Stewart Filmscreen Cima Instructions originales

PDF provided by Conference Room AV

Stewart Filmscreen 00900-1092H Cima 92" Fixed Frame Projection Screen (White) - 16:9 HDTV

TO THE INSTALLER: BE SURE TO LEAVE THIS MANUAL WITH THE OWNER.

To the Owner

Installation Instructions

Screen Care

Maintenance

Fixed Frame Screen

Owner’s Manual &

Installation Instructions

CFS-0415

Wall mount (standard screen attachment)

Aperture mount

At the designated point in the installation, you will need to refer to the

general instructions for attaching the screen to the frame.

TO THE OWNER

Using this manual for installation

For the frame and mount type, refer to the appropriate page:

Congratulations on your purchase of one of our highly versatile Cima

projection screens representing "Top of the Class" in standard

commercial and residential projection screens.

Please take a moment to review this manual as it will help ensure you

many years of trouble-free service from your new Cima by Stewart

Filmscreen product.

This manual includes and describes proceduresfor several types of

frames and mounts. You must refer to the appropriate section for the

type of Cima Fixed Frame you are installing. In addition, there are

general instructions for attaching the screen to the frame that are

provided in a separate section. This procedure is to be performed at a

specific step in the overall sequence.

To the Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Printed in U.S.A.

www.stewartfilmscreen.com.

Stewart Filmscreen reserves the right to make changes to the product specified in this document.

Sizes and specifications subject to change without notice at Manufacturer's discretion. From time to time, this

document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at:

Contents

Assembling the Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Mounting the Frame . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Attaching the Screen To Frame. . . . . . . . . . . . . . . . . . . . . . . . . 9

Adjusting the Screen Fabric . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Attaching the back support to the frame (where required) . . . . 11

Screen Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Mounting the Frame - Section View . . . . . . . . . . . . . . . . . . . . . 7

General Notes for Preparing the Installation . . . . . . . . . . . . . . . 4

Product Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Aperture Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

General Instructions For Attaching Screen To Frame . . . . . . . 8

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Preparation

Check the specifications for the type of frame and mounting to be

used.

You will need:

A level

Fasteners appropriate for the surface on which the screen is

being mounted (See instructions for the type of mount for

recommendations.)

Tools for tightening fasteners

Unpacking

Be sure to unpack carefully in a clean area. Use special care when

handling the screen so that it does not become soiled or damaged.

If you plan to repack your screen and hardware for transportation to another

location, you may wish to photograph or make a note of how it was packed.

Keep the packing material.

GENERAL NOTES FOR PREPARING THE INSTALLATION

Before proceeding with the installation of this screen,

take time to thoroughly read and understand these

installation and operation instructions.

Drill for making holes to attach brackets to the mounting surface,

as needed

Check the size and weight of the screen to be installed so that

you can plan for the number of people required for the mounting

procedure. You need at least two people to mount the smaller

screens; more are needed for larger, heavier screens.

Make sure there is a clean surface on which to unroll the screen

and assemble the frame.

Specifications regarding the individual screen dimensions, weight, and

mounting type are provided by the factory when the unit is ordered.

Before beginning the installation:

Note: Bolts and other fasteners for the screen are standard gauge and

sizes used in the U.S., regardless of where they will be installed. For this

reason, the sizes are expressed in inches rather than metric measurements.

Ladders for the personnel supporting the screen during the

mounting process, as needed

Clean cotton gloves, for handling the screen

Cima Fixed Frame Screen: Owner’s Manual

MOUNTING THE FRAME

Wall mount

1. Identify the location of wall studs where you can securely mount

the wall bracket.

2. Use a level to accurately position the wall bracket on the wall.

4. Drill holes in the wall through the bracket into the stud.

5. Use appropriate fasteners to secure the wall bracket to the wall

stud.

6. Check to make sure the bracket is level.

7. Hang the assembled frame, without the screen attached, on the

wall bracket to ensure that it is correctly mounted.

9. Reposition the frame, and slide the magnets so that they align

with the steel disks mounted on the wall.

10. Follow the steps for attaching the screen to the frame.

Holes drilled for wall mount

Hanging bracket

Follow the procedures for the type of mount you will use: wall mount or

aperture mount.

Figure 2: Wall bracket

To accurately position the frame, you will mount the wall bracket and temporarily

attach the frame prior to attaching the screen fabric. Holes for supporting the

bracket are not pre-drilled; you can drill holes so that the frame mounting is

attached to wall studs. On the bottom of the frame, there are magnets you

canslide to align with wall studs; fasten the steel disks to the wall where studs

are located. If the wall is not perfectly flat, the force of the magnet may cause

the frame to bend. For this reason, wall puck shims (similar to washers) are

provided for you to place between thewall and the steel puck so that the frame

lays completely flat. The screen should not be attached to the frame at this

point. Refer to Figures 2,3,and 4.

8. Remove the frame. Drill holes so you can attach the steel disks

that will hold the magnets on the frame. Use wall puck shims as

needed.

3. Mark the desired position of the bracket on the wall. Mark the

location of the studs where you willdrill to attach the bracket.

Mark where you will attach the steel disks to the magnets which

will fasten to the frame.

MOUNTING THE FRAME - SECTION VIEW

Figure 3:Components for wall mount Figure 4: Hang the frame on wall mount

Cima Fixed Frame Screen: Owner’s Manual

Standard attachment

Keep in mind that this procedure applies to several types of frames, so

the appearance of your frame may be somewhat different than that

shown in the illustrations.

Unpacking and unrolling the screen

The viewing side of the projection screen is rolled to the inside to protect

the optical coating. The screen is rolled lengthwise.

Caution

Be careful not to touch or scratch the image surface

with fingernails.

Do not use any tools to fasten the screen to the frame.

Do not fold or crease the screen.

1. Remove the screen

from the cardboard

shipping tube.

2. On a clean floor,

unroll screen viewing

side up.

This section provides the general instructions for attaching the screen to

the frame. DO NOT perform this step UNTIL instructed to do so in the

section for the specific type of mount you are using.

GENERAL INSTRUCTIONS FOR ATTACHING SCREEN TO FRAME

Figure 10:Unrolling the screen

3. Allow the paper to

unroll between

screenback and the

floor. (This will keep

thescreen clean.)

Referto Figure 10.

Attaching the screen to frame

The next step is to attach the screen to the frame.

1. Place the frame

over the screen.

Figure 11:Lifting frame to snap on screen; top corner first

2. While lifting the

frame with one

hand, snap the

screen into the

frame. Gently allow

the screen to

stretchonto the

snaps. Do not jerk

the material, as it

can rip. Refer to

Figure11. Attach

the snaps on the top

corners and top

horizontal first.

Figure 12:Attaching all top snaps first

3. Lift the frame to a

vertical position to

finish attaching the

sides and bottom

rows of the snaps.

Refer to Figure 12.

Cima Fixed Frame Screen: Owner’s Manual
