X11SCA/-F/-W QUICK REFERENCE GUIDE Product Safety Information

Standardized Warning Statements

Motherboards

About Standardized Warning Statements

The following statements are industry standard warnings, provided to warn the user of situations which can potentially

cause a bodily injury. Should you have questions or experience difculty, contact Supermicro's Technical Support De-

partment for assistance. Only certied technicians should attempt to install or congure components.

Read this section in its entirety before installing or conguring components in the Supermicro chassis.

Battery Handling

Warning!

There is a danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or an equiva-

lent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.

電池の取り扱い

電池交換が正しく行われなかった場合、破裂の危険性があります。交換する電池はメーカーが推奨する型、または同等のもの

を使用下さい。使用済電池は製造元の指示に従って処分して下さい。

警告

電池更換不當會有爆炸危險。請使用製造商建議之相同或功能相當的電池更換原有電池。請按照製造商的說明指示處理

廢棄舊電池。

警告

电池更换不当会有爆炸危险。请只使用同类电池或制造商推荐的功能相当的电池更换原有电池。请按制造商的说明处理

废旧电池。

경고!

배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제조사에서 권장하는 동등한

종류의 배터리로만 교체해야 합니다. 제조사의 안내에 따라 사용된 배터리를 처리하여 주십시오.

Note: For complete product safety information, refer to http://www.supermicro.com/about/policies/safety_information.cfm.









WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

X11SCA/-F/-W QUICK REFERENCE GUIDE 限用物質含有情況標示聲明書

限用物質含有情況標示聲明書

設備名稱：主機板 /

Motherboard

型號（型式）： X11SCA, X11SCA-F, X11SCA-W

單元Ｕnit

限用物質及其化學符號

鉛Lead

(Pb) 汞Mercury

(Hg) 鎘Cadmium

(Cd)

六價鉻

Hexavalent

chromium

(Cr+6)

多溴聯苯

Polybrominated

biphenyls

(PBB)

多溴二苯醚

Polybrominated

diphenyl ethers

(PBDE)

主機板

(Motherboard)

－○○○○○

備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準

值。

備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。

備考3.〝－〞係指該項限用物質為排除項目。

Equipment name

Type designation (Type)

Restricted substances and its chemical symbols

Declaration of the Presence Condition of the Restricted Substances Marking

Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the

reference percentage value of presence condition.

Note 2：“○” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.

Note 3：The “−” indicates that the restricted substance corresponds to the exemption.

X11SCA/-F/-W QUICK REFERENCE GUIDE BIOS POST Codes

AMI BIOS POST Codes

About AMI BIOS POST Codes

The table below lists some of AMI BIOS POST codes for X11SCA/-F/-W. For more information, refer to https://www.

supermicro.com.tw/manuals/other/AMI_BIOS_POST_Codes_for_Grantley_Motherboards.pdf.

Code Description

0x32 CPU post-memory initialization is started

0x55 No Memory detected or memory failed

0x63 CPU DXE initialization is started

0x69 North Bridge DXE initialization is started

0x70 South Bridge DXE initialization is started

0x92 PCI Bus initialization is started

0x99 Super IO Initialization

0x9A USB initialization is started

0xA0 IDE initialization is started

0xA9 Boot into BIOS setup menu

0xAE Legacy Boot event

0xB2 Legacy Option ROM Initialization

0xB4 USB hot plug

0xD6 No VGA device

0xD7 No Keyboard plugged in

0xF2 Recovery process started

0xF9 Recovery capsule is not found

X11SCA/-F/-W QUICK REFERENCE GUIDE M.2 Device Installation Instructions

M.2 Device Installation Instructions

M.2 Device Installation

AHolder

A+B+C A+B+D

BHolder mount

CCard holder mount

ECard mount

Hole location on MB

M.2 card 42

M.2 card 60

M.2 card 80

M.2 card 110

A+B+C

A+B+D

A+B+C

A+B+D

A+B+C

A+B+D

110

N/A

Turn 90 degree to lock

Turn 90 degree to lock Locked position

with M.2 card

Press in here

Locked position

DPlastic screw

Press in here

Mounting position with M.2 card

Rectangle hole on MB

STOP

The installation may vary depending on the

type of M.2 cards. For the X11SCA(-F)(-W)

series motherboards, please install the M.2

card (length 80) directly with component E.

X11SCA/X11SCA-F/X11SCA-W

Quick RefeRence Guide Rev. 1.0b

SUPERMICR R

COM1

JBT1

USB0/1 (2.0)

JPAC1

JPME2

JF1

JLED1

CPU SLOT6 PCI-E 3.0 X16

PCH SLOT2 PCI-E 3.0 X4

PCH SLOT7 PCI-E 3.0 X1

SLOT1 PCI 33MHZ

JWD1

JPG1

CPU

PCI-E_M.2-M2

PCI-E_M.2-M1

I-SATA5 I-SATA3 I-SATA1

CMOS CLEAR

I-SATA4 I-SATA2 I-SATA0

I-SATA7

I-SATA6

U.2-1

USB4/5 (3.0) USB8 (3.1,TypeC)

USB9 (3.1,TypeA)

SYS_FAN2

JPW1

SYS_FAN1

CPU_FAN1

DIMMA1

DIMMA2

DIMMB1

DIMMB2

CPU_FAN2

SYS_FAN3

JPW2

WIFI+BT (for X11SCA-W only)

JPL1

VGA (for X11SCA-F only)

DVI

PCI-E M.2-E1

HDMI

USB2/3(3.0) USB6/7(3.1)

LAN1

LAN2

AUDIO

JPL2

I-SGPIO1

I-SGPIO2

JSTBY1

SPKR

SP1

JTPM1

AUDIO_FP

JPI2C1

CPU SLOT4 PCI-E 3.0 X8 (IN X16)

JL1

JSD1

BMC_HB_LED

LED_PWR_SB

LED4

PWR_LED

JPG1

(Only for X11SCA-F)

Motherboard Layout and Features

=mounting hole

LGA 1151

I/O BACK PANEL

Xeon -E, CoreTM i3,

Pentium®and Celeron®

processor

Package contents

• One (1) Supermicro Motherboard

• Six (6) SATA Cables

• One (1) I/O Shield

• One (1) Quick Reference Guide

Connector Description

AUDIO FP Front Panel Audio Header

B3 Onboard Battery

COM1 COM Header

CPU SLOT4 PCI-E 3.0 x8 (INx16) PCI Express x16 Slot (PCI-E 3.0 x8 link)

CPU SLOT6 PCI-E 3.0 x16 PCI Express x16 Slot (PCI-E 3.0 x16 link) or PCI-E 3.0 x8 when Slot4 is

populated

PCH SLOT2 PCI-E 3.0 x4 PCI Express x4 Slot (Slot2 is shared with M.2-M1)

PCH SLOT7 PCI-E 3.0 x1 PCI Express x1 Slot

PCI SLOT1 33MHz PCI Slot, 32 Bit/ 33MHz with 5V single voltage

DP/HDMI DisplayPort Connector/High Denition Multimedia Interface (HDMI)

DVI Digital Video Interface

FAN 1 ~ 5 System/CPU Fan Headers (FAN1 and FAN2: CPU Fans)

HD AUDIO High Denition Audio (back panel)

I-SATA0~7 Intel®Serial ATA (SATA 3.0) Ports 0~7 (6Gb/sec)

I-SGPIO1/2 Serial General Purpose I/O Headers

JF1 Front Control Panel Header

JL1 Chassis Intrusion Header

JLED1 3-Pin Power LED

JPW1 24-pin ATX Main Power Connector (Required)

JPW2 +12V 8-pin CPU Power Connector (Required)

JSD1 SATA DOM (Disk On Module) Power Connector

JSTBY1 Standby Power Header

JTPM1 Trusted Platform Module (TPM) Header

LAN 1/2 Gb RJ45 Port

PCI-E M.2-M1,M2

PCI-E M.2 Connectors 1 and 2, small form factor devices and other

portable devices for high speed NVMe SSDs (M.2-M1 is shared with PCI-

Ex4 Slot)

PCI-E M.2-E1 WiFi+BT (for X11SCA-W only)

SP1 Internal Speaker/Buzzer

SPKR Header for Speaker/Buzzer (Pins 1~4: External Speaker, Pins 3~4: Buzzer)

U.2-1 U.2 Connector 1 for 2.5” SSD Drives (U.2 is shared with M.2-M2)

USB 0/1 Front Access USB 2.0 Header

USB 2/3 Back Panel USB 2.0/3.0 Ports

USB 4/5 Front Access USB 3.0/2.0 Header

USB 6/7 Back Panel USB 3.1 Ports (USB6: Type C, USB7: Type A)

USB 8/9 Front Access USB 3.1 Headers (USB8: Type C, USB9: Type A)

VGA VGA Port (for X11SCA-F, IPMI only)

Jumpers and Connectors

Jumpers

Jumper Description Default

JBT1 Clear CMOS (onboard) Short Pads to Clear CMOS

JPAC1 Audio Enable Pins 1-2 (Enabled)

JPG1 Disable BMC GFX Chip (for X11SCA-F only) Pins 1-2 (Enabled)

JPL1/2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled)

JPME2 Intel® Manufacturing Mode Pins 1-2 (Normal)

JWD1 Watch Dog Function Enable Pins 1-2 (RST)

Connectors

ContaCt InformatIon

• www.supermicro.com (Email: [email protected])

• Manuals: http://www.supermicro.com/support/manuals

• Drivers & Utilities: https://www.supermicro.com/wftp/driver/

• Safety: http://www.supermicro.com/about/policies/safety_information.cfm

The X11SCA/X11SCA-F/X11SCA-W motherboard supports a single Intel®Xeon-E, CoreTM i3, Pentium®, and Celeron®

series processor, up to 128GB of Unbuffered (UDIMM) ECC/Non-ECC DDR4 memory, and up to 2666MHz in four

288-pin memory slots. Populating these DIMM slots with a pair of memory modules of the same type and size will

result in interleaved memory, which will improve memory performance.

Note: 1) For memory optimization, use only DIMM modules that have been validated by Supermicro. For the latest memory updates, please

refer to our website at http://www.supermicro.com/products/motherboard.

2) Always connect the power cord last, and always remove it before adding, removing or changing any hardware components.

LED Indicators

LED Description Color/State

BMC_HB_LED BMC Heartbeat LED Green Blinking: Normal

LED4 UID (for X11SCA-F, IPMI only) Blue on: Unit Identied

LED_PWR_SB Onboard Standby PWR LED Green on: P3V3 Standby power ready

PWR_LED Onboard Power LED Green on: Power on

LED Indicators

CPU & Memory Support

Towards the CPU

Memory Population Guidelines

• Always use DDR4 DIMM modules of the same size, type, and speed.

• Mixed DIMM speeds can be installed. However, all DIMMs will run at the speed of the slowest DIMM.

Recommended Population (Balanced)

DIMMA1 DIMMB1 DIMMA2 DIMMB2 Total System Memory

2GB DIMM 2GB DIMM 4GB

2GB DIMM 2GB DIMM 2GB DIMM 2GB DIMM 8GB

4GB DIMM 4GB DIMM 8GB

4GB DIMM 4GB DIMM 4GB DIMM 4GB DIMM 16GB

8GB DIMM 8GB DIMM 16GB

8GB DIMM 8GB DIMM 8GB DIMM 8GB DIMM 32GB

16GB DIMM 16GB DIMM 32GB

16GB DIMM 16GB DIMM 16GB DIMM 16GB DIMM 64GB

32GB DIMM 32GB DIMM 64GB

32GB DIMM 32GB DIMM 32GB DIMM 32GB DIMM 128GB

DIMM Memory Installation

DIMMB2 (Gray Slot)

DIMMA2 (Gray Slot)

DIMMA1 (Black Slot)

DIMMB1 (Black Slot)

MNL-2087-QRG-10b

micro's written consent. All Trademarks are property of their respective entities. All information provided is deemed accurate at the time of printing;

however, it is not guaranteed.

Notes

• Graphics shown in this quick reference guide are for illustration only. Your components may or

may not look exactly the same as drawings shown in this guide.

• Refer to Chapter 2 of the User Manual for detailed information on jumpers, connectors, LED

indicators, memory support and CPU/motherboard installation instructions.

Power Button

OH/Fan Fail LED

NIC1 LED

Reset Button

Power Fail LED

HDD LED

Power LED

#3~4

#1~2

Vcc

Ground

1920

Vcc

Ground NMI

Vcc

NIC2 LED

Front Control Panel (JF1)

CPU Installation Heatsink Installation

Back Panel I/O Connectors

A. DisplayPort F. 1Gb RJ45 Port 1 K. Surround Out

B. HDMI Port G. USB 3.1 Port 6 (Type C)/

Port 7 (Type A)

L. S/PDIF Out

C. WiFi+BT (for X11SCA-W only) H. 1Gb RJ45 Port 2 M. Line In

D. VGA Port (for IPMI, X11SCA-F only) I. USB 3.0 Ports 2/3 N. Line Out

E. Digital Video Interface (DVI) J. Center/LFE Out O. Mic In

B C

X11SCA/-F/-W

Push down

Lock

Unlock

美超微電腦股份有限公司

X11SCA/X11SCA-F/X11SCA-W

快速參考指南版本 1.0

SUPERMICR R

COM1

JBT1

USB0/1 (2.0)

JPAC1

JPME2

JF1

JLED1

CPU SLOT6 PCI-E 3.0 X16

PCH SLOT2 PCI-E 3.0 X4

PCH SLOT7 PCI-E 3.0 X1

SLOT1 PCI 33MHZ

JWD1

JPG1

CPU

PCI-E_M.2-M2

PCI-E_M.2-M1

I-SATA5 I-SATA3 I-SATA1

CMOS CLEAR

I-SATA4 I-SATA2 I-SATA0

I-SATA7

I-SATA6

U.2-1

USB4/5 (3.0) USB8 (3.1,TypeC)

USB9 (3.1,TypeA)

SYS_FAN2

JPW1

SYS_FAN1

CPU_FAN1

DIMMA1

DIMMA2

DIMMB1

DIMMB2

CPU_FAN2

SYS_FAN3

JPW2

WIFI+BT (for X11SCA-W only)

JPL1

VGA (for X11SCA-F only)

DVI

PCI-E M.2-E1

HDMI

USB2/3(3.0) USB6/7(3.1)

LAN1

LAN2

AUDIO

JPL2

I-SGPIO1

I-SGPIO2

JSTBY1

SPKR

SP1

JTPM1

AUDIO_FP

JPI2C1

CPU SLOT4 PCI-E 3.0 X8 (IN X16)

JL1

JSD1

BMC_HB_LED

LED_PWR_SB

LED4

PWR_LED

JPG1

(Only for X11SCA-F)

主機板元件配置圖

=裝機孔

LGA 1151

I/O BACK PANEL

Xeon -E, CoreTM i3,

Pentium®and Celeron®

processor

Autres manuels pour X11SCA

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Supermicro Carte mère

Supermicro

Supermicro X10DRC-T4 Plus Manuel utilisateur

Supermicro

Supermicro X10SLM+-F Manuel utilisateur

Supermicro

Supermicro Supero X9SRH-7F Manuel utilisateur

Supermicro

Supermicro Supero X8DAH+-F Manuel utilisateur

Supermicro

Supermicro P4SPA Plus Manuel utilisateur

Supermicro

Supermicro Supero X10SRL-F Manuel utilisateur

Supermicro

Supermicro X11DPG-OT-CPU Manuel utilisateur

Supermicro

Supermicro X6DHP-TG Manuel utilisateur

Supermicro

Supermicro X7DB8-X Manuel utilisateur

Supermicro

Supermicro X12MP Manuel d'utilisation et d'entretien

Supermicro

Supermicro X11SPH-NCTPF Manuel utilisateur

Supermicro

Supermicro H11SSL-I/C/NC Manuel utilisateur

Supermicro

Supermicro H8SSP-8 Manuel utilisateur

Supermicro

Supermicro X5DPR-TG2 Plus Manuel utilisateur

Supermicro

Supermicro X11DPFF-SNR Manuel utilisateur

Supermicro

Supermicro H11DSi Manuel utilisateur

Supermicro

Supermicro Supero X8DTH-6F Manuel utilisateur

Supermicro

Supermicro H12SSG-AN6 Manuel utilisateur

Supermicro

Supermicro X10DRFF-iG Manuel utilisateur

Supermicro

Supermicro X6DHT-G Manuel utilisateur

Supermicro

Supermicro X11SAT Manuel utilisateur

Supermicro

Supermicro C7Z270-PG Manuel utilisateur

Supermicro

Supermicro X7DWN Plus Manuel utilisateur

Supermicro

Supermicro SuperO A1SAM-2750F Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
