SUPER
SUPER P6DLS
SUPER P6DLE
SUPER P6SLS
SUPER P6SLA
USER’S MANUAL
Revision 1.4
The information in this User’s Manual has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates.
SUPERMICRO COMPUTER reserves the right to make changes to the product described in
this manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL SUPERMICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF THE REPAIRING, REPLACING, OR
RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Unless you request and receive written permission from SUPERMICRO COMPUTER, you
may not copy any part of this document.
Information in this document is subject to change without notice. Other products and
companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 1998 by SUPERMICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America.
iii
Preface
About This Manual
This manual is written for system houses, PC technicians and
knowledgeable PC end users. It provides information for the instal-
lation and use of SUPER P6DLS/P6DLE/P6SLS/P6SLA
motherboard. SUPER P6DLS/P6DLE/P6SLS/P6SLA supports
Pentium II 233/266/300/333 MHz.
The Pentium II processor with the Dual Independent Bus Architec-
ture is housed in a new package technology called the Single Edge
Contact (S.E.C.) cartridge. This new cartridge package and its as-
sociated "Slot 1" infrastructure will provide the headroom for future
high-performance processors.
Manual Organization
Chapter 1, Introduction, describes the features, specifications and
performance of the SUPER P6DLS/P6DLE/P6SLS/P6SLA system
board, provides detailed information about the chipset, and offers
warranty information.
Refer to Chapter 2, Installation, for instructions on how to install the
Pentium II processor, the retention mechanism, and the heat sink
support. This chapter provides you with the instructions for han-
dling static-sensitive devices. Read this chapter when you want to
install or remove DIMM memory modules and to mount the system
board in the chassis. Also refer to this chapter to connect the floppy
and hard disk drives, IDE interfaces, parallel port, serial ports, as
well as the cables for the power supply, reset cable, Keylock/Power
LED, speaker and keyboard.
If you encounter any problem, please see Chapter 3, Troubleshoot-
ing, which describes troubleshooting procedures for video, memo-
ry, and the setup configuration stored in memory. Instructions are
also included on contacting a technical assistance support repre-
sentative and returning merchandise for service and the BBS# for
BIOS upgrades.
iv
SUPER P6DLS/P6DLE/P6SLS/P6SLA User’s Manual
Preface
Table of Contents
Preface
About This Manual ......................................................................................... iii
Manual Organization...................................................................................... iii
Quick Reference........................................................................................... viii
Chapter 1:
1-1 Overview............................................................................................... 1-1
SUPER P6DLS ............................................................................. 1-2
SUPER P6DLE ............................................................................. 1-3
SUPER P6SLA .............................................................................. 1-4
SUPER P6DLS Motherboard Layout........................................ 1-5
SUPER P6DLE Motherboard Layout........................................ 1-6
SUPER P6SLS Motherboard Layout ........................................ 1-7
SUPER P6SLA Motherboard Layout ........................................ 1-8
SUPER P6DLS Features............................................................ 1-9
SUPER P6DLE Features.......................................................... 1-11
SUPER P6SLS Features .......................................................... 1-13
SUPER P6SLA Features .......................................................... 1-15
1-2 PC Health Monitoring ...................................................................... 1-17
1-3 ACPI/PC 98 Features ...................................................................... 1-20
1-4 Chipset Overview.............................................................................. 1-22
1-5 Wake-on-LAN .................................................................................... 1-22
1-6 Power Supply .................................................................................... 1-22
1-7 National Semiconductor Super I/O................................................ 1-23
1-8 AIC 7880 SCSI Controller................................................................ 1-23
1-9 Warranty, Technical Support, and Service.................................. 1-24
Parts.............................................................................................. 1-24
BIOS .............................................................................................. 1-24
v
Labor............................................................................................. 1-25
Returns......................................................................................... 1-25
Chapter 2: Installation
2-1 Static-Sensitive Devices ................................................................... 2-1
Precautions ................................................................................... 2-1
Unpacking...................................................................................... 2-1
2-2 Pentium II Processor Installation................................................... 2-2
OEM Pentium II and Heat Sink Support.................................. 2-6
Removing the Pentium II Processor........................................ 2-7
2-3 Changing the CPU Speed ............................................................... 2-8
Turbo Function.............................................................................. 2-9
2-4 Mounting the Motherboard in the Chassis................................... 2-9
2-5 Connecting Cables............................................................................ 2-9
Power Supply Connector............................................................ 2-9
Infra-Red Connector ................................................................... 2-10
PW_ON Connector...................................................................... 2-11
Reset Connector ........................................................................ 2-11
Hard Drive LED .......................................................................... 2-12
Keylock/Power LED Cable Connector ................................... 2-12
Speaker Connector.................................................................... 2-13
SCSI LED..................................................................................... 2-13
Power Save State Select .......................................................... 2-13
ATX PS/2 Keyboard and Mouse Ports ................................... 2-14
Universal Serial Bus .................................................................. 2-14
ATX Serial Ports ......................................................................... 2-15
SMI................................................................................................. 2-15
CMOS Clear................................................................................. 2-16
External Battery ........................................................................... 2-16
Wake-on-LAN .............................................................................. 2-17
Fan Connectors.......................................................................... 2-17
vi
SUPER P6DLS/P6DLE/P6SLS/P6SLA User’s Manual
Table of Contents
vii
Chassis Intrusion Detector....................................................... 2-18
2-6 Installing/Removing the DIMM Modules...................................... 2-18
DIMM Module Installation.......................................................... 2-19
Removing DIMM Modules......................................................... 2-19
2-7 Connecting Parallel, FDD and HDD ............................................ 2-20
Parallel Port Connector ............................................................ 2-21
Floppy Connector ....................................................................... 2-22
IDE Interfaces ............................................................................. 2-23
SCSI Connectors......................................................................... 2-24
AGP Port....................................................................................... 2-26
Chapter 3: Troubleshooting
3-1 Troubleshooting Procedures ........................................................... 3-1
No Video ........................................................................................ 3-1
Troubleshooting Flowchart ........................................................ 3-2
Memory Error................................................................................. 3-3
Losing the System’s Setup Configuration.............................. 3-3
3-2 Technical Support Procedures........................................................ 3-4
3-3 Frequently Asked Questions............................................................. 3-4
3-4 Returning Merchandise for Service................................................. 3-7
viii
SUPER P6DLS/P6DLE/P6SLS/P6SLA User’s Manual
Quick Reference
Jumpers Function Page
JB1, JB2, JB3, JB4 CPU Speed Selection 2-8
JC1, JC2, JC3 External Bus Speed 2-8
JBT1 CMOS Clear 2-16
JP19 SMI 2-15
JP20 Power Save State
Select 2-13
JC4, JL2, JP17 Manufacturer Default 1-4
Connectors Function Page
J17 USB 2-14
J18 USB 2-14
J19 Printer Port 2-21
J20 COM 1 2-15
J21 COM 2 2-15
J32 ATX Power 2-9
J34 PS/2 KB and Mouse 2-14
JA1 UW SCSI 2-25
JA2 Ultra SCSI 2-24
JBT2 External Battery
Connector 2-16
JF1 IDE LED 2-12
Keylock 2-11
Speaker 2-12
JF2 IR Connector 2-10
PW_ON 2-10
Reset 2-11
JL1 Chassis Intrusion 2-18
JPA3 SCSI LED 2-13
JT1 CPU 1 Fan 2-17
JT2 CPU 2 Fan 2-17
JT3 Thermal/Overheat Fan 2-17
WOL Wake-on-LAN 2-17
1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
SUPER P6DLS/P6DLE supports dual Pentium II 233/266/300/333
MHz processors. SUPER P6SLS/P6SLA supports single Pentium
II. They are based on Intel’s 440 LX chipset which enables Acceler-
ated Graphics Port (AGP), Wake-on-LAN, SDRAM, concurrent PCI
and Ultra DMA 33 MB/s burst data transfer rate.
All motherboards are ATX size and have 4 PCI slots, 3 ISA slots and
an AGP connector. SUPER P6DLS, P6DLE and P6SLS accommo-
date a total of 1 GB EDO or 512 MB SDRAM memory with 4 168-pin
DIMM sockets. SUPER P6SLA accommodates a total of 768 MB
EDO or 384 MB SDRAM memory with 3 168-pin DIMM sockets.
AGP reduces contention with the CPU and I/O devices by broaden-
ing the bandwidth of graphics to memory. It delivers a maximum of
532 MB/s 2x transfer mode which is quadruple the PCI speed!
Wake-on-LAN allows remote network management and configura-
tion of the PC, even in off-hours when the PC is turned off. This
reduces the complexity of managing the network.
Other features that maximize customer satisfaction and simplicity in
managing the computer are PC 98-ready and support for Advanced
Configuration and Power Interface (ACPI). With PC Health Monitor-
ing, you can protect your system from problems before they even
occur.
Included I/O on all motherboards are 2 EIDE ports, a floppy port, an
ECP/EPP parallel port, PS/2 mouse and PS/2 keyboard, 2 serial
ports, an infrared port and 2 USB ports. SUPER P6DLS and P6SLS
provide an on-board Adaptec 2940UW Ultra Wide SCSI controller
with fast data transfer rate of up to 40 MB/s.
1-2
SUPER P6DLS/P6DLE/P6SLS/P6SLA User’s Manual
SUPER P6DLS
Figure 1-1. SUPER P6DLS Motherboard Picture
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Supermicro Carte mère
Supermicro
Supermicro X12DPFR-AN6 Manuel utilisateur
Supermicro
Supermicro Supero H8SMi-2 Manuel utilisateur
Supermicro
Supermicro M11SDV-4C-LN4F Manuel utilisateur
Supermicro
Supermicro C7B360-CB-M Manuel utilisateur
Supermicro
Supermicro H13SRD-F Manuel utilisateur
Supermicro
Supermicro X7DCT Manuel utilisateur
Supermicro
Supermicro X10DRT-B+ Manuel utilisateur
Supermicro
Supermicro X11SSN Series Manuel utilisateur
Supermicro
Supermicro SUPER P6SWA Manuel utilisateur
Supermicro
Supermicro H8DMT Manuel utilisateur
Supermicro
Supermicro X9DRX PLUS-F Manuel utilisateur
Supermicro
Supermicro X11DGQ Manuel utilisateur
Supermicro
Supermicro SUPERO X10DRU-X Manuel utilisateur
Supermicro
Supermicro X9SCA Manuel utilisateur
Supermicro
Supermicro PDSMU Manuel utilisateur
Supermicro
Supermicro X6DHR-3G2 Manuel utilisateur
Supermicro
Supermicro X10SDE-DF Manuel utilisateur
Supermicro
Supermicro X13SEW-TF Manuel utilisateur
Supermicro
Supermicro C7Z270-CG-M Manuel utilisateur
Supermicro
Supermicro X11DPU-XLL Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
