StarTech.com ST124UTPE Manuel

UTP Cat5 Extender & Splitter

4/8-port Ethernet VGA Signal Extender & Splitter

ST124UTPE

ST128UTPE Instruction Guide

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Connecting Your VGA Extender and Splitter . . . . . . . . . . . . . . . . . . . 3

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com VGA Cat5 Splitter/Extender. Combined with

one or more StarTech.com remote receivers (STUTPRXL - sold separately), you can

display the image from a computer or other VGA image source on multiple remote

displays at distances of up to 1000 feet (300 meters). With no drivers or software to

install, this VGA Extender offers simple setup and crystal-clear images at resolutions of

up to 1280 x 1024 pixels.

Features

• Display the image from a local computer on multiple remote displays at distances up to

1000ft (300m)

• Hardware-only solution: no drivers or software to install or configure

• Uses industry-standard Category 5 Ethernet cable

• Supports resolutions of up to 1280 x 1024 at 60Hz refresh (depends on distance of

remote displays)

Before You Begin

System Requirements

• 1 x STUTPRXL Remote Receiver module for each remote display (not provided)

• 1 x HD15 male-to-male VGA cable

• Category 5 Ethernet cable terminated at each end with RJ-45 connectors, one for

each remote display (if using surface cabling)

Category 5 Ethernet cable terminated at each end in a wall-mounted outlet, with a

standard Category 5 patch cable, two for each remote display (if using premises

cabling)

Do you need additional cables? Visit www.startech.com to find what you need and the

name of your local StarTech.com dealer.

NOTE: The total length of RJ45 cables supporting each remote display cannot exceed

1000 feet (300 meters) from the VGA Extender unit to the remote.

Contents

• 1 x Local VGA Extender/Splitter

• 1 x VGA cable (HD-15 male-to-male)

• 1 x Power adapter DC 12V 600mA

• 1 x User Manual

IInnssttaallllaattiioonn

The VGA Extender is composed of two different units: the ST124UTPE(4-

port)/ST128UTPE(8-port) Extender and Splitter, along with a STUTPRXL Remote

Receiver (available seperately). The VGA Extender takes the output from a VGA source

(usually a computer) and transmits it to one or more Remote Receivers over Category 5

Ethernet cable. Each remote display (monitor, projector) connects to a Remote Receiver

using a standard VGA connection and displays the image from the local computer on the

remote display.

Preparing Your Site

Before you can install the VGA Extender, you need to prepare your site.

1. Determine where the local computer will be located and set up the computer.

2. Determine where the remote displays will be located, situate them appropriately.

3. If you are using surface cabling, ensure you have enough Category 5 Ethernet cabling

to connect the VGA Extender to each remote location, and that each end is terminated

with an RJ-45 connector.

If you are using premises cabling, ensure that the Category 5 Ethernet Cabling

between the VGA Extender and each remote display location has been properly

terminated in a wall outlet in each location and there is a patch cable long enough to

connect the Remote Receiver and the VGA Extender to their respective outlets.

Installing the VGA Extender and Splitter (local)

1. Place the VGA Extender (ST128UTPE/ST124UTPE) near the local computer.

2. Switch off the computer.

3. Connect the data cable from the local computer display to the OUTPUT port

on the VGA Extender.

4. Connect the HD15 male-to-male VGA cable (provided) to the INPUT port on the VGA

Extender.

5. Connect the other end of the HD15 male-to-male VGA cable to the VGA Out

connection on the local computer (originally occupied by the local computer display).

6. Connect the Ethernet cable connection for each Remote Receiver to an RJ-45

port on the VGA Extender (marked Cat. 5).

7. Connect the AC Adapter (provided with local unit) into an appropriate power

source and plug the opposite end into the DC/12V port on the VGA Extender.

Step 3

(See Below)

Step 4

(See Below)

Step 7

(See Below)

Back

Front

Step 6 (See Below)

Installing the Remote Receiver Module

1. Connect the Remote Receiver to the Ethernet cable connection from the VGA

Extender, marked Cat. 5.

2. Connect the data cable from the display to the opposite side of the receiver,

marked VGA OUT.

3. Repeat steps 1and 2at each remote display location.

4. Connect the AC Adapter (provided with remote unit) into an appropriate power

source and plug the opposite end into the DC/12V port on the Remote Receiver.

CAUTION: The Category 5 Ethernet cables that connect the VGA Extender and Remote

Receivers carry electrical current and should not be plugged in to other devices, as they

may cause damage. We strongly recommend marking the Ethernet cables you are using

with the VGA Extender at every location for easy identification.

Completing the Installation

1: Switch on the local computer and display.

2: Switch on the display at each remote location.

3: Verify that every remote display/monitor is properly displaying the image from the local

computer connected to the VGA Extender.

TTrroouubblleesshhoooottiinngg

The following section provides troubleshooting help. The solutions are arranged in the

order they should be attempted in most situations. If you continue to have difficulties

after attempting the solutions in this section, please contact StarTech.com technical

support.

One or more of the remote displays is black or displays a “no signal” message:

This means that the Remote Receiver is not receiving a signal from the VGA Extender.

(1) Check that the display is receiving power and that all cables are connected.

(2) Check that the display is connected to the Remote Receiver.

(3) Try an alternate RJ-45 connector on the VGA Extender.

(4) If you have a computer connected to the VIDEO IN port on the Remote Receiver,

switch it off and/or disconnect it.

One or more remote displays does not display an image when the local computer

wakes up from Standby Mode:

Power the remote displays OFF and ON again.

One or more remote displays is distorted, noisy, or displays a “signal error” or

similar error message.

The screen resolution and/or refresh rate on the local computer may be set too high for

the capabilities of the remote displays. to remedy this:

(1) Adjust the local computer to a lower resolution and refresh rate until all

remote displays show an image.

(2) Gradually increase the resolution and refresh rate on the local computer

until one (or more) remote displays ceases to display an image.

(3) Return the resolution and refresh rate on the local computer to the highest

resolution and refresh rate setting that displayed an image on all remote

displays.

NOTE: If you are still unable to see an image on a remote display after trying the above

solutions, it is recommended that you verify the Category 5 Ethernet cable installation to

the remote display before calling technical support. This can be done using a standard

cable tester. If you do not have a cable tester, contact a local computer service or wiring

professional.

SSppeecciiffiiccaattiioonnss

Resolution Up to 1280 x 1024 @ 60Hz

(can be affected by overall cable length)

Sync TTL Compatible

Horizontal/Vertical Sync Polarity Positive/Negative

System Cable Maximum

Distance

Category 5 Shielded FTP Cable 1000 feet

(300 meters)

Connectors

ST124UTPE: 4 x Cat. 5

1 x HD-15 VGA (in)

1 x HD-15 VGA (out)

ST128UTPE: 8 x Cat. 5 (out)

1 x HD-15 VGA (in)

1 x HD-15 VGA (out)

Power External Adapter: 12V DC 600mA

Dimensions (L x W x H) mm: ST124UTPE: 130 x 83.5 x 29.5

ST128UTPE: 200 x 83.5 x 29.5

Weight ST124UTPE: 247g

ST128UTPE: 345g

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer Parts”.

Since 1985, we have been providing IT professionals with the quality products

they need to complete their solutions. We offer an unmatched selection of

computer parts, cables, server management solutions and A/V products and

serve a worldwide market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products and to

access exclusive interactive tools such as the Parts Finder and the KVM

Reference Guide. StarTech.com makes it easy to complete almost any IT

solution. Find out for yourself why our products lead the industry in performance,

support, and value.

Revised: 10 February 2006

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels StarTech.com Extenseur

StarTech.com

StarTech.com DPBOOST Manuel utilisateur

StarTech.com

StarTech.com USBthere USB100EXT Manuel utilisateur

StarTech.com

StarTech.com SV565UTPDUV Manuel utilisateur

StarTech.com

StarTech.com USBthere USB221EXT Manuel utilisateur

StarTech.com

StarTech.com ST121HD20L Manuel utilisateur

StarTech.com

StarTech.com ST121UTPHD2 Manuel utilisateur

StarTech.com

StarTech.com USBthere USB110EXT Manuel utilisateur

StarTech.com

StarTech.com PS2UTPEXT Manuel utilisateur

StarTech.com

StarTech.com ST121R Manuel utilisateur

StarTech.com

StarTech.com ST121UTPMINI Manuel utilisateur

StarTech.com

StarTech.com ST128UTPE Manuel utilisateur

StarTech.com

StarTech.com RS232EXTC1 Manuel utilisateur

StarTech.com

StarTech.com STUTPRXWAL Manuel utilisateur

StarTech.com

StarTech.com 33FT-8K-HDMI-BOOSTER Manuel utilisateur

StarTech.com

StarTech.com ST121UTP Manuel utilisateur

StarTech.com

StarTech.com IPUSB2HD3 Manuel utilisateur

StarTech.com

StarTech.com USB2004EXTGB Manuel utilisateur

StarTech.com

StarTech.com STUTPRXL Manuel utilisateur

StarTech.com

StarTech.com USB2G4LEXT2 Manuel utilisateur

StarTech.com

StarTech.com 8STSV565HDIP Manuel utilisateur

StarTech.com

StarTech.com ST12MHDLNHR Manuel utilisateur

StarTech.com

StarTech.com ST12MHDLAN Manuel utilisateur

StarTech.com

StarTech.com STDHVHDBT Manuel utilisateur

StarTech.com

StarTech.com ST121SHD30 Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
