3408 Manuel d'installation et d'exploitation

Symbol

Symbol MiniScan Series Manuel utilisateur

Symbol

Symbol MicroKiosk MK1000 Manuel d'installation et d'exploitation

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
