SWELLPRO Splash Drone 3 Mode d’emploi

Safety operation guideline &

Disclaimer and warning

www.swellpro.com

-3-

Safety operation guideline

1. Flying conditions and environmental considerations

- Fly in open spaces or above water surface that is far away from crowds.

- Only ﬂy the splash drone 3 to a maximum altitude of 4000m.

- The operating temperature range of splash drone 3 is -10°C to 40°C.

- Only ﬂy in permitted areas, please refer to the interpretations in chapter 6 for

further information.

2. Pre-Flight Inspection and checks

- Make sure all the batteries are fully charged.

- Make sure all the propeller blades are in good condition and correctly

fastened.

- Manually rotate the 4 motors, make sure the rotations are smooth.

- Make sure the GPS top cover is correctly installed, all the screws are properly

fastened, and there is an airtight seal under the hatch.

- Make sure the drone fuselage is sealed and without damage, and the

membrane is in good condition.

a) Please keep the sealing surfaces of the fuselage, and of the cover clean, free

of dirt, sand, or any other contamination.

b) Please keep the sealing gasket clean, and ensure the gasket is without rips

or damage whatsoever.

c) Please ensure the gasket is seated and located correctly onto the 4 cover

screws.

Highlighted Factors regarding the GPS Top cover

The top cover is the only point of entry into the fuselage of the Splash

drone. Therefore, great care should be taken to ensure the integrity of the

watertight seal, to protect the electronics of the Splash drone.

-4-

3.Operating Guide

a) It's preferable to ﬂy the Splash drone within eyesight, please pay particular

attention and take great care when ﬂying the drone out of visible sight range.

b) Unless in an emergency, whilst in ﬂight, NEVER Lock or STOP the motors, as

this will cause the drone to fall to the ground and crash!

c) When the battery level has dropped to it’s low level, please activate the

Return to Home function, this is done by a single ﬂip of the Return

home/Normal switch.

d) The Return to Home function should also be activated if the drone goes out

of eﬀective radio control range, or has gone out of sight.

e) If any obstacles are in the ﬂight path of the drone on it’s way back, control

should be regained. Please ﬂick the switch once to regain ﬂight control.

f ) If the Drone has collided into a tree, or crashed onto a roof, or hit the ground

unexpectedly, please lock the motors immediately to protect the motors, the

ESCs and propellers from burning out or other further damages.

d) When closing the cover, please make sure the gasket is not kinked, or

distorted in any way, with a snug ﬁt all around.

e) Please make sure to take care when tightening the hatch screws, and they

are not cross threaded.

f ) Tighten the hatch screws by hand initially, then, if necessary, using a coin of

20 – 30mm diameter, held between the thumb and foreﬁnger, and using the

slot in the top of the screw/s, tighten the screws and check the tightness.

Please do not over tighten the screws, as this will pinch and possibly distort the

gasket.

g) Please check and ensure that the breathable membrane seal on the top of

the cover is in good condition, and has not been disturbed in any way, or has

no scratches or puncture holes.

-5-

- Please immediately switch back to ATTI mode to take over control, and y

the drone back to within visible range, and nd a safe landing place.

- Please land and power o the drone, followed by its controller.

* Toilet bowl eect – this is the opposite action to water owing in a

spiraling action in a toilet bowl. Initially a small radius circling, then

increasing in radius.

The possible causes for the instability or loss of control of the drone could

be:

g) Once the Splash drone has landed safely, and the motors have shut down,

and have been locked, please follow these steps: 1. Open the hatch; 2.

Disconnect the battery connector; 3.Then power oﬀ the remote control.

h) Do not attempt to touch the motors, until the motors have stopped rotating.

i) When taking-oﬀ & landing on the water, please avoid high-speed crashes or

abusive landing, so as to avoid damaging the drone.

j) When ﬂying over the water, please avoid allowing the drone to drop or crash

into the water from a high altitude. This could cause major damage to the

drone.

k) Don't expose the drone & battery to direct sunlight for sustained periods of

time, it can raise the temperature inside the fuselage to well above the

operating temperature range. If it is the case that the drone & battery have

been exposed to sunlight, and is overheated, we recommended opening the

hatch, and placing the drone in a sheltered area, until it has completely cooled

down.

l) If the drone goes out of control or becomes unstable in ﬂight for any reason

(such as slow or lethargic responses to ﬂight commands, if the toilet bowl

eﬀect* occurs during hovering, or any other erratic ﬂight symptoms), please

follow the steps:

-6-

4. Maintenance

- Please make sure to double check the propellers after ﬂight,

distorted/damaged props should be replaced immediately.

- After ﬂying over the sea or other corrosive waters, please wash the outer

modules of the drone with fresh water within 2 hours, especially the motors,

the gimbal structure, and mounting brackets of the landing gear.

- It's strongly advised to rinse the drone before the salt crystalizes. A mild

solvent can be used to clean oﬀ the crystalized salt completely, please contact

your local dealer, or SwellPro for detailed guidelines.

- The drone has been subjected to unstable GPS signal/s or spurious

interference/eﬀects on the Compass module during ﬂight.

- The calibration of the drone (compass and/accelerometer) was incorrectly

carried out.

- The battery cable was not correctly positioned, behind the battery and as far

as possible from the compass module.

- Re-calibrate both the compass and accelerometer on the Splash drone.

- After completing the calibration, arm the drone motors to ﬂy, whilst in GPS

mode, to verify whether this phenomenon has been eliminated.

- If the abnormality remains the same, please re-locate to another place at least

5KM away and re-calibrate the Splash drone. Following the re-calibration,

please test the drone again.

- If the problem persists, please contact SwellPro or your local dealer for further

trouble-shooting and solutions.

Steps that can be taken to resolve the issues:

-7-

5. Flight Safety

- Please make sure you have a comprehensive understanding of the Splash

drone, and all the necessary measures required to implement a successful

return home function, in the event of an emergency.

- Please be well prepared before each ﬂight, avoid any violent or excessive

operations.

- Please maintain strict compliance with the local laws, any ﬂying in NO-FLY

ZONEs is prohibited.

- Any illegal & improper use or operation of this product is highly prohibited.

- Any invasion & violation against another person/s right of privacy is not

allowed. Before using this product, it remains the duty of the drone pilot to

comply with the local laws regarding privacy protection.

- Any invasion or ﬂying over another person/s property is not allowed, please

agree with any person/s regarding any potential breech of privacy before the

proposed ﬂight.

- Any ﬂights in or around the strong magnetic ﬁelds are highly prohibited,

these inﬂuential factors include wireless electricity emission towers,

High-voltage transmission lines, transformer substations, radar and other

magnetic sources or metal objects.

- DO NOT ﬂy the Splash drone under the inﬂuence of alcohol, drugs or any

other physical or mental impediment.

- Please don't ﬂy the drone with a malfunctioning radio controller - Please ﬂy

the drone away from crowds.

- In the event of the Splash drone not being used for a long time, please store

the drone, and the batteries in a dry, and ventilated environment, within a

temperature range of 20°C~28°C.

- Please refer to <Safety guideline with batteries> for further details on

maintaining the batteries.

-8-

Threats to ght safety scenarios

Airport

Radio signal tower High voltage poer linesRadar Trees Tall buildings

Crowds

Restricted area

Be sure to read this document carefully before using the product, to fully

understand your legal rights, responsibilities and safety instructions. Failure to

do so, may cause property damage, safety accidents and personal safety risks.

Once this product is used, it is deemed that you have understood, recognized

and have accepted all the terms and conditions of this statement. The user is

responsible for all the consequences of his actions and consequences. The user

agrees to use the product for his sole & legal purpose, and agrees with the

terms & conditions of this agreement, and other relevant policies & guidelines

that may be speciﬁed by SwellPro.

This product is not a toy, and should only be operated by persons

over the age of 18. Please keep it out of reach of children, and pay

particular attention to the possible scenarios of children's

unexpected appearance during ﬂight operation.

Disclaimer and warning

-9-

Under the maximum permission by law and approved circumstances, SwellPro

is exempt of liability for any indirect, punitive, consequential, special or criminal

damages, including the purchase cost, or for loss of income due to the loss of

use of the drone.

- Damage(s) or injuries incurred when the user/s are under the inﬂuence of

alcohol, drugs or medication.

- Any malfunction caused by operators' failure to follow the guidance of the

manual to assemble and set up, or operate the drone as described, and

designed.

- Damage(s) or injuries that may occur due to failure to study the tutorial

videos, and the user manual before ﬂying the drone.

- Damage(s) or injuries caused to a person/s or property, due to failure in

correctly calibrating the UAV as outlined in the manual, prior to ﬂight.

- Damage(s) or injuries incurred as a result of the use or installation of any

unauthorized third party accessories or counterfeit parts - which were not

provided and approved of by SwellPro.

- Damage(s) or injuries as a result of ﬂying the drone out of eyesight range, or

more than 300m away from the controller.

- Damage(s) or injuries caused by ﬂying the drone in areas of magnetic ﬁelds &

radio interference.

- Damage(s) or injuries caused by ﬂying in a NO-FLY ZONE that is regulated by

local laws & rules.

- Damage(s) or injuries including crashes, loss of control or water ingress

caused by abusing or modifying the original drone structure,

- Damage(s) or injuries caused by using broken & ageing components.

SwellPro is exempt from the user's liabilities for damage(s) to person/s or

property, or injuries incurred directly or indirectly from the use of this

product in the following conditions:

-10-

- Damage(s) or injuries caused by continuing to ﬂy the drone even if the low

battery alarm is activated.

- Damage(s) or injuries caused by failure to wash the components with fresh

water after ﬂying over or near the sea & corrosive waters.

- Damage(s) or injuries that have occurred when the drone has been subjected

to the following conditions or situations: collision, ﬁre, explosion, ﬂoods,

tsunamis, ice, snow, avalanche, ﬂooding, landslide, earthquake, etc.

- Damage(s) or injuries incurred by intentionally dropping or crashing the

splash drone into the water from a high altitude, especially water ingress into

the drone fuselage and Gimbal malfunction.

- Damage(s) or injuries incurred by intentionally dropping or crashing the

Splash drone to the ground from a high altitude, especially water leakage into

the drone fuselage and Gimbal frame as a result of this collision.

- Other Damage(s) or injuries that are not SwellPro's liability.

Autres manuels pour Splash Drone 3

Table des matières

Autres manuels SWELLPRO Drone

SWELLPRO

SWELLPRO SplashDrone4 Manuel utilisateur

SWELLPRO

SWELLPRO SPLASH DRONE Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone 3 Manuel utilisateur

SWELLPRO

SWELLPRO SPLASH DROME 3 Manuel utilisateur

SWELLPRO

SWELLPRO SPLASH DRONE Manuel utilisateur

SWELLPRO

SWELLPRO SplashDrone 4 Instructions de montage

SWELLPRO

SWELLPRO SPLASHDRONE 3 Mode d'emploi

SWELLPRO

SWELLPRO Splashdrone Fisherman FD1 Manuel utilisateur

SWELLPRO

SWELLPRO GC3-T Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone PR Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone Auto Manuel utilisateur

SWELLPRO

SWELLPRO Fisherman Manuel utilisateur

SWELLPRO

SWELLPRO spry Manuel d'utilisation et d'entretien

SWELLPRO

SWELLPRO SPLASH DRONE Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone 3 Mode d’emploi

SWELLPRO

SWELLPRO Splash Drone 3 Manuel utilisateur

SWELLPRO

SWELLPRO spry Manuel utilisateur

SWELLPRO

SWELLPRO Fisherman FD3 Manuel utilisateur

SWELLPRO

SWELLPRO SWIFT 2 Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone 3 Manuel utilisateur

SWELLPRO

SWELLPRO SPLASH DRONE Manuel utilisateur

SWELLPRO

SWELLPRO SplashDrone 4 Manuel utilisateur

SWELLPRO

SWELLPRO SWIFT 2 Manuel utilisateur

SWELLPRO

SWELLPRO Splash Drone 3 Manuel utilisateur

Manuels Drone populaires d'autres marques

Ryze

Ryze Tello Manuel utilisateur

PowerVision

PowerVision PowerRay Manuel utilisateur

Force1

Force1 rogue F72 Manuel utilisateur

Zerotech

Zerotech DOBBY Manuel utilisateur

Protocol

Protocol VIDEODRONE AP Manuel utilisateur

dji

dji Matrice M210 Manuel utilisateur

MAKE

MAKE Terry Kilby Manuel utilisateur

SYMA

SYMA X440 Manuel utilisateur

RUKO

RUKO F11 Manuel utilisateur

SYMA

SYMA X5UW(720P) Manuel utilisateur

Dynali

Dynali 25 H Mode d’emploi

dji

dji PHANTOM 4 Manuel utilisateur

Atlas

Atlas AtlasPRO Manuel utilisateur

Twodots

Twodots TVVIN BOARD Manuel utilisateur

GDU

GDU SAGA Manuel utilisateur

Ares

Ares ETHOS QX 130 Manuel utilisateur

Walkera

Walkera ZHUN Manuel utilisateur

dji

dji WIND-4 Manuel utilisateur
