Sunsea AIoT SimCom SIM7090G-EVB Kit Manuel utilisateur

SIM7090G-EVB Kit

User Guide

SIMCom Wireless Solutions Limited

Building B, SIM Technology Building, No.633, Jinzhong Road

Changning District, Shanghai P.R.China

Tel: 86-21-31575100

support@simcom.com

www.simcom.com

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 1 -

Document Title: SIM7090G-EVB Kit User Guide

Version: 1.00

Date: 2020-05-09

Status: Release

GENERAL NOTES

SIMCOM OFFERS THIS INFORMATION AS A SERVICE TO ITS CUSTOMERS, TO SUPPORT

APPLICATION AND ENGINEERING EFFORTS THAT USE THE PRODUCTS DESIGNED BY SIMCOM.

THE INFORMATION PROVIDED IS BASED UPON REQUIREMENTS SPECIFICALLY PROVIDED TO

SIMCOM BY THE CUSTOMERS. SIMCOM HAS NOT UNDERTAKEN ANY INDEPENDENT SEARCH

FOR ADDITIONAL RELEVANT INFORMATION, INCLUDING ANY INFORMATION THAT MAY BE IN THE

CUSTOMER’S POSSESSION. FURTHERMORE, SYSTEM VALIDATION OF THIS PRODUCT DESIGNED

BY SIMCOM WITHIN A LARGER ELECTRONIC SYSTEM REMAINS THE RESPONSIBILITY OF THE

CUSTOMER OR THE CUSTOMER’S SYSTEM INTEGRATOR. ALL SPECIFICATIONS SUPPLIED

HEREINARE SUBJECT TO CHANGE.

THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION WHICH IS THE PROPERTY

OF SIMCOM LIMITED., COPYING OF THIS DOCUMENT AND GIVING IT TO OTHERS AND THE USING

OR COMMUNICATION OF THE CONTENTS THEREOF, ARE FORBIDDEN WITHOUT EXPRESS

AUTHORITY. OFFENDERS ARE LIABLE TO THE PAYMENT OF DAMAGES.ALLRIGHTS RESERVED IN

THE EVENT OF GRANT OF A PATENT OR THE REGISTRATION OF A UTILITY MODEL OR DESIGN.

ALL SPECIFICATION SUPPLIED HEREIN ARE SUBJECT TO CHANGE WITHOUT NOTICE AT ANY

TIME.

SIMCom Wireless Solutions Limited

Building B, SIM Technology Building, No.633 Jinzhong Road, Changning District, Shanghai P.R.China

Tel: +86 21 31575100

Email: simcom@simcom.com

For more information, please visit:

https://www.simcom.com/download/list-863-en.html

For technical support, or to report documentation errors, please visit:

https://www.simcom.com/ask/or email to: support@simcom.com

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 2 -

Version History

Date Version Description of change Author

2020-5-9 1.00 Origin Tu Hongjun

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 3 -

Contents

Contents......................................................................................................................................................- 3 -

Figure Index................................................................................................................................................- 4 -

SCOPE........................................................................................................................................................- 5 -

1. SIM7090G-EVB Overview...................................................................................................................... - 6 -

2. EVB Accessory....................................................................................................................................... - 8 -

3. Accessory Interface................................................................................................................................- 9 -

3.1 Power Interface.................................................................................................................................- 9 -

3.2 Audio Interface..................................................................................................................................- 9 -

3.3 SIM Card Interface..........................................................................................................................- 10 -

3.4 UART Port Interface.........................................................................................................................- 11 -

3.5 USB Interface..................................................................................................................................- 12 -

3.5 Power Switch ..................................................................................................................................- 13 -

3.6 PWRKEY Button.............................................................................................................................- 13 -

3.8 LED Indicator ..................................................................................................................................- 13 -

4. Driver Installations................................................................................................................................- 14 -

4.1 EVB KIT USB driver installation...................................................................................................... - 14 -

5. FW Update............................................................................................................................................- 16 -

5.1 Select module platform and firmware path..................................................................................... - 16 -

6. Using SIMCom Serial Port Tool............................................................................................................ - 19 -

7. Test Case..............................................................................................................................................- 20 -

7.1 PDN Auto- activation....................................................................................................................... - 20 -

7.2 Ping Tests........................................................................................................................................ - 21 -

7.3 TCP Functions.................................................................................................................................- 21 -

7.4 MQTT Functions ............................................................................................................................. - 22 -

7.5 GNSS Function Test........................................................................................................................ - 23 -

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 4 -

Figure Index

FIGURE 1: SIM7090G-EVB TOP VIEW.....................................................................................................- 6 -

FIGURE 2: SIM7090G-EVB BOTTOM VIEW.............................................................................................- 6 -

FIGURE 3: EVB ACCESSORY...................................................................................................................- 8 -

FIGURE 4: AUDIO INTERFACE.................................................................................................................- 9 -

FIGURE 5: VIRTUAL SERIAL PORTS..................................................................................................... - 11 -

FIGURE 6: MICRO USB PORT................................................................................................................- 12 -

FIGURE 7: SIM7090 DEVICES RECOGNIZED BY THE OPERATING SYSTEM ..................................- 14 -

FIGURE 8: BROWSE FOR THE DRIVERS.............................................................................................- 15 -

FIGURE 9: ALL DRIVERS INSTALLED....................................................................................................- 15 -

FIGURE 10: SELECT PLATFORM USING LOAD SECTION..................................................................- 16 -

FIGURE 11: BROWSING FW LOCATION ...............................................................................................- 16 -

FIGURE 12: START THE UPDATE ..........................................................................................................- 17 -

FIGURE 13: UPDATE SUCCESS WILL BE APPEAR. ............................................................................- 17 -

FIGURE 14: SIMCOM SERIAL PORT TOOL INTRODUCTION ...........................................................- 19 -

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 5 -

SCOPE

THIS DOCUMENT DESCRIBES HOW TO USE SIMCOM EVB AND TE BOARDS TO DO TEST; USER

CAN GET USEFUL INFOABOUT SIM7090G QUICKLY THROUGH THIS DOCUMENT.

THIS DOCUMENT IS SUBJECTTO CHANGE WITHOUT NOTICEATANY TIME.

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 6 -

1. SIM7090G-EVB Overview

Figure 1: SIM7090G-EVB TOP view

Figure 2: SIM7090G-EVB BOTTOM view

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 7 -

A: Micro USB Connector

B: UART Port jack

C: PWRKEY

D: Power switch

E: MODULE

F: Handset jack

G: GNSS ANT Interface

H: LTE ANT Interface

P: POWER LED indicator

T: STATUS LED indicator

N: NETLIGHT LED indicator

S：SIM Card holder

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 8 -

2. EVB Accessory

Figure 3: EVB Accessory

A: SIM7090G-EVB

B: GNSS antenna

C: USB Cable

D: LTE antenna

SIM7090G EVB Kit User Guide V1.00

www.simcom.com

- 9 -

3. Accessory Interface

3.1 Power Interface

Both USB interface (A) and UART Port interface (B) provide power supply for EVB.

Pin Signal I/O Description

A and B USB power Input I 5V/0.5A DC Source Input

3.2 Audio Interface

Figure 4:Audio Interface
