StarTech.com SV431USBAE Manuel utilisateur

StarView USB KVM Switch

SV431USBAE Instruction Manual

Actual product may vary from photo

4 Port StarView USB KVM Switch With Audio

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aannddootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other protected names

and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur

these references are for illustrative purposes only and do not represent an endorsement of a

product or service by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks,

registered trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Instruction Manual

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements: Console Side . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements: Computer Side . . . . . . . . . . . . . . . . . . . . . . . .1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Console Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting Slave Computers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Auto Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Optional: Rack Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Instruction Manual

Thank you for purchasing a StarTech.com 4 port USB KVM Switch with Audio. Providing

simple, centralized control of up to 4 computers from a single display and USB peripheral

set (Keyboard and Mouse), SV431USBAE supports audio switching and USB device

sharing between connected computers, providing rich multimedia capability and cost-

effectiveness.

IInnttrroodduuccttiioonn

•Audio switching with microphone and speaker connectivity

Features

System requirements: Console Side

•One VGA, SVGA or Multisync monitor

Package contents:

•1 X 4 Port StarView USB KVM Switch With Audio

This package should contain:

•Integrated USB 2.0 hub allows you to share up to three high-speed USB devices

between computers

•Supports resolutions up to 1920x1440 pixels

•Compatible with all USB supported Operating Systems

•Auto-scan function automatically selects computer sequentially

System requirements: Computer Side

•One USB keyboard

•One USB mouse

•One HDB15 male-to-female VGA cable for monitor

•One USB A-B cable with Type-A and Type-B plug for USB devices

•1 X Power Adapter 5V DC 2.0A

•1 X Instruction Manual

Instruction Manual

IInnssttaallllaattiioonn

PC BIOS Notice: The following BIOS setup changes are necessary for PC

users but are not required for Mac users:

1) In STANDARD CMOS, set HALT ON ERROR to ALL BUT KEYBOARD.

2) In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set the USB

IRQ to ENABLED.

Please note: SV431USBAE is capable of switching between computers while

maintaining USB mouse and keyboard control. If you plan to share other

peripherals such as a CCD camera, printer or scanner, you must shut down the

corresponding driver on the computer from which KVM control is being

switched.

Because port switching is equivalent to unplugging the USB cable from one

computer and plugging it in on another, some USB drivers continuously check

attached USB peripherals and do not accept plug and play functionality.

Console Connection

Before installation, please ensure that all devices and computers to be connected to the

KVM Switch have been turned off.

1) Connect the monitor that will be used to the Console VGA port on the rear panel of

SV431USBAE.

2) Connect a USB keyboard and a USB mouse to any two of the Console USB ports as

shown below:

USB Keyboard

USB Mouse

USB Device

Instruction Manual

Connecting Slave Computers

1) Connect the VGA port located on the rear panel of SV431USBAE to the VGA port

provided by the video connection on the desired computer, using an HDB15 male-to-

female cable. Please note the PC Port number, for steps 2 and 3.

2) Using a USB A-B Cable, connect the USB port that corresponds with the PC port

used in step 1, to the USB port on the corresponding computer, as shown below.

3) Optional: Using an audio cable (Speaker and Mic), connect the Speaker and Mic

ports provided by the PC port used in step 1 on SV431USBAE to the

Speaker and Mic ports located on the computer.

One USB patch cable for

both mouse and keyboard

Male-to-female

HDDB15 for VGA

Audio cable (Speaker and Mic)

4) Repeat steps 1-4 as necessary for each computer you wish to connect. Once all

computers have been connected, you can turn on all devices and computers.

OOppeerraattiioonn

Front Panel

1. Online and Selected LEDs: When the LED turns green, the connected computer is

powered on. When a computer is selected, the

corresponding (red) LED will illuminate.

Each computer has a button associated with it on the

front panel for selection.

2. Pushbuttons:

Auto Scan

Auto Scan automatically scans through the connected computers individually, in a fixed

interval.

Please note: Keyboard and Mouse are not operable during Auto Scan.

To activate Auto Scan, press down the 3and 4buttons (on the front panel)

simultaneously. To exit Auto Scan, tap any one of the pushbuttons.

To change the Scan Time interval, press both front panel buttons 1and 2simultaneously.

Instruction Manual

The switch will beep 1, 2, 3 or 4 times for Scan Times of 3, 8, 15 or 30 seconds

respectively.

OOppttiioonnaall::RRaacckkMMoouunnttIInnssttaallllaattiioonn

The following illustration depicts how to attach optional mount brackets and cable support

for rack mounting SV431USBAE. To do so, you may wish to use SV431RACK (please

see Accessory Products from StarTech.com for further information).

1To the Rack Cabinet back post

2USB or Monitor cables to switch

3Two screws secure the cable

support

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading

solutions. If you ever need help with your product, visit www.startech.com/support and access our

comprehensive selection of online tools, documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a three-year warranty. In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial date of purchase. During this period, the

products may be returned for repair, or replacement with equivalent products at our discretion. The warranty covers

parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

LLiimmiittaattiioonnooffLLiiaabbiilliittyy

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors,

employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or

otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product

exceed the actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or

consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply

to you.

SSppeecciiffiiccaattiioonnss

Computers supported 4

Front panel push buttons 4

Hot plug-and-play supported Ye s

Automatic scan interval 3, 8, 15, 30 seconds

Cable Length (Max) 30M(100ft) for VGA

5M(15ft) for USB

Computer ON-LINE LED 4

Computer selected LED 4

Resolution supported 1920 X 1440, DDC2B

Computer peripheral connector

Monitor

USB Type B x 4

HDB-15 male x 4

SPEAKER Jack x 4

MIC Jack x 4

Console peripheral connector

monitor

USB Type A x 4

HDB-15 female x 1

SPEAKER Jack x 1

MIC Jack x 1

Weight (g)

(oz.)

1000

35.27

H x W x D (mm)

(in.)

44 x 220 x 130

1.7 x 8.7 x 5.1

5 September 2007 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”.

Since 1985, we have been providing IT professionals with the quality products

they need to complete their solutions. We offer an unmatched selection of

computer parts, cables, server management solutions and A/V products and

serve a worldwide market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products and to

access exclusive interactive tools such as the Parts Finder and the KVM

Reference Guide. StarTech.com makes it easy to complete almost any IT

solution. Find out for yourself why our products lead the industry in performance,

support, and value.
