SUPER
P5MMA98/P5MMS98
P5MMA2/P5MMS2
AMI BIOS
REFERENCE MANUAL
Revision 1.1
The information in this User’s Manual has been carefully reviewed and is believed to be
accurate. The vendor assumes no responsibility for any inaccuracies that may be
contained in this document, makes no commitment to update or to keep current the
information in this manual, or to notify any person or organization of the updates.
The manufacturer reserves the right to make changes to the product described in this
manual at any time and without notice. This product, including software, if any, and
documentation may not, in whole or in part, be copied, photocopied, reproduced, translated
or reduced to any medium or machine without prior written consent.
IN NO EVENT WILL THE MANUFACTURER BE LIABLE FOR DIRECT, INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, THE VENDOR SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE
PRODUCT, INCLUDING THE COSTS OF THE REPAIRING, REPLACING, OR
RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Copyright © 1997 by SUPERMICRO COMPUTER INC.
All rights reserved.
Printed in the United States of America.
Unless you request and receive written permission from the manufacturer, you may not
copy any part of this document.
All products and company names mentioned are trademarks or registered trademarks of
their respective holders.
Do not upgrade the BIOS unless you are notified to do so. Please call technical
support first before upgrading the boot-block BIOS.
SUPER BBS # (408) 895-2022 (24 hours)
Baud Rate: 1200-14400 bps, Data Bits: 8, Stop Bit: 1, Parity: None
Table of Contents
Chapter 1: AMI BIOS
1-1 Introduction
System BIOS ....................................................................................... 1-1
Configuration Data............................................................................. 1-1
How Data Is Configured................................................................... 1-1
POST Memory Test ............................................................................ 1-2
1-2 BIOS Features...................................................................................... 1-3
BIOS Configuration Summary Screen ........................................... 1-4
Chapter 2: Running Setup
2-1 Setup
2-1-1 Standard Setup.................................................................. 2-1
2-1-2 Advanced Setup................................................................. 2-3
2-1-3 Chipset Setup .................................................................... 2-7
2-1-4 Power Management Setup............................................ 2-11
2-1-5 PCI/PnP Setup ................................................................. 2-14
2-1-6 Peripheral Setup ............................................................. 2-18
2-2 Security Setup
2-2-1 Supervisor/User................................................................ 2-22
2-2-2 Anti-Virus ........................................................................... 2-22
2-3 Utility Setup
2-3-1 Detect IDE.......................................................................... 2-23
2-3-2 Language........................................................................... 2-23
2-4 Default Setting
2-4-1 Optimal Default................................................................. 2-23
2-4-2 Fail-Safe Default............................................................... 2-23
SUPER P5MMA98/P5MMA2/P5MMS98/P5MMS2 User's Manual
iii
Table of Contents
iv
Appendix A: Hard Disk Error Messages ................ A-1
Appendix B: BIOS Hard Disk Drive Types.............. B-1
Appendix C: BIOS Error Beep Codes..................... C-1
Appendix D: AMI BIOS POST Diagnostic Error
Messages.......................................... D-1
Appendix E: BIOS Non-Fatal Error Messages........ E-1
PRINTED IN U.S.A.
1-1
Chapter 1: AMI BIOS
Chapter 1
AMI BIOS
1-1 Introduction
This chapter describes the AMIBIOS for the Intel 430 TX chipset
which is designed for an Intel Pentium®75/90/100/120/133/150/
166/180/200/233 MHz, Cyrix/IBM 5x86, 6x86, AMD-K5, AMD-K6 and
MMXTM processors. The AMI ROM BIOS is stored in the Flash
EEPROM and is easily upgraded using a floppy disk-based pro-
gram.
System BIOS
The BIOS is the basic input output system used in all IBM®PC,
XT™, AT®, and PS/2®compatible computers. The WinBIOS is a
high-quality example of a system BIOS.
Configuration Data
AT-compatible systems, also called ISA (Industry Standard Architec-
ture) must have a place to store system information when the
computer is turned off. The original IBM AT had 64 bytes of non-
volatile memory storage in CMOS RAM. All AT-compatible systems
have at least 64 bytes of CMOS RAM, which is usually part of the
Real Time Clock. Many systems have 128 bytes of CMOS RAM.
How Data Is Configured
AMIBIOS provides a Setup utility in ROM that is accessed by
pressing <Del> at the appropriate time during system boot. Setup
configures data in CMOS RAM.
1-2
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User's Manual
POST Memory Test
Normally, the only visible POST routine is the memory test. The
screen that appears when the system is powered on is shown
below.
An AMIBIOS Identification string is displayed at the left bottom
corner of the screen, below the copyright message.
081597 Pentium Mainboard
xxxxx KB OK
Hit <DEL> if you want to run SETUP
(C) American Megatrends Inc.,
XX-XXXX-XXXXXX-XXXXXXXX-XXXXXX-XXXX-X
1-3
Chapter 1: AMI BIOS
1-2 BIOS Features
•supports Plug and Play V1.0A
•supports V1.03 of the EPA Green PC specification
•supports V1.1 of the APM (Advanced Power Management)
specification. Power management features are implemented via
the System Management Interrupt (SMI). Sleep and Suspend power
management modes are supported. Power to the hard drives and
video monitors can be managed
•supports Intel PCI 2.1 (Peripheral Component Interconnect) lo-
cal bus specification
•supports pipelined burst synchronous and asynchronous SRAM
•supports FPM, EDO and SDRAM memories
•supports Flash ROM, 1 Mb flash memory
•supports DMI 2.0
•supports ACPI (Advanced Configuration and Power Interface)
1-4
SUPER P5MMA98/P5MMS98/P5MMA2/P5MMS2 User's Manual
BIOS Configuration Summary Screen
AMIBIOS displays a screen that looks similar to the following when
the POST routines complete successfully.
AMIBIOS System Configuration (C) 1985-1996 American Megatrends Inc.,
Main Processor :Pentium(P54C) Base Memory Size :640 KB
Math Processor :Built-In Ext. Memory Size :31744 KB
Floppy Drive A: :1.2 MB, 5¼ Display Type :VGA/EGA
Floppy Drive B: :1.44 MB, 3½ Serial Port(s) :3F8,2F8
ROM-BIOS Date: :07/15/95 Parallel Port(s) :378
Processor Clock: :166MHz Ext Cache :512KB,Enabled
Power Management: :APM, SMI
PCI Devices:
PCI Onboard Bridge Device PCI Onboard USB Controller
PCI Onboard IDE PCI Slot 3 VGA
Current CPU Temperature 35 °C
2-1
Chapter 2: Running Setup
Chapter 2
Running Setup
The WinBIOS Setup options described in this section are selected
by choosing the appropriate high-level icon from the Standard Setup
screen. All displayed icons are described in this section, although
the screen display is often all you need to understand how to set
the option.
2-1 Setup
2-1-1 Standard Setup
Pri Master
Pri Slave
Sec Master
Sec Slave
Choose these icons to configure the hard disk drive. When you
click on an icon, the following parameters are listed: Type, LBA/
Large Mode, Block Mode, 32Bit Mode, and PIO Mode. All
parameters relate to IDE drives except Type.
If the hard disk drive to be configured is an IDE drive, select the
appropriate drive icon, choose the Type parameter and select Auto.
The BIOS will automatically detect the IDE drive parameters and
display them. Click on the OK button to accept these parameters.
Click on LBA/Large Mode and choose On to enable support for IDE
drives with capacities greater than 528MB. Click on Block Mode
and choose On to support IDE drives that use Block Mode. Click on
32Bit Mode and click on On to support IDE drives that permit 32-bit
accesses.
