Supermicro BPN-SAS3-836EL Manuel utilisateur

1.0a

BPN-SAS3-836EL Backplane

USER'S GUIDE

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

1 2 3

A C A C

AFAE

YRKEA

1510

15202526

14 1

1 4

110

+ +

AEH

BAR CODE

WWN

DESIGNED IN USA

BPN-SAS3-836EL2

REV 1.01

S_HB_LED

J33 J32 J31 J30

J23 J22 J21 J20

MH4

MH3

MH2

MH1 MH13 MH5 MH6

MH12

MH9

MH10

MH7

MH11

MH8

D21

OVERHEAT_FAIL2

5V_LED1 12V_LED1

OVERHEAT_FAIL1

ACTLED1

J19J24

J35

J36

LT3 LT4

C21

PWR4 PWR3

PWR2

PWR1

J18

J34

PRI_I2C1

J17

EC9

EC8EC7

EC6 EC5

EC3

EC20 EC2EC19

EC18

EC17

EC16

EC15

EC14EC13 EC12 EC11

EC10

EC1

EC4

U48

HS1

HS2

J37

J27

J29

L12

L10

TP75

J28

SEC_J3

SEC_J1

SEC_J0

SEC_J2

PRI_J3

PRI_J2

PRI_J0

PRI_J1

S_ICE_HDR

S_SDB

S_UART

S_JTAG

S_MDIO

P_ICE_HDR

P_SDB

P_UART P_HB_LED

SMB

P_JTAG

P_MDIO

SECONDARY EXPANDER

P_MDIO

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.

The vendor assumes no responsibility for any inaccuracies that may be contained in this document,

makes no commitment to update or to keep current the information in this manual, or to notify any

person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product

described in this manual at any time and without notice. This product, including software, if any,

and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or

reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO

USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall

be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all

claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the manufacturer’s instruction manual, may cause harmful interference

with radio communications. Operation of this equipment in a residential area is likely to cause harm-

ful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warn-

ing applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate

Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Manual Revision 1.0a

Release Date: October 29, 2018

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

iii

Contents

Contacting Supermicro.......................................................................................iv

Returning Merchandise for Service.....................................................................v

Chapter 1 Safety Guidelines

1-1 ESD Safety Guidelines ................................................................................... 1-1

1-2 General Safety Guidelines .............................................................................. 1-1

1-3 Version ............................................................................................................ 1-2

Chapter 2 Jumper Settings and Pin Denitions

2-1 Front Connectors Locations............................................................................ 2-1

2-2 FrontConnectorandPinDenitions............................................................... 2-2

2-3 Front Jumper Locations and Settings............................................................. 2-3

Explanation of Jumpers .................................................................................. 2-3

2-4 Front LED Indicators....................................................................................... 2-4

2-5 Rear Connectors and LED Indicators............................................................. 2-5

Chapter 3 Dual Port and Cascading Congurations

3-1 Single and Dual Port Expanders..................................................................... 3-1

Single Ports..................................................................................................... 3-1

Dual Ports ....................................................................................................... 3-1

3-2 Failover............................................................................................................ 3-2

Single Host Bus Adapter................................................................................. 3-2

Single Host Bus Adapter Failover................................................................... 3-2

3-3 Failover with RAID Cards and Multiple HBAs ................................................ 3-3

Dual Host Bus Adapter .................................................................................. 3-3

Dual Host Bus Adapter Failover...................................................................... 3-3

3-4 Chassis Control Board .................................................................................... 3-4

3-5 Support Cables ............................................................................................... 3-5

Connecting an Internal HBA to the Backplane .............................................. 3-5

Supported Internal HBA Cables...................................................................... 3-6

Connecting an External HBA to the Backplane ............................................. 3-7

Single External Host Bus Adapter ............................................................. 3-7

Dual External Host Bus Adapter ............................................................... 3-7

Connecting Multiple Backplanes in a Single Channel Environment............... 3-8

SingleHBACongurationCables ................................................................... 3-9

Connecting Multiple Backplanes in a Dual Channel Environment ............... 3-10

BPN-SAS3-836EL Backplane Manual

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: +1 (408) 503-8000

Fax: +1 (408) 503-8008

Email: [email protected] (General Information)

[email protected] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: +31 (0) 73-6400390

Fax: +31 (0) 73-6416525

Email: [email protected] (General Information)

[email protected] (Technical Support)

[email protected] (Customer Support)

Web Site: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: +886-(2) 8226-3990

Fax: +886-(2) 8226-3992

Email: [email protected]

Web Site: www.supermicro.com.tw

Contents

Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning to

the manufacturer, the RMA number should be prominently displayed on the outside

of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling

charges will be applied for all orders that must be mailed when service is complete.

For faster service, RMA authorizations may be requested online (http://www.super-

micro.com/support/rma/).

Whenever possible, repack the backplane in the original Supermicro box, using the

original packaging materials. If these are no longer available, be sure to pack the

backplane in an anti-static bag and inside the box. Make sure that there is enough

packaging material surrounding the backplane so that it does not become damaged

during shipping.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

Duringthewarrantyperiod,contactyourdistributorrstforanyproductproblems.

BPN-SAS3-836EL Backplane Manual

Notes

1-1

Chapter 1 Safety Guidelines

Chapter 1

Safety Guidelines

To avoid personal injury and property damage, carefully follow all the safety steps

listed below when accessing your system or handling the components.

1-1 ESD Safety Guidelines

Electrostatic Discharge (ESD) can damage electronic components. To prevent dam-

age to your system, it is important to handle it very carefully. The following measures

aregenerallysufcienttoprotectyourequipmentfromESD.

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing a component from the antistatic

bag.

• Handle the backplane by its edges only; do not touch its components, peripheral

chips, memory modules or gold contacts.

• When handling chips or modules, avoid touching their pins.

• Put the card and peripherals back into their antistatic bags when not in use.

1-2 General Safety Guidelines

• Always disconnect power cables before installing or removing any components

from the computer, including the backplane.

• Disconnect the power cable before installing or removing any cables from the

backplane.

• Make sure that the backplane is securely and properly installed on the mother-

board to prevent damage to the system due to power shortage.

BPN-SAS3-836EL Backplane Manual

1-2

1-3 Version

The BPN-SAS3-836EL backplane has been designed to utilize the most up-to-date

technology available, providing your system with reliable, high-quality performance.

This manual reects SAS3-836EL1 and SAS3-836EL2 Revision 1.01, the most

current release available at the time of publication. Always refer to the Supermicro

Web site at www.supermicro.com for the latest updates, compatible parts and sup-

portedcongurations.

All images and layouts in this user's guide are based upon the latest PCB revision

available at the time of publishing. The backplane you have received may not look

exactly the same as the graphics in this manual.

2-1

Chapter2JumperSettingsandPinDenitions

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

CG1

PRESSFIT

CG2

CG3

123

1 2 3

A C A C

AFAE

YRKEA

1510

15202526

14 1

1 4

110

+ +

AEH

BAR CODE

WWN

DESIGNED IN USA

BPN-SAS3-836EL2

REV 1.01

S_HB_LED

J33 J32 J31 J30

J23 J22 J21 J20

MH4

MH3

MH2

MH1 MH13 MH5 MH6

MH12

MH9

MH10

MH7

MH11

MH8

D21

OVERHEAT_FAIL2

5V_LED1 12V_LED1

OVERHEAT_FAIL1

ACTLED1

J19J24

J35

J36

LT3 LT4

C21

PWR4 PWR3

PWR2

PWR1

J18

J34

PRI_I2C1

J17

EC9

EC8EC7

EC6 EC5

EC3

EC20 EC2EC19

EC18

EC17

EC16

EC15

EC14EC13 EC12 EC11

EC10

EC1

EC4

U48

HS1

HS2

J37

J27

J29

L12

L10

TP75

J28

SEC_J3

SEC_J1

SEC_J0

SEC_J2

PRI_J3

PRI_J2

PRI_J0

PRI_J1

S_ICE_HDR

S_SDB

S_UART

S_JTAG

S_MDIO

P_ICE_HDR

P_SDB

P_UART P_HB_LED

SMB

P_JTAG

P_MDIO

SECONDARY EXPANDER

P_MDIO

Chapter 2

Jumper Settings and Pin Denitions

2-1 Front Connectors Locations

1. Power connectors: PWR1, PWR2,

PWR3 and PWR4 (4-pin)

2. Primary SAS connectors: PRI_J0

(J20), PRI_J1 (J21), PRI_J2 (J22),

and PRI_J3 (J23)

3. Secondary SAS connectors: SEC_

J0 (J30), SEC_J1 (J31), SEC_J2

(J32), and SEC_J3 (J33)

4. Primary expander chip

5. Secondary expander chip

Figure 2-1. Front Connectors

6. I2C connector: PRI_I2C1 (4-pin)

7. Primary UART connector: UART_

P1 (J19; 4-pin)

8. Secondary UART connector:

UART_S1 (J35; 4-pin)

9. Primary SDB (J24, 4-pin)

10. Secondary SDB (J36, 4-pin)

11. SMB connector: JBOD controller

(J17, 4-pin)

12. Overheat_Fail2 (2-pin)

BPN-SAS3-836EL Backplane Manual

2-2

2-3. SAS Connectors

The primary and secondary sets of SAS connectors provide expander features

including cascading and failover.

4-5. Expander Chips

These primary and secondary expander chips allow the backplane to support

dual ports, cascading, and failover.

6-10. I2C Connector, UART Connectors, SDB Connectors

The I2C connector, the UART connectors, and the SDB connectors are for manu-

facturing diagnostic purposes only.

11. SMB Connector

This header provides for a connection with an optional JBOD controller board.

12. OVERHEAT_FAIL2 Connector

This header can be connected to an external overheat LED, if desired.

2-2 Front Connector and Pin Denitions

Backplane

Main Power

4-Pin Connector

Pin#Denition

1+12V

2 and 3 Ground

4 +5V

1. Backplane Main Power Connectors

The 4-pin connectors, designated PWR1,

PWR2, PWR3 and PWR4, provide power

to the backplane. See the table on the right

forpindenitions.
