Sylvania SDVD7040B Manuel utilisateur

SDVD7040B

Table Of Contents

Safety Precaution

Package

Main Features

Main Unit Controls

System Connection

The Remote Control

Basic operation

System Setup

Specification

Troubleshooting

Safety Precaution

Warning: To reduce the risk of fire or electric shock, do not expose this

apparatus to rain or moisture.

1) Please read the instruction manual carefully and follow all the requirements

of safe operation to operate the device.

2) Do not use this unit near water. Do not place over the unit any container

with liquid inside.

3) Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus (including amplifiers) that produce heat.

4) Unplug this unit during lightning storms or when unused for long time.

5) About Cleaning: Unplug the system, use only wet cloth to clean. Do not use

liquid detergent or aerosol.

6) Only use accessories specified by the manufacturer.

7) Refer all servicing to qualified service personnel, servicing is required when

the unit has been damaged in any way, such as power supply cord or plug

is damaged, liquid has been spilled or objects have fallen into the unit,

exposed to moisture, does not operate normally. Don't try to repair the

machine by yourself because of the danger of high voltage and electric

shock.

8) Do not use irregular shaped discs such as heart or star-shaped discs as

they may cause the unit to malfunction.

Thank you for choosing our portable DVD player.

The unit applies the latest state of art electronics and is designed for use at

home, in hotels and in offices etc for relaxation. The compact size makes

carrying easier as well as installation. Please read the manual carefully prior

to use and keep it well for later consultation.

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference received,

including interference that may cause undesired operation.

Warning: Changes or modifications to this unit not expressly approved by the

party responsible for compliance could void the user's authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

High brightness color 7" LCD screen

Compatible with disc of DVD, VCD, MP3, MPEG4, CD, JPEG, etc.

Built-in stereo speaker

Built-in rechargeable Lithium polymer battery

Support PAL or NTSC system

Support Multi-language OSD, speed forward/backward, repeat function

Package

Main Features

DVD Player

Remote Control with battery

AC/DC Power Adapter

Cigarette Lighter Adapter

User Manual

Swiveling LCD Screen

You can swivel the LCD screen of this player clockwise a maximum of 180

for use.

180° 180°

Main Unit Controls

1. SD card slot

2. MODE button

3. Play/Pause / VOL+

(press shortly to play/pause,

press longly to add volume.)

4. STOP / VOL

(press shortly to stop, press

longly to reduce volume.)

7. Open knob

8. DC IN 9-12V

9. Power ON/OFF switch

10. AV OUT

11. Earphone jack

12. USB Port

13. Rating label position

Plug one end of the AC/DC power adaptor into the DC IN9-12V jack on the

right of the machine, then plug the other end into the AC power receptacle.

Please refer to the following illustration.

If using car cigarette lighter adaptor to connect to the power: Plug one end of

the cigarette lighter adaptor into the DC IN 9-12V jack on the unit, plug the

other end into the car cigarette lighter socket. See illustration below.

System Connection

Powering And Installation

Note

1. Car cigarette lighter adaptor is available to use only when the car cigarette

lighter with DC 12V negative grounding.

2. The mains plug is used as the disconnect device, the disconnect device

should remain readily operable.

Using SD/MMC card

Upon using an SD or MMC card, insert it into the corresponding slot flatly with

label side upward until you hear a click.

Using USB

Upon using an USB, insert it into the USB slot directly.

Connecting With External Speaker

Note:

There is no 5.1 channel in the unit, however, after connecting to APM it is

available to output audio in 5.1 channel.

AMPLIFIERTV

SUBWOOFER

Left front

speaker

Right front

speaker

Center speaker

Left rear speaker Right rear speaker

AUDIO INVIDEO IN

AV CABLE

Not supplied

The unit can be connected with external speaker. Please see the following

illustration.

The Remote Control

1. Number button

2. TITLE (To display title

information)

3. AUDIO (To select audio

language)

4. SETUP (To go to or exit

setup menu)

5. / Previous/Next

button (To go to previous/

next chapter or scene

during playing)

6. / Fast forward/

backward button (To scan

forward/backward at 2, 4,

8, 16, or 32 times )

7. OSD (To display disc

information during playing

such as elapsed and

remaining time)

8. Play / pause

9. STOP ( Press once to

stop playback, then press

to resume playback

from the point where you

stopped; press stop button

twice to stop playback completely.)

10. ENTER (To confirm)

11. MODE (To select the source refer to P17)

12. ZOOM(To zoom in the image during the playback)

13. MENU (To enter or exit menu root)

14. SUBTITLE (To select subtitle language when playing DVD disc)

15. ANGLE (To change viewing angle when playing disc with multi-angle)

16. A-B (Repeat a specific portion from point Ato B, press it again to cancel

repeat playing)

17. REPEAT (To repeat playing title, chapter or track)

18. RETURN (To return to the main menu)

19. MUTE (To turn to mute)

20. VOL +/- (To adjust the volume)

When using remote control, make sure the

infrared window is pointed to infrared receiving

window of the machine. The distance between

machine and remote control must be within 3

metres. Please refer to the following illustration.

1. To avoid falling off or place near damp environment.

2. To avoid infrared receiving window of the unit being under direct sunlight.

3. Please use a new battery to replace old one if the remote control doesn't

work.

The Use Of Remote Control

Notice

CR2025 CR2025

Please put the battery into the remote control as per illustration below.
