FusionTREK™

Voice, text & 4G LTE signal booster for your vehicle

User Guide

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com

Table of Contents

Thank you for purchasing SureCall’s FusionTrek cell phone signal booster kit. FusionTrek provides

enhanced voice, text and 4G data signal for any vehicle.

If you have any questions during setup, please reach out to our US-based experienced support

technicians:

• Call: 1-888-365-6283

• Email: [email protected]

TABLE OF CONTENTS

How It Works ................................................................................................................................. 3

Package Contents ......................................................................................................................... 4

Step 1: Mount Booster On/Near Rear Window............................................................................ 5

a. Installation Using Adjustable Window Suction Mount........................................................... 5

b. Installation Using Adhesive Base ......................................................................................... 5

Step 2. Mount Cradle Antenna & Connect Components ............................................................... 6

Step 3. Connect To Power............................................................................................................. 7

Troubleshooting............................................................................................................................. 8

Specications ................................................................................................................................ 9

Antenna Kitting Information ......................................................................................................... 10

Consumer Guidelines.................................................................................................................. 12

Three-Year Product Warranty...................................................................................................... 13

Watch the quick install video https://youtu.be/_k20SwLBaQg

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com 3

HOW IT WORKS

The SureCall FusionTrek is a high-quality bidirectional booster that enhances cellular signals for

vehicles.

The FusionTrek works with two antennas:

• An inside antenna that communicates with your cell phone.

• An outside antenna that communicates with the cell tower.

Signals sent from a cell tower are received by the outside antenna, amplied by the booster and

then sent to your cell phone via the inside antenna. When your phone transmits, the signal is sent to

the inside antenna, and then sent to the cell tower via the outside antenna.

How It Works

➌

➊

➋

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com

Package Contents

PACKAGE CONTENTS

1. Unpack all package contents. For missing or damaged items, contact your reseller.

2. Turn over the signal booster and record the model and serial number for reference:

Serial #:

Purchase Date:

Keep the carton and packing material to store the product in case you need to return it.

Your signal booster package includes the following items:

1. SureCall FusionTrek Inside window mount signal booster 2 mounting options

2. Adjustable Window Suction-Mount

3. Adhesive Base Mount

4. Magnetic phone mount with incorporated antenna

5. Metal phone plates

6. DC power adapter

6. DC Power

Adapter

1. FusionTrek

Booster

2. Adjustable Window

Suction-Mount

3. Adhesive Base

Mount

4. Magnetic Cradle

Antenna

5. Metal

Plates

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com 5

STEP 1: MOUNT BOOSTER ON/NEAR REAR WINDOW

Mount booster in the center of your inside back window using one

of the two options below. We suggest using the adjustable window

mount option for vertical or near-vertical windows and the adhesive

base mount for windows that are more angled, like sedans. For both

installations you need to place the booster as close to the rear window

as possible. For best performance, be sure the booster is mounted

vertically with the SureCall logo facing the front of the vehicle.

Ensure that the antenna has at least a 12-inch radius clear of obstruc-

tions and other radiating elements, such as a radio antenna.

Note: The outside antenna must not be collocated or operating with any other antenna or booster.

Installation

b. Installation Using Adhesive Base

1. Find a at and horizontal surface near the rear window and the use

alcohol pad to clean the mounting location.

2. Remove the backing from the adhesive strip and press the booster

down rmly on to the mounting location.

Adhesive

base

a. Installation Using Adjustable Window Suction Mount

1. Remove the back part of the window suction mount bracket by

pressing on the release.

2. Identify a high and centered location on the back window and clean

location.

3. Lift the lever on the adjustable window mount, place rmly onto the

window and press down on the lever to lock in place.

4. Press the booster back into the mounted adjustable window mount

bracket.

Lever

Release

Connector

Nut

Ball Joint

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com

IMPORTANT: The antenna must be located at least 8 inches from all persons. The FCC requires to never use the cell phone in the cradle next to

your ear.

Installation

STEP 2. MOUNT CRADLE ANTENNA & CONNECT COMPONENTS

Identify a location for the inside antenna on or near your front dashboard that is

1. Place the magnetic cradle antenna on an air-vent, in your cup-hold-

er or center-console.

2. Plug the barrel connector into the cradle antenna and route the

cable from the cradle antenna to the booster. Screw the cable into

the connector on the back of the booster.

3. We recommend running the cable under the oor-mats or beneath

the car’s molding for a professional look.

4. Adhere one of the magnetic stickers to the back of your phone or

phone-case and place your phone on the magnetic cradle antenna.

Identify a location for the inside antenna on or near your front dash-

board that is

1. Within 2-3 feet of the typical cell phone location

2. At least 8 inches (20cm) from cellular devices and

3. At least 4 inches (10cm) from metal

Vent clip

Magnetic plate

Cable to booster

Metal plate

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com 7

Installation

STEP 3. CONNECT TO POWER

1. Plug the DC Power Adapter into power port of your car.

2. Switch the Power Switch to On and a red light will illuminate on the adapter.

3. The cradle antenna will illuminate a green light when it is receiving power.

Note: Your phone will only receive the enhanced signal when it is placed on the

cradle antenna.

When your car is off, turn the power switch to OFF to keep the booster from con-

tinuing to draw power from your vehicle.

Power

switch

Power LED

Power connector

Cable to booster

WARNING: The booster is rated for 5-15V input voltage. DO NOT use the booster with a higher voltage power supply. This can damage the

booster and/or cause personal injury.

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com

SpecicationsTroubleshooting

TROUBLESHOOTING

Problem Resolution

Signal booster has no

power

Verify that the Power LED is ON.

Connect the power supply to an alternate power source.

Verify that the power source is operational and the fuse is intact.

If it remains OFF, contact tech support at:

1-888-365-6283 or [email protected]

After completing

installation, signal has

not Improved

Verify that cable connections are tightly tted to the booster.

Note: Bars are not always a reliable measure of signal. The best way to conrm signal coverage is the ability to

place and hold a call.

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com 9

Specications

SPECIFICATIONS

Product FusionTrek (US) FusionTrek CA (Canada)

Uplink Frequency Range (MHz): 698-716 / 776-787 / 824-849 / 1850-1915 / 1710-1755 (G Block Included)

Downlink Frequency Range (MHz): 728-746 / 746-757 / 869-894 / 1930-1995 / 2110-2155 (G Block Included)

Input / Output Impedance: 50 Ω

Maximum Gain: 23 dB

Gain Adjustment: 20 dB (Automatic)

Supported Standards: CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards

Noise Figure: ≤ 7 dB

VWSR: ≤ 2.0

Maximum Output Power: 1 Watt EIRP

DC Power: 8-15VDC

Cable: SC-174, 15 ft

RF Connectors: SMA Female

Power Consumption: <12W

Operation Temperature: 14°F – 122ºF

Dimensions: 7.5 x 3.5 x 1.16 in

Weight: .62 lbs (9.92 oz)

Certication: FCC ID: RSNF-TREK IC: 7784A-FTREK

Note: The term “IC” before the radio certication number only signies that Industry Canada technical specications were met.

SureCall | www.surecall.com | 1-888-365-6283 | support@surecall.com

Kitting InformationKitting Information

ANTENNA KITTING INFORMATION

Component Prod No. Description

Gain/Loss Notes

LTE-A LTE-V 800 MHz

1900

MHz

1700 MHz /

2100 MHz

FusionTrek Kit

Outdoor Antenna WPANT10104-S3A

(SC325W-WP)

0.5dBi 0.5dBi 2dBi 2dBi 3dBi\3dBi Integrated

antenna

Indoor Antenna SC128W -0.1dBi -0.1dBi -0.3dBi 3dBi 2.5dBi\3.2dBi

Indoor Cable SC-174-15FT (15 Feet) 3.4dB 3.4dB 3.7dB 6dB 5.5dB \6.2dB

*All equivalent antennas and cables are suitable for use with the FusionTrek

As above information. Remark: Lower gain antenna can also be used.

* Warning: Unauthorized antennas, cables, and/or coupling devices are prohibited by FCC new rules. Changes or modications not

expressly approved by SureCall could void the user’s authority to operate the equipment.

* FCC 27.50(d)(4) Statement: Fixed, mobile and portable (hand-held) stations operating in the 1720-1755 MHz band are limited 1 Watt

EIRP. Fixed stations operating in this band are limited to a maximum antenna height of 10 meters above ground. Mobile and portable

stations operating in this band must employ a means for limiting power to the minimum necessary for successful communications.
