SAT32MSAT257

mSATA SSD to 2.5in SATA SSD Converter

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Product Diagram ....................................................................................1

Front View .................................................................................................................................................... 1

Rear View...................................................................................................................................................... 1

Introduction............................................................................................2

Packaging Contents ................................................................................................................................. 2

System Requirements.............................................................................................................................. 2

mSATA SSD Installation.........................................................................2

Hard Drive Initialization........................................................................4

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Product Diagram

Front View

Rear View

1. SATA DATA & Power Combo (7+15 pin)

2. Side mounting holes

1. mSATA SSD Connector

2. Drive installation bracket

3. Top mounting holes

Instruction Manual

Introduction

Packaging Contents

• 1 x mSATA SSD to 2.5in SATA SSD Converter

• 1 x Mounting screw kit

• 1 x Instruction Manual

System Requirements

• mSATA Drive

• SATA Host Device

mSATA SSD Installation

WARNING! SSD Drives and storage adapters require careful handling. If you are

not careful with your SSD Drive, lost data may result. Always handle your drive with

caution. Be sure that you are properly grounded by wearing an anti-static strap when

handling computer components or discharge yourself of any static electricity build-up

by touching a large grounded metal surface (such as the computer case) for several

seconds.

1. Slide the mSATA connector on the SSD into the mSATA receprical connector on the

SAT32M257.

Instruction Manual

2. Press the drive down toward the drive mounting bracket, and drive the two smaller

screws included in the screw kit through the mounting holes on your SSD drive and

into the drive mounting bracket using a Philips head screw driver (not included).

3. The SSD has now been installed, and is ready to be implemented in your 2.5” SATA

drive application.

Refer to the manual for your SATA host device for installation instructions. The top or

side mounting holes and included screw kit may, or may not be required to assist in

your installation

Instruction Manual

Hard Drive Initialization

If the mSATA SSD is new or otherwise blank, it may need to be initialized and formatted

before use. Follow the steps below in a Windows interface to initialize the drive.

1. From the main Windows desktop, right-click on “My Computer” (“Computer” in Vista/

7 / 8), then select Manage. In the new Computer Management window, select Disk

Management from the left window panel.

2. A dialog window should automatically appear, asking you to initialize the drive.

Depending on the version of Windows, it will give you the option of either creating

an “MBR” or“GPT” disk. GPT (GUID partition) is not compatible with some older

operating systems, while MBR is supported by newer and older operating systems.

3. Once initialized, locate the Disk that says it is “Unallocated” (check the listed hard

drive capacity to conrm it’s the correct hard drive) and then right-click in the

section that says “Unallocated” and select “New Partition”.

4. Follow the on screen prompts to initialize the drive in the format of your choice.

Instruction Manual

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials

and workmanship for the periods noted, following the initial date of purchase.

During this period, the products may be returned for repair, or replacement with

equivalent products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old and

new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they need

to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to

the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products and

to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
