ICUSB23216FD

16-Port USB-to-Serial Adapter Hub

with Daisy Chain Support

*actual product may vary from photos

Quick-start guide

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Quick-start guide

Table of Contents

Introduction............................................................................................1

Package contents...................................................................................................................................... 1

System requirements............................................................................................................................... 2

RS-232 pinout............................................................................................................................................. 2

Product diagram ....................................................................................3

Front view .................................................................................................................................................... 3

Back view...................................................................................................................................................... 3

About the LED indicators......................................................................4

Installation ..............................................................................................4

Install the USB serial hub with the power adapter ....................................................................... 4

Install the USB serial hub with the terminal block power .......................................................... 5

Conrm installation.................................................................................................................................. 5

Use the daisy chain feature ..................................................................6

Perform a serial loopback test .............................................................6

Install the serial hub in a server rack ..................................................7

Technical support...................................................................................8

Warranty information............................................................................8

Quick-start guide

Introduction

The ICUSB23216FD adds 16 RS232 serial ports with data transfer rates up to 921.6

Kbps and can be controlled by a desktop or laptop computer system using a single

USB port. The durable metal chassis ts into standard 19-inch server storage racks for

an organized industrial USB to COM port solution, and supports an extended -40oC to

85oC (-40oF to 185oF) operating temperature range that allows for reliable use even in

harsh environments.

The ICUSB23216FD also features daisy chain capability, allowing you to connect

multiple devices through a single USB port.

Package contents

• 1 x 16-port USB to RS232 hub

• 1 x USB cable

• 2 x rack mounting brackets

• 8 x rack mounting screws

• 2 x DIN rail mounting brackets

• 4 x DIN rail mounting screws

• 4 x washers

• 4 x nuts

• 1 x universal power adapter (NA/EU/UK/AU)

• 1 x driver CD

• 1 x terminal block plug

• 1 x quick-start guide

Quick-start guide

System requirements

• USB-equipped host computer system

• Any of the following operating systems:

• Windows® 10 (32-bit or 64-bit)

• Windows 8.1 (32-bit or 64-bit)

• Windows 8 (32-bit or 64-bit)

• Windows 7 (32-bit or 64-bit)

• Windows XP (32-bit or 64-bit)

• Windows Vista®

• Windows Server® 2012

• Windows Server 2008 R2

• Windows Server 2003

• Mac OS 10.7 and later (tested up to 10.11)

• Linux® 3.5

System requirements are subject to change. For the latest requirements, please visit

www.startech.com/ICUSB23216FD.

RS-232 pinout

PIN Signal

1 DCD

2 RxD

3TxD

4DTR

5 GND

6 DSR

7RTS

8CTS

9 RI

Quick-start guide

Product diagram

Front view

DB9 serial connectors

1 to 16

USB Type-B connector

(host)

USB Type-A connector

(daisy chain)

Receive LEDs

(yellow)

Transmit LEDs

(green)

Back view

DC power connector

2-wire terminal block

(9~36V DC input)

Quick-start guide

Installation

You can use the power adapter or the terminal block power input (9~36V DC) to power

the USB serial hub. You can also use redundant power input by connecting both the

power adapter and the terminal block power, and in the event that your power source

fail, the USB serial hub will switch to use the secondary power source.

Install the USB serial hub with the power adapter

Warning! Make sure that the driver installation is complete before you plug in and

connect the USB serial hub.

1. Insert the provided driver CD into your host computer.

Note: The CD should automatically open and display all of the folders contained on the

CD. If that doesn’t happen, navigate to the CD/DVD drive on your computer.

2. In the driver folder, double-click the appropriate setup le for the OS that you’re

currently running. The driver installation wizard will begin installing the driver and

automatically closes when the installation is complete.

3. Connect the provided USB cable to the USB Type-B host port on the USB serial hub

and the USB port on your computer.

4. Connect the universal power adapter to the DC power connector on the USB serial

hub and a wall outlet.

About the LED indicators

The ICUSB23216FD features a set of transmit and receive LEDs for all of the 16 ports.

For more information about what the LEDs signify, see the table below.

LED LED behavior Signicance

Transmit LED (yellow)

Blinking Data is being transmitted

through the port.

Not illuminated No data is being transmitted

through the port.

Receive LED (green)

Blinking Data is being received through

the port.

Not illuminated No data is being received

through the port.

Quick-start guide

Conrm installation

Windows OS

1. On your computer, navigate to Device Manager.

2. Expand the Ports (COM & LPT) option.

3. Verify that the additional COM ports are listed.

4. Double-click a port and review the device properties.

Mac OS

1. On your computer, press and hold the Option key and click the Apple menu.

2. Click System Information or System Proler.

3. Under Hardware, click USB.

The USB device tree lists all of the devices connected to each port.

Install the hub using the terminal block power input

Warning! Make sure that the driver installation is complete before you plug in and

connect the USB serial hub.

1. Insert the provided driver CD into your host computer.

Note: The CD should automatically open and display all of the folders contained on the

CD. If that doesn’t happen, navigate to the CD/DVD drive on your computer.

2. In the driver folder, double-click the appropriate setup le for the OS that you’re

currently running. The driver installation wizard will begin installing the driver and

automatically closes when the installation is complete.

3. Connect the provided USB cable to the USB Type-B host port on the USB serial hub

and the USB port on your computer.

4. If the terminal block connector is already inserted in the USB serial hub, use a small

at-head screwdriver to loosen the screws to the left and right of the terminal block

connector until you can remove it from the USB serial hub.

5. Use a small at-head screwdriver to loosen the two screws located on the top of the

terminal block connector.

6. Connect the positive and negative wires from your DC power source to the proper

terminal block connectors.

Note: Make sure that the polarity of the input power, positive (+) and negative (-), is

matched correctly with the terminal block pins.

7. Tighten the two screws located on the top of the terminal block connector.

8. Reinsert the terminal block connector into the USB serial hub and tighten the

screws to the left and right of the terminal block connector.

Quick-start guide

Perform a serial loopback test

To verify that a port is operational and to map the ports, you should perform a serial

loopback test. A loopback test sends and receives data from the same serial port. To

complete the loopback test, you need to temporarily connect pins two and three to

allow the signals to be sent and received on the same port.

To perform a serial loopback test, you need a loopback adapter and a third-party

software program (for example, PuTTY or HyperTerminal).

1. Download a third-party software program.

2. Open a connection on the COM port that you want to test.

3. Insert the loopback adapter into a serial port.

4. Type something in the third-party software.

If what you typed is displayed in the window, you have located the correct port. If the

text isn’t displayed in the window, move the adapter to another port and try again

until you nd the correct port.

Use the daisy chain feature

The ICUSB23216FD includes a daisy chain feature, allowing you to connect one

ICUSB23216F serial hub or up to two ICUSB23216FD serial hubs. You can daisy chain up

to three USB serial hubs, for a total of 48 ports.

1. Connect the ICUSB23216FD to your host computer. For more information about

how to do this, see “Installation.”

2. Connect a USB cable to the USB Type-A connector on the ICUSB23216FD

connected to your host computer and to the USB Type-B connector on the serial

hub that you want to daisy chain.

3. If you’re connecting a third serial hub, connect a USB cable to the USB Type-A

connector on the second serial hub and to the USB Type-B connector on the third

serial hub that you want to daisy chain.

4. On each of the USB serial hubs, connect the universal power adapter to the DC

power connector or the terminal block power input and a wall outlet.

Quick-start guide

Install the serial hub in a server rack

The ICUSB23216FD comes with the necessary hardware to install the serial hub in a

regular server rack or a DIN rail.

1. To mount the serial hub, do one of the following:

• Use the rack mounting screws to attach the two rack mounting brackets to

both sides of the serial hub.

• Use the DIN rail mounting screws to attach the two DIN rail mounting brackets

to both sides of the serial hub.

2. To install the serial hub, follow the instructions that came with your server rack or

DIN rail.

Table des matières

Autres manuels StarTech.com Changer

StarTech.com

StarTech.com SV231DDVDUA Manuel utilisateur

StarTech.com

StarTech.com SV431DPUA Manuel utilisateur

StarTech.com

StarTech.com StarView SV221DVI Manuel

StarTech.com

StarTech.com MSTDP122DP Manuel utilisateur

StarTech.com

StarTech.com StarView SV211KA Manuel

StarTech.com

StarTech.com ST3300U3S Instructions d'installation

StarTech.com

StarTech.com SV211KDVI Manuel utilisateur

StarTech.com

StarTech.com SV211HDUC Manuel utilisateur

StarTech.com

StarTech.com DuraView RACKCONS1708 Manuel utilisateur

StarTech.com

StarTech.com SV431DPUA2 Manuel utilisateur

StarTech.com

StarTech.com ICUSB23208FD Manuel utilisateur

StarTech.com

StarTech.com VS424HDPIP Manuel utilisateur

StarTech.com

StarTech.com SV431DL2DU3A Manuel utilisateur

StarTech.com

StarTech.com 5G7AINDRM-USB-A-HUB Manuel utilisateur

StarTech.com

StarTech.com VS221HD4KA Manuel utilisateur

StarTech.com

StarTech.com SV231DVIUDDM Manuel utilisateur

StarTech.com

StarTech.com 5G7AIBS-USB-HUB-EU Manuel utilisateur

StarTech.com

StarTech.com StarView SV231USBGB Manuel utilisateur

StarTech.com

StarTech.com SV431HDU3A2 Manuel utilisateur

StarTech.com

StarTech.com HB30C3APDW Manuel utilisateur

StarTech.com

StarTech.com RS24102V Manuel utilisateur

StarTech.com

StarTech.com SV231HU34K6 Manuel utilisateur

StarTech.com

StarTech.com VS221HD2VGA Manuel utilisateur

StarTech.com

StarTech.com StarView SV221DVIDD Manuel

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
