StarTech.com SATADOCK525 Manuel du système

5.25in Bay Mounted 2.5in and 3.5in SATA Hard Drive Docking Station

StarTech ID: SATADOCK525

This SATA hard drive dock/docking station can be mounted internally in a 5.25in computer drive bay, to provide

simple access to 2.5in or 3.5in SATA hard drives.

Featuring a convenient trayless design, the internal hard drive dock doesn't require that hard drives be mounted in

an enclosure, saving time and hassle. Once the docking station is connected to the host computer, it's as simple as

inserting the desired SATA hard drive into the slot(s) as needed for full access to the hard drive(s) as though

installed conventionally within the computer case.

The HDD dock accommodates both 2.5in and 3.5in SATA hard drives and can support one of each at the same

time. Plus, when the 3.5in slot is not in use, two 2.5in drives can be inserted simultaneously.

The 5.25in bay-mounted SATA Hard Drive Dock features front panel power control, allowing you to power the drives

on/off as needed.

Applications

Easily add two SATA hard drives to a system with an available external 5.25" bay

System builders who need to image drives quickly and efficiently

Environments where drives need to be replaced/removed regularly, without external protection for the drives

required after removal

Be able to replace/remove individual drives from a storage array with minimal or no system down time

intrl.startech.com

Features

Supports one 2.5" and one 3.5" SATA form factor hard drive (HDD) or solid state drive (SSD) simultaneously

Fits into a single 5.25" drive bay

Dust resistant drive door design

Front accessible power button

Power/Activity LED indicators for each drive

Fully supports SATA 1/2/3 (1.5/3.0/6.0 Gbps) drives and controllers

intrl.startech.com

Technical Specifications

Warranty 2 Years

Interface SATA

Number of

Drives

Drive Size 2.5in & 3.5in

Drive Type SATA

Drive

Installation

Removable

Fan(s) No

Drive

Connectors

2 - SATA Data & Power Combo (7+15 pin) Receptacle

Host

Connectors

2 - SATA Data & Power Combo (7+15 pin) Plug

Type and

Rate

SATA III (6 Gbps)

RAID No

Max Drive

Capacity

Tested up to 2.0 TB

Hot Swap

Capability

Yes

Color Black

Enclosure

Type

Plastic

Product

Length

5.7 in [145 mm]

Product

Width

4.3 in [108 mm]

Product

Height

1.7 in [42 mm]

Product

Weight

8.5 oz [240 g]

LED

Indicators

2 - Power/Activity

Note Hot-swap capabilities are a function of the SATA controller that the dock is connected to. If hot-

swappable, then the hard drive can be removed and replaced without the need to restart the

operating system.

Shipping 15.9 oz [450 g]

intrl.startech.com

(Package)

Weight

Included in

Package

1 - SATA Docking Station

Included in

Package

2 - SATA 15 pin Power Cables

Included in

Package

2 - SATA 7 pin Data Cables

Included in

Package

4 - Mounting Screws

Included in

Package

1 - Instruction Manual

Certifications, Reports and Compatibility

intrl.startech.com
