Swann NHD-855 Manuel utilisateur

Super HD Bullet

Security Camera

NHD-855 5MP Bullet Camera for Network Video Recorders

EN INSTRUCTION MANUAL

Security Made Smarter

Introduction

Congratulations on the purchase of your Swann Su-

per HD Camera.

• Enjoy day & night security & have a bird’s eye

view of your premises in crystal clear super HD

with this impressive 5 Megapixel camera

• See what’s happening in any light with infrared

cut filter & powerful night vision up to 130ft/40m

& a wide 70° viewing angle

• With sleek bullet styling & sturdy aluminium

construction, the camera suits indoor & out-

door applications with an IP66 rating for any

weather conditions

• This camera is the perfect addition if you al-

ready have a recording solution (NVR) & need

extra surveillance. It can only be used in combi-

nation with Swann’s Platinum Digital HD NVRs

including the 7450 series

Important instructions

1. Make sure the camera is fixed correctly and stable

if fastened in place.

2. Never place strain of any kind on the network ca-

ble connection. It’s designed to clip into the Ethernet

port, but it won’t support weight and can be broken.

3. Do not operate if wires and terminals are exposed.

Important note: All jurisdictions have specific laws

and regulations relating to the use of cameras. Be-

fore using any camera for any purpose, it is the buy-

er’s responsibility to be aware of all applicable laws

and regulations that limit the use of cameras.

If you own a 8 or 16 channel 8000 series NVR, con-

figuration is required for successful connection,

go to support.swann.com for further instructions.

Search for - NHD 855 Connection Guide.

Connecting the Camera2

To connect the camera to your NVR, simply connect the supplied Ethernet cable to the LAN connection on the

camera then plug the other end of the cable into one of the IP camera inputs on the back of your NVR.

Please note: The power connector is provided as an alternative power option if required. Your NVR will

provide power over the Ethernet cable when connected and a separate power adapter is not required.

LAN7LAN7 LAN5LAN5

LAN8LAN8 LAN6LAN6

LAN3LAN3

LAN4LAN4

LAN1LAN1

LAN2LAN2 WANWAN AUDIO OUTAUDIO OUT VGAVGA USB 3.0USB 3.0

LINE INLINE IN

8 78 7 6 56 5 G 4G 4 3 23 2 1 G1 G ALARMALARM

SENSORSENSOR 48V48V

Power

Ethernet Cable

LAN

Mounting the Camera3

The camera can be mounted onto a flat surface using the screws and wall plugs provided. The surface must

have sufficient strength to hold the camera.

→ Position the camera in the location you want to mount it, and mark the screw holes on the surface to

position the screws (a mounting template has been included). Then, using the appropriate screws for the

surface you’re fixing the camera to, secure the camera in place.

→ If you’re mounting to a wooden surface, then screw the camera directly to the surface.

→ If you’re mounting to a masonry surface (bricks, concrete or similar), then you’ll need to use wall plugs.

Aiming the camera

1. Loosen both screws (use an Allen key) to adjust the camera’s orientation.

This enables you to rotate the camera so no matter what direction it is facing,

your images will be the right way up. Tighten each screw to secure in place.

2. Loosen the screw to tilt the camera up or down. Tighten the screw to

secure in place.

3. To pan the camera left or right, loosen the screw and position accordingly.

Tighten the screw to secure in place.

1. Take into consideration what you want to monitor

and where you’ll get the best view of it.

2. How you’re going to connect the camera to your

monitoring system; remember that cables and

connections should be kept out of the weather.

3. How to keep the camera out of harm’s way. It’s

recommended to mount your camera at an elevated

position.

4. Place your camera as close to the area of interest

as practicable. The best position is from about

13ft/4m above looking slightly down, keeping in mind

the details you are looking for.

5. Although the sky looks nice when you look at the

live view from your camera, it is an unlikely direction

for an offender to approach. Make sure your camera

has minimal sky in it as the light in daylight can make

the foreground of the image darker.

6. Think about the most likely way a potential offender

may approach your home, use your camera to give

you the best coverage of these areas.

7. The camera’s casing is resistant to different

weather conditions and tampering. It would take an

overwhelming event to damage the housing.

8. Even though the camera is weather and water-

resistant, prolonged exposure to adverse weather

conditions such as sunlight or excessive moisture,

may eventually damage the internal components of

the camera and adversely affect its performance.

9. Run cables inside a wall cavity or other protected

enclosure, and ensure that all wiring and connectors

are insulated and protected from moisture.

10. Don’t put your cable near live electrical wiring. AC

electricity generates radio “noise” which can interfere

with the signal from your camera.

Camera Location Tips4

Swann Communications warrants this product against defects in workmanship and material for a period of

one (1) year from its original purchase date. You must present your receipt as proof of purchase for warranty

validation. Any unit which proves defective during the stated period will be repaired without charge for parts or

labour or replaced at the sole discretion of Swann. The end user is responsible for all freight charges incurred

to send the product to Swann’s repair centres. The end user is responsible for all shipping costs incurred when

shipping from and to any country other than the country of origin.

The warranty does not cover any incidental, accidental or consequential damages arising from the use of or

the inability to use this product. Any costs associated with the fitting or removal of this product by a tradesman

or other person or any other costs associated with its use are the responsibility of the end user. This warranty

applies to the original purchaser of the product only and is not transferable to any third party. Unauthorized end

user or third party modifications to any component will render all warranties void. By law some countries do not

allow limitations on certain exclusions in this warranty. Where applicable by local laws, regulations and legal

rights will take precedence.

For Australia: Our goods come with guarantees which cannot be excluded under Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably

foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be

of acceptable quality.

Limited Warranty - Terms & Conditions5

This equipment has been tested and found to comply with the limits for Class A digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and the receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) These devices may not cause harmful interference.

(2) These devices must accept any interference received, including interference that may cause undesired op-

eration.

FCC Verification6

M855CAMVER1E | © Swann 2017

Helpdesk & Technical Support

Technical Support E-mail: [email protected]om

Technical Support Website: support.swann.com

Telephone Helpdesk

USA Toll Free 1-800-627-2799

USA Parts & Warranty 1-800-627-2799

(M-F, 9am-5pm US PT)

AUSTRALIA 1800 788 210

NEW ZEALAND Toll Free 0800 479 266

UK 0808 168 9031
