Video Scaler/Converter

DVI2DVI Instruction Manual

DVI to DVI-I PC/HD Scaler Video Converter

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Connecting Devices to the Scaler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Using the Scaler/Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Input Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Picture Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

H/V Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

OSD Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

System Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Auto Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com DVI to DVI-I scaler video converter. This

product allows you to convert between a DVI-D source signal and DVI-I(digital + analog

RGB) output. The input resolution is automatically detected while the output resolution

and refresh rate can be selected through an on-screen menu with the buttons located on

the front of the panel.

FFeeaattuurreess

• Converts DVI-D video input to DVI-I signal output. A DVI-D source can be

displayed onto a DVI-I display, supporting a variety of resolutions

• 48MB frame memory for frame rate conversion

• Input resolution is automatically detected while output resolution and refresh rate can

be selected through an on-screen display menu and front panel push buttons

• On-screen display allowing adjustments to brightness, contrast, color and

Horizontal/Vertical positioning

• DVI output enables an entirely digital rendering of video without the losses associated

with an analog interface

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• A DVI video source

• A display capable of using a DVI-I signal

• Cables necessary to make connections between input, scaler and display

Contents

• DVI2DVI scaler video converter

• 1 x DVI Cable

• 1 x 5V DC 2Amp Power Adapter

• 1 x User Manual

Instruction Manual

IInnssttaallllaattiioonn

These instructions assume that the display has at least one available input that uses a

DVI-I video signal, and that all the devices have their cables attached. You may need to

disconnect an existing device from the display to make an input available and re-connect

that device using the video scaler.

Connecting Devices to the Scaler

1. Place the scaler near the display and the devices you wish to use with the scaler.

2. Connect the input device (i.e. a DVD player) to the connector labeled DVI Input on the

back of the video scaler converter.

3. Connect the scaler to your display device, using the port marked DVI OUTPUT on the

front of the scaler. If you require a VGA resolution output, use a DVI to VGA adapter

and VGA to VGA cable to make this connection (see Accessory

Products available from StarTech.com).

4. Connect the power adapter (provided) to the port marked DC 5V on the back of the

video scaler. Connect the opposite end to a wall outlet or other suitable power source.

The red light located next to the DC 5V output will illuminate once the scaler is

powered.

5. If you are using a DVI-I display, the scaler converter is now ready to use. If you are

using an RGB (VGA) display, adjustments will be required from within the On-screen

menu (Please see Menu and Adjustments)

Instruction Manual

Front

Back

UUssiinnggtthheeVViiddeeooSSccaalleerr

Once you have connected the desired input and output devices to the video scaler, you

can proceed to test the connection to the television or other display. Turn on the display,

and select the input to which you connected the video switch. Consult the

documentation for your display if you are unsure on how to select A/V inputs. Usually,

there will be a button on the display’s remote or front panel labeled INPUT or A/V. If the

display has multiple inputs, you will need to ensure the input you have selected

corresponds to the connectors on the television you used for the scaler. Power on the

devices you connected to the video scaler. Pressing the MENU button located on the

front of the scaler converter will bring up the on-screen display controls on the screen as

follows:

Using the +or - buttons, move the cursor to your desired selection, then press Menu to

confirm your selection and enter the corresponding sub-menu. Once selected, each

parameter can be adjusted by using the +or -buttons to increase the setting value.

Input set up

When selected, a sub-menu for selecting either YPbPr or RGB as your input signal will

appear. Note: This scaler video converter will automatically detect your input signal,

however manual adjustment of this setting is available by using the + or - buttons located

on the front panel of the scaler video converter.Pressing Menu will save your selection

and exit this sub-menu.

Output set up

When selected, a sub-menu will appear giving you options as to the desired output,

either DVI-A (analog) or DVI-D (digital). Once you have selected the appropriate output

signal, use the + or - buttons to choose the correct resolution/refresh rate. The following

output refresh rates/resolutions are available:

Instruction Manual

Input Setup

Output Setup

Picture Adjust

HV Adjust

OSD Adjust

System Information

Auto Adjust

Exit

PC (RGBHV) HDTV (YPbPr, RGBHV)

VGA

VESA85

VGA70

SVGA

XGA

Mac

WXGA

1280A

SXGA

640x480

640x400

720x400

800x600

1024x768

1152x864

1280x768

1280x960

1280x1024

60/72/75/85 Hz

85 Hz

70 Hz

60/72/75/85 Hz

60/70/75/85 Hz

70/75 Hz

60 Hz

60/75 Hz

1080i -RGB

720p -RGB

576p -RGB

480p -RGB

1080i -YPbPr

720p -YPbPr

576p -YPbPr

480p -YPbPr

1920x1080

1280x720

720x576

720x480

1920x1080

1280x720

720x576

720x480

60 Hz

50 Hz

60 Hz

50 Hz

60 Hz

Output modes available for DVI-A (Analog)

Instruction Manual

Pressing Menu will save your selection and return you to the main menu.

Picture Adjust

This sub-menu allows you to adjust the contrast, brightness and color of the displayed

image. Using the + and - buttons, select the attribute you wish to change, and use the

Menu button to confirm your selection. Use the + or -buttons to increase or decrease

the amount of the element you are modifying, followed by the Menu button to save.

Repeat this procedure for each element as desired. Once you have made the necessary

adjustments, use the + or -button to navigate to the Exit, which will take you back to the

main menu. NOTE: using the Reset feature will return all adjustments back to the factory

reset values.

HV Adjust

When chosen, a sub-menu will appear, allowing you to adjust the best horizontal and

vertical position of the picture, using the + or -buttons.

OSD Adjust

Allows you to adjust the horizontal and vertical position of the on-screen menu.

System Information

Displays the input and output resolutions and their vertical refresh rate on the screen.

Auto Adjust

When chosen, the scaler will automatically adjust all parameters to the factory preset

values.

Exit

When selected, exits the on-screen display

VGA

VESA85

VGA70

SVGA

XGA

Mac

WXGA

1280A

SXGA

640x480

640x400

720x400

800x600

1024x768

1152x864

1280x768

1280x960

1280x1024

60/72/75/85 Hz

85 Hz

70 Hz

60/72/75/85 Hz

60/70/75/85 Hz

70/75 Hz

60 Hz

60/75 Hz

1080i -RGB

720p -RGB

576p -RGB

480p -RGB

1920x1080

1280x720

720x576

720x480

60 Hz

50 Hz

60 Hz

PC (RGBHV) HDTV (RGBHV)

Output modes available for DVI-D (Digital)

SSppeecciiffiiccaattiioonnss

Input Resolutions:

Output Resolutions:

*HDTV YPbPr format is only available on Analog output

Input Format: Digital RGBHV, YPbPr or YCbCr

Input Signal: Digital RGB data bitstream

Input Connector: 24-pin DVI-D connector

Output Format: Analog RGBHV + Analog RGBHV or YPbPr(through DVI to

HD-15 adapter)

Output Signal:Digital data bitstream

Output Connector: 24-pin DVI-D connector

Power: 5V 2A center-positive

Instruction Manual

VGA

VESA85

VGA70

SVGA

XGA

Mac

WXGA

1280A

SXGA

640x480

640x400

720x400

800x600

1024x768

1152x864

1280x768

1280x960

1280x1024

60/72/75/85 Hz

85 Hz

70 Hz

60/72/75/85 Hz

60/70/75/85 Hz

70/75 Hz

60 Hz

60/75 Hz

1080i

720p

576p

480p

576i

480i

1920x1080

1280x720

720x576

720x480

720x576

720x480

60 Hz

50 Hz

60 Hz

50 Hz

60 Hz

Digital PC (RGBHV) HDTV (YPbPr, RGBHV)

VGA

VESA85

VGA70

SVGA

XGA

Mac

WXGA

1280A

SXGA

640x480

640x400

720x400

800x600

1024x768

1152x864

1280x768

1280x960

1280x1024

60/72/75/85 Hz

85 Hz

70 Hz

60/72/75/85 Hz

60/70/75/85 Hz

70/75 Hz

60 Hz

60/75 Hz

1080i

720p

576p

480p

1920x1080

1280x720

720x576

720x480

60 Hz

50 Hz

60 Hz

PC (RGBHV) HDTV (RGBHV) *

TTrroouubblleesshhoooottiinngg

If you’re having difficulty using the video scaler, try the following solutions based on the

nature of the problem.

No image is being shown on the display.

1) Ensure the video scaler is plugged in and receiving power. One LED indicator on the

front panel will be lit when the switch is receiving power.

2) Try selecting another input on the display and verify which input the scaler is

connected to. Most displays will have their A/V inputs marked with a number, so

ensure the input selected on the screen matches the physical connection between the

scaler and the display.

3) Verify cable connections between the input device, video scaler and display are snug.

Video quality is poor.

1) Verify cable connections between the input device, video scaler and display are snug.

2) Using lengthy cables may cause signal degradation. Try to locate the scaler as close

to the input device and display, as possible.

3) Enter the Picture Adjust sub-menu, ensure that Contrast, Brightness and Color are

set appropriately.

4)Ensure that the proper input signal is selected in the Input Setup sub-menu.

Instruction Manual

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

ZENDVI1

Cable ZEN 3.3 ft (1m) DVI Digital Video Cable

ZENDVI2

Cable ZEN 6.6 ft (2m) DVI Digital Video Cable

ZENDVI4

Cable ZEN 13.1 ft (4m) DVI Digital Video Cable

DVIVGAMM6

6 Ft. DVI to VGA Analog Flat Panel Display Cable

DVIVGAMF

DVI to VGA Display Adapter

Instruction Manual

Table des matières

Autres manuels StarTech.com Convertisseur de média

StarTech.com

StarTech.com ET91000SM40 Manuel utilisateur

StarTech.com

StarTech.com PIB2M21 Manuel utilisateur

StarTech.com

StarTech.com VGA2VID Manuel utilisateur

StarTech.com

StarTech.com 8STSDI2HD Manuel utilisateur

StarTech.com

StarTech.com ET9003SM Manuel du système

StarTech.com

StarTech.com USB32DVCAPRO Manuel utilisateur

StarTech.com

StarTech.com VGA2HDPRO2 Manuel utilisateur

StarTech.com

StarTech.com VID2HDCON Manuel utilisateur

StarTech.com

StarTech.com ET91000SC Manuel utilisateur

StarTech.com

StarTech.com 8STET91000LCOAM Manuel utilisateur

StarTech.com

StarTech.com ET90110SC2 Manuel utilisateur

StarTech.com

StarTech.com ET1000SM40LC Manuel du système

StarTech.com

StarTech.com HDMI2HDMI Manuel utilisateur

StarTech.com

StarTech.com POESLT1G48V Manuel utilisateur

StarTech.com

StarTech.com ET91000SM10 Manuel utilisateur

StarTech.com

StarTech.com ET91000SM40 Manuel utilisateur

StarTech.com

StarTech.com IMC100MSFP Manuel utilisateur

StarTech.com

StarTech.com CPNT2VGAA Manuel utilisateur

StarTech.com

StarTech.com VID2VGATV3 Manuel utilisateur

StarTech.com

StarTech.com CONVERGEAV CPNTA2HDMI Manuel utilisateur

StarTech.com

StarTech.com VGA2TV2WAY2 Manuel utilisateur

StarTech.com

StarTech.com MCM1110SFP Manuel utilisateur

StarTech.com

StarTech.com IPUSB2VGA Manuel utilisateur

StarTech.com

StarTech.com ET90110ST Manuel du système

Manuels Convertisseur de média populaires d'autres marques

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuel utilisateur

SPROLINK

SPROLINK VA1 Manuel utilisateur

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuel utilisateur

Nikon

Nikon AF-S TC-20E III Manuel utilisateur

Axis

Axis AXIS Q7406 Manuel utilisateur

Omega

Omega TAC80B-J Manuel utilisateur

Zoom

Zoom Thunderbolt TAC-2R Manuel utilisateur

OST

OST iConverter 10/100M Manuel utilisateur

Vertiv

Vertiv Netsure Manuel utilisateur

birddog

birddog MINI Manuel utilisateur

Roland

Roland GI-10 Manuel utilisateur

Wallenstein

Wallenstein WX310 Manuel utilisateur

Pace

Pace MSS 200-1 Manuel utilisateur

Solar Converters

Solar Converters EQ 12/24-50 Manuel utilisateur

CYP

CYP EL-7400V Manuel utilisateur

TIE

TIE MIDI 1i1o Manuel utilisateur

DCS

DCS Vivaldi Upsampler Manuel utilisateur

Westermo

Westermo MCW-211 SERIES Manuel utilisateur
