SvoëMesto Kayfun X Manuel utilisateur
ATTENTION: Do not use oils or oil-based fluids with the atomizer.
This manual is meant as a brief overview on the general
functionality of the SvoëMesto Kayfun X. If you have no
experience using a rebuildable atomizer or creating coils, please
consult your local vendor.
Further information and languages at www.svoemesto.de.
The SvoëMesto Kayfun X is a rebuildable tank atomizer specifically
designed to vaporize e-liquid for electronic cigarettes. Before use you
must install a coil intended for use in electronic cigarettes. It is
recommended to clean the device with water, dry and lube all visible
o-rings with e-liquid.
1. Before use
The SvoëMesto Kayfun X recommended use is for coils with a minimum
resistance of 0.5 ohm and an electric input from 5 to 25 watts. Please
use the atomizer responsibly and the coils you’ve created at your own
risk.
2. Application
2.1 Accessing the deck
Step 1
Flip the atomizer
upside down, if
the tank is filled.
Step 2
Unscrew the base
counter-clockwise.
Step 3
Remove the base to
access the deck.
User manual
2.2 Installing coil and wick
The coil is placed diagonally between the build screws and approx. 1.5 mm –2 mm
above the air outlet, so that air can smoothly flow around the coil. The ends of the wire
are placed under the build screws and then clamped underneath them.
The overhanging ends of the wick should be placed in the empty spaces beneath the
terminals, so that they lay above the liquid channels. Before assembling the atomizer, it
is recommended to saturate the wick with e-liquid.
ATTENTION: For your own safety please
note the following
•The coil has to be connected with
one end at the plus terminal, with
the other end at the minus terminal.
•The exceeding ends of the wire
have to be cut flush with the
terminals and must not stick out of
the build deck. Otherwise, this may
cause a short circuit.
•The coil must not touch the deck
itself.
2.3 Setting airflow
The Kayfun X has the continuously adjustable airflow control system
AEROKON.
Step 1
Insert a small flathead
screwdriver into the 510
connector in the bottom. While
fully assembled, put the Kayfun
X with the mouthpiece to your
lips and draw on it.
Step 2
Turn the screw inside the 510
connector clockwise to tighten
the airflow or counter-
clockwise to loosen it.
Step 1
Lift the tank up until
you feel a “click”.
The liquid channels
are now closed.
Step 2
Lift the topcap up
until it snaps into
place.
Step 3
Push against the engraving
to open the fill port and Fill
the tank through the fill port,
then reverse steps 2 and 1.
2.4 Filling
For filling the Kayfun X has to be assembled completely
3. Warranty
4. Disclaimer
5. Warnings
The manufacturer’s warranty is one year on all stainless-steel parts. Excluded from
warranty are all plastic components such as tanks and insulators, glass tanks and
o-rings.
With the SvoëMesto Kayfun X, please use original SvoëMesto accessories only. The
manufacturer accepts no liability for any third-party accessories or issues which may
have been caused or exacerbated by their use.
•Before use, please read the manual carefully!
•Please keep the atomizer dry!
•Do not use the atomizer for other purposes than intended!
•Connect the atomizer to a power source that is suitable for its intended use!
•Using the atomizer on high voltages or without a fluid can damage the
atomizer. The manufacturer accepts no liability for atomizers that were
damaged during use.
•Using the atomizer incorrectly not only can lead to a defect of the atomizer,
but also cause fire.
•Keep the atomizer away from heat sources.
•Not suitable for children. Please keep the atomizer away from children!
www.svoemesto.de
© 2017 SMtec GmbH
