StetSom BRAVO Full 2000 Manuel utilisateur
2
English
Introduction
system.
Before installing
Please read this manual carefully.
OFF.
If you have quesons , contact the store where the purchase or
installaon was done. For more informaon please contact our
Customer Service: BR +55 18 2104-9412.
3
1. RCA JACK INPUT:
2. LEVEL:
3. CROSSOVER:
HIGH PASS FILTER (H.P.F.):
10Hz ~ 90Hz
LOW PASS FILTER (L.P.F.):
90Hz ~ 22KHz
4. BASS BOOST:
BASS: 0dB ~ +10dB.
FREQ: BASS30Hz ~ 70Hz.
5. FLAT KEY: FLAT
made on the CROSSOVER and BOOST
using this mode.
6. OUTPUT CONNECTOR (SPEAKERS):
Input, output and audio controls
432 5 61
venlaonvenlaon
4
Power input
7. COOLERs:
8. POSITIVE POWER SUPPLY CONNECTOR:
4 AWG
9. REMOTE CONNECTOR (REM):
18 AWG.
10. NEGATIVE POWER SUPPLY CONNECTOR:
4 AWG.
7. COOLER 98 10
venlaon
5
blink
1x
blink
3x
blink
4x
blink
2x
POWER (blue LED):
PROT (top red LED):
protecon
table below
CLIP (lower red LED):
Indicators LED
Smart protection system
the PROT LED
Diagnostic: Short circuit or output overload.
Diagnostic: Supply voltage less than 9V.
Solution: Check that the speaker cables are well insulated and that the output
impedance does not exceed that supported by the amplier.
Solution: Check voltage of baery or power supply.
Solution: Check if the amplier is in a venlated place or if the coolers are not
obstructed. Keep the amplier turned on for a few minutes for the coolers to
assist in the cooling process.
Solution: Check voltage of baery or power supply.
Diagnostic: Excessive temperature. When the amplier reaches approximately
194°F, audio is stopped and the coolers run at maximum speed to speed up the
cooling process of the internal components.
Diagnostic: Supply voltage greater than 16V.
6
Installaon should only be done by qualied professionals with the
product turned OFF.
Instalation
connectors........................................
Remote connector ......................................................................
..........................................
..............................................................
The use of a fuse or circuit breaker is mandatory to protect the system from short
circuits and overload. Install them as close to the baery as possible.
4 AWG
18 AWG
9 AWG
120A
REM
Radio / Player
18 AWG cable
Baery
RECOMMENDED USE
OF AUXILIARY BATTERY.
(maximum
12” of baery)
STETSOM
REM (remote)
POWER
GROUND
4 AWG cable
4 AWG cable
Fuse
120A
Ground
Because it is a sensive lter, aach
the ferrite so that it is secure and
protected from possible impacts.
7
Ferrite instalation
(maximum 2” of
audio connecon)
SPEAKERS
INPUT RCA
Check the minimum impedance
supported by the amplier.
Radio / Player
Ferrite
STETSOM
9 AWG cables
8
Troubleshooting
AMPLIFIER DOES NOT TURN ON:
have electrical and mechanical contact.
NO SOUND:
LEVEL control is not at a minimum.
PROT LED FLASHING:
SOUND DISTORTIONS:
a)
b)
goes out completely.
WEAK OF BASS:
NOISE AND FAILURE IN SOUND:
original
as it may cause interference and noise in the audio signal.
9
Images contained in this manual are merely illustrave and may dier from the actual product.
Any updates made in this manual will be available for customers to consult free of
charge on the brand’s site.
It is recommended that the updated manual be consulted whenever needed.
The data measured are based on STETSOM laboratory equipment. Test reference
in frequency from 60hz to 1Khz with THD + N at ≤1% in impedances as indicated in
each measurement. The electronic components and the manufacturing process may
present manufacturing variaons, thus leading to a variaon in the measurements
made.
10
Level (db)
Frequency (Hz)
output
1
200mV
>90dB
10Hz ~ 22KHz
90Hz ~ 22KHz
10Hz ~ 90Hz
Freq: 30Hz ~ 70 Hz
Boost: 0dB ~ +10dB
9V ~ 16V DC
3.14” x 9.11” x 7.75”
4.96 lb
2750W RMS @ 2 Ohms
1600W RMS @ 4 Ohms
2115W RMS @ 2 Ohm
1140W RMS @ 4 Ohms
2600W RMS @ 1 Ohms
1720W RMS @ 2 Ohms
2015W RMS @ 1 Ohm
1330W RMS @ 2 Ohms
108A
217A
108A
217A
Technical specications
1 OHM 2 OHMs
2000
BRAVO FULL
12K Ohms 10K Ohms
0
+ 2
+ 4
+ 6
+ 8
+ 10
- 2
- 4
- 6
- 8
- 10
10 20 30 50 100 200 300 500 1K 2K 3K 5K 10K 20K 30K 50K 100K
