StetSom BRAVO FULL 5000 Manuel utilisateur
2
English
Introduction
system.
Before installing
Please read this manual carefully.
OFF.
If you have quesons , contact the store where the purchase or
installaon was done. For more informaon please contact our
Customer Service: BR +55 18 2104-9412.
3
1. COOLERs:
2. RCA JACK INPUT:
3. LEVEL:
4. CROSSOVER:
HIGH PASS FILTER (H.P.F.):
10Hz ~ 90Hz
LOW PASS FILTER (L.P.F.):
90Hz ~ 12KHz
5. BASS BOOST:
BASS: 0dB ~ +10dB.
FREQ: BASS30Hz ~ 70Hz.
6. FLAT KEY: FLAT
made on the CROSSOVER and BOOST
using this mode.
7. OUTPUT CONNECTOR (SPEAKERS):
Input, output and audio controls
543 6 72
1. COOLER 1. COOLER
4
Power input
8. POSITIVE POWER SUPPLY CONNECTOR:
00 AWG
9. REMOTE CONNECTOR (REM):
18 AWG.
10. NEGATIVE POWER SUPPLY CONNECTOR:
00 AWG.
venlaon venlaon
98 10
5
blink
1x
blink
3x
blink
4x
blink
2x
POWER (blue LED):
PROT (top red LED):
protecon
table below
CLIP (lower red LED):
Indicators LED
Smart protection system
the PROT LED
Diagnostic: Short circuit or output overload.
Diagnostic: Supply voltage less than 9V.
Solution: Check that the speaker cables are well insulated and that the output
impedance does not exceed that supported by the amplier.
Solution: Check voltage of baery or power supply.
Solution: Check if the amplier is in a venlated place or if the coolers are not
obstructed. Keep the amplier turned on for a few minutes for the coolers to
assist in the cooling process.
Solution: Check voltage of baery or power supply.
Diagnostic: Excessive temperature. When the amplier reaches approximately
194°F, audio is stopped and the coolers run at maximum speed to speed up the
cooling process of the internal components.
Diagnostic: Supply voltage greater than 16V.
6
Installaon should only be done by qualied professionals with the
product turned OFF.
Instalation
connectors........................................
Remote connector ......................................................................
..........................................
The use of a fuse or circuit breaker is mandatory to protect the system from short
circuits and overload. Install them as close to the baery as possible.
00 AWG
18 AWG
7 AWG
REM
Radio / Player
18 AWG cable
Baery
STETSOM
REM (remote)
POWER
GROUND
00 AWG cable
00 AWG cable
RECOMMENDED USE
OF AUXILIARY BATTERY.
Recommended fuse
BRAVO 5000
250A
BRAVO 8000
400A
(maximum
12” of baery)
FUSE
Ground
7
Troubleshooting
AMPLIFIER DOES NOT TURN ON:
have electrical and mechanical contact.
NO SOUND:
LEVEL control is not at a minimum.
PROT LED FLASHING:
SPEAKERS
INPUT RCA
Check the minimum impedance
supported by the amplier.
7 AWG cables
Radio / Player
STETSOM
8
SOUND DISTORTIONS:
a)
b)
goes out completely.
WEAK OF BASS:
NOISE AND FAILURE IN SOUND:
original
as it may cause interference and noise in the audio signal.
Images contained in this manual are merely illustrave and may dier from the actual product.
Any updates made in this manual will be available for customers to consult free of
charge on the brand’s site.
It is recommended that the updated manual be consulted whenever needed.
The data measured are based on STETSOM laboratory equipment. Test reference
in frequency from 60hz to 1Khz with THD + N at ≤1% in impedances as indicated in
each measurement. The electronic components and the manufacturing process may
present manufacturing variaons, thus leading to a variaon in the measurements
made.
9
Level (db)
Frequency (Hz)
output
1
200mV
>90dB
10Hz ~ 12KHz
90Hz ~ 12KHz
10Hz ~ 90Hz
Freq: 30Hz ~ 70 Hz
Boost: 0dB ~ +10dB
12K Ohms
9V ~ 16V DC
3.14” x 9.11” x 13.11”
9.36 lb
5300W RMS @ 2 Ohms
3000W RMS @ 4 Ohms
5000W RMS @ 2 Ohms
2600W RMS @ 4 Ohms
5300W RMS @ 1 Ohm
3300W RMS @ 2 Ohms
5000W RMS @ 1 Ohm
2800W RMS @ 2 Ohms
242A
485A
227A
445A
Technical specications
1 OHM 2 OHMs
5000
BRAVO FULL
0
+ 2
+ 4
+ 6
+ 8
+ 10
- 2
- 4
- 6
- 8
- 10
10 20 30 50 100 200 300 500 1K 2K 3K 5K 10K 20K 30K 50K 100K
10
output
1
200mV
>90dB
10Hz ~ 12KHz
90Hz ~ 12KHz
10Hz ~ 90Hz
Freq: 30Hz ~ 70 Hz
Boost: 0dB ~ +10dB
9V ~ 16V DC
3.14” x 9.11” x 16.49”
13.2 lb
8700W RMS @ 2 Ohms
4400W RMS @ 4 Ohms
8000W RMS @ 2 Ohm
4200W RMS @ 4 Ohms
8600W RMS @ 1 Ohm
5100W RMS @ 2 Ohms
8000W RMS @ 1 Ohm
4400W RMS @ 2 Ohms
370A
740A
14K Ohms 13K Ohms
360A
720A
Technical specications
1 OHM 2 OHMs
8000
BRAVO FULL
Level (db)
Frequency (Hz)
0
+ 2
+ 4
+ 6
+ 8
+ 10
- 2
- 4
- 6
- 8
- 10
10 20 30 50 100 200 300 500 1K 2K 3K 5K 10K 20K 30K 50K 100K
