Stûv P-10.2 - installation [en] - 03/20
Standards, certification and technical specifications (continued)
Requirements relating to the electrical power supply
Voltage 230 V
Frequency 50 Hz
Electric power consumption on ignition 1000 W
Electrical power consumption under normal operation 40W
Requirements relating to fuel
Recommended fuel Wood pellets only
Certification Din plus, EN plus A1
Diameter 6 mm
Materials and main components
The Stûv P-10 consists mainly of:
> Painted steel sheets/tubes for
structural and facing elements
> The bottom facings are available in
a oak-veneered wood panel finish
(light or dark)
> Vermiculite for the inside of the
combustion chamber
> Cast steel for the structural elements
of the burner
> Aluminium for the smoke extraction
flue
> HDPE for the Pellet hopper
> Remote control with PP body and
PC screen, lithium-ion battery.
> A trim finishing kit is available to
trim the bottom facings. In this case,
the installer should check that the
material chosen corresponds to the
use for which it is intended.
All of these components are
deemed to be compliant within
tolerances and national practices.
Stûv P-10 marking
Stûv S.A Rue Jules Borbouse 4, 5170 Bois-de-Villers
15
Notifi ed Body 1881
Declaration of performance number : 15QA151478501
EN 14785 : 2006
Stûv P-10
Read and follow operating instructions
Use only recommended fuel :
Wood pellets diameter 6 mm, quality standard EN plus A1
Version française disponible dans la notice d’utilisation
Nederlandse versie beschikbaar in de gebruikersgids
Deutsche Version in der Installationsanleitung
La versione italiana è disponibile all’interno della guida utente
Versión española disponible en el manual del usuario
Versão portuguesa disponível no Manual do Utilizador
Česká verze je k dispozici v uživatelské příručce
Wersja polska dostępna w instrukcji obsługi
Heating output nominal
nominal
nominal
nominal
peak
reardr
ηnom
8.0kWPnom
COnom
Tnom
0.001%
217°
90.5%
1000W
230V
70mm
2.4kWPpart
COpart
Tpart
0.028%
94°
94.5%
40W
50Hz
100mm
1000mm
reduced
reduced
reduced
reduced
average
sidesds
ηpart
frontdf
Measured CO
(at 13% oxygen content)
Average temperature of the
smoke at the appliance’s
outlet
Minimum clearance distance
from combustible materials
Turntable appliance : 1000 mm
in range of inspection window
Appliance effi ciency
Rated input power
Rated voltage
Rated frequency
Stûv has a determinedly proactive
responsible environmental apprach.
We think about the end-of-life of our
products.
Each of the device's components can
be isolated so that sorting can be
carried out and therefore optimum
recycling.
Removal of the various parts must
be done in accordance with local and
national regulations.
