StarTech.com ST121SHD50 Manuel utilisateur

Manual Revision: 04/24/2019

User Manual

For the latest information and specications visit

www.startech.com/ST121SHD50

HDMI® Over Cat 5e/6 Extender | 50m

Actual product may vary from photos

SKU#: ST121SHD50

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference when

the equipment is operated in a commercial environment. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference

to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to

correct the interference at his own expense.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference,

and (2) this device must accept any interference received, including interference

that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void

the user’s authority to operate the equipment.

Industry Canada Statement

This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (A)/NMB-3(A)

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Product Diagram....................................................................................4

Top View ....................................................................................................................................................... 4

Front View.................................................................................................................................................... 5

Rear View...................................................................................................................................................... 6

Introduction............................................................................................7

Package Contents ..................................................................................................................................... 7

Requirements ............................................................................................................................................. 7

Installation ..............................................................................................8

Preparing Your Site ................................................................................................................................... 8

Hardware Installation .............................................................................................................................. 8

Operation ................................................................................................10

Video Adjustment (Receiver Unit Only) ............................................................................................ 10

EDID Conguration................................................................................11

Auto EDID Conguration........................................................................................................................ 12

Manual EDID Conguration (EDID Copy/EDID Ghost)................................................................. 12

EDID Factory Default Setting ................................................................................................................ 13

DDC Pass Mode.......................................................................................................................................... 14

LED Indicators.........................................................................................14

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Top View

1LED Indicator

2EDID Copy Button

3LED Indicator

4EQ Selector

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Front View

1LINK OUT A (RJ-45 Connector)

2LINK OUT B (RJ-45 Connector)

3LINK OUT A (RJ-45 Connector)

4LINK OUT B (RJ-45 Connector)

12 3 4

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Rear View

1Power Jack Port

2HDMI In Port

3Power Jack Port

4HDMI Out

1 2 3 4

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Introduction

The ST121SHD50 HDMI® over CAT5e/6 Video Extender kit lets

you extend HDMI® video and audio up to 165 feet (50 Meters)

(1080i) over 2 CAT5e Ethernet cables, or up to 130 Feet (40

Meters)(1080p) over 2 CAT6 Ethernet cables.

Package Contents

• HDMI over CAT5e/6 UTP transmitter x 1

• HDMI over CAT5e/6 UTP receiver x 1

• Universal power adapter (NA / EU / UK / AU) x 1

• Mounting brackets x 2

• Foot pad set x 2

• User Manual x 1

Requirements

Requirements are subject to change. For the latest

requirements, please visit www.startech.com/ST121SHD50.

Video Device

• HDMI® enabled video source device (i.e. computer, Blu-ray

Player)

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Display Device

• HDMI® enabled display device (i.e. television, projector)

Cables

• HDMI® cables for Receiver and Transmitter

• CAT5e/CAT6 Cables x 2

Note: Two cables are necessary for transmitting video signal

and DDC data.

Installation

Preparing Your Site

1. Determine where the local video source (i.e. computer, Blu-

ray Player) will be located and set up the device.

2. Determine where the remote display will be located and

place/ mount the

display appropriately.

Note: This HDMI® extender kit features Power over cable, al-

lowing both the Transmitter and Receiver to be powered from

a single power source that can be connected at either end of

the connection. Please ensure that either the Transmitter or

the Receiver Unit is situated near an available AC electrical

outlet. Make sure all devices are turned o before beginning

installation.

Hardware Installation

1. Position the Transmitter Unit near the video source (i.e.

Computer, Blu-ray Player).

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

2. Connect an HDMI® cable from the video source device

(i.e. computer, Blu-ray Player) to the “HDMI® IN”on the

Transmitter Unit.

3. (Optional) If you’ve chosen to power the kit from the

Transmitter side, connect the provided power supply.

4. Connect an RJ45 terminated Cat5e/6 Ethernet cable (not

included) to the LINK OUT A (RJ-45 connector) on the

Transmitter unit.

5. Connect another RJ45 terminated Cat5e/6 Ethernet cable

(not included) to the LINK OUT B (RJ-45 connector) on the

Transmitter unit.

Note: If you are using surface cabling, ensure you have

enough Category 5e unshielded twisted pair (UTP) network

cabling to connect the Host Unit to the Remote Unit’s loca-

tion, and that each end is terminated with a RJ45 connector.

The cabling should not go through any networking equip-

ment (i.e. router, switch).

- or -

If you are using premises cabling, ensure that the Category 5

unshielded twisted pair (UTP) network cabling between the

Host Unit and the Remote Unit has been properly terminated

in a wall outlet in each location and there is a patch cable

long enough to connect the Remote Unit and the Host Unit

to their respective outlets. The cabling should not go through

any networking equipment (i.e. router, switch).

6. Connect the other end of the Cat5e/6 cable (from LINK OUT

A) to the LINK IN A (RJ-45 connector) on the Receiver Unit.
